2004 Citroen XSARA PICASSO Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 245
INJECTION
PROHIBITED OPERATIONS: SIEMENS HDI DIRECT INJECTION SYSTEM
Engines: 8HX 8HW 8HZ
Cleaning.
The use of high pressure cleaners is prohibited.
Do not use compressed air.
Fuel supply circuit.
Required fuel: diesel.
Electric circuit.
Swapping injection ECUs between two vehicles will render it impossible to start either vehicle.
It is forbidden to supply a diesel injector with
12 volts.
High pressure fuel pump.
Do not separate the following components from the high pressure fuel pump (5):
Sealing ring
(a)(no replacement parts).
High pressure outlet connector
(b)(will cause a malfunction).
PS: HDi = High pressure Diesel injection
B1HP1K9C
C2 C3 XSARA

Downloaded from www.Manualslib.com manuals search engine 246
INJECTION
PROHIBITED OPERATIONS: SIEMENS HDI DIRECT INJECTION SYSTEM
Engines: 8HX 8HW 8HZ
Diesel injectors.
WARNING: Diesel and ultrasonic c
leaners are prohibited.
Do not separate the following components from the diesel injector
carrier
(2):
Diesel injector
(f)(no replacement parts).
Electromagnetic element
(c)(no replacement parts).
Do not alter the position of the nut
(d)(malfunction).
Do not separate the connector
(e)from a diesel injector.
It is forbidden to clean the carbon deposits from the diesel injector
nozzle.
B1HP1KACB1HP1KBC
C2 C3 XSARA

Downloaded from www.Manualslib.com manuals search engine 247
INJECTION
PROHIBITED OPERATIONS: DELPHI HDI DIRECT INJECTION SYSTEM
Engines: 8HY 8HV
Cleaning.
The use of high pressure cleaners is prohibited.
Do not use compressed air.
Fuel supply circuit.
Required fuel: diesel.
Electric circuit.
Swapping injection ECUs between two vehicles will render it impossible to start either vehicle.
It is forbidden to supply a diesel injector with
12 volts.
High pressure fuel pump.
Do not separate the following components from the high pressure fuel pump (5):
Sealing ring
(a) (no replacement parts).
High pressure outlet connector
(b)(will cause a malfunction).
PS:HDi = High pressure Diesel injection
B1HP1J6C
C3

Downloaded from www.Manualslib.com manuals search engine 248
INJECTION
PROHIBITED OPERATIONS: DELPHI HDI DIRECT INJECTION SYSTEM
Engines: 8HY 8HV
B1HP1J7CB1HP1J8C
Fuel high pressure injection common rail.
Do not separate the pressure regulator «c»from the injection
common rail (2)(Risk of malfunction).
Diesel injectors.
WARNING:
Diesel and ultrasonic cleaners are prohibited.
Do not separate the following components from the diesel
injector carrier
(3):
Diesel injector (e)(no replacement parts).
Electromagnetic component «d»(no replacement parts).
It is forbidden to clean the carbon deposits from the diesel
injector nozzle..
C3

Downloaded from www.Manualslib.com manuals search engine 249
INJECTION
PROHIBITED OPERATIONS: HDi DIRECT INJECTION SYSTEM
Engines: RHY RHZ
XSARA PICASSO
Cleaning.
The use of high pressure cleaners is prohibited.
Do not use compressed air.
Fuel supply circuit.
Required fuel: diesel.WARNING:Do not use other fuels.
Electric circuit.
Swapping injection ECUs between two vehicles will render it impossible to start either vehicle.
It is forbidden to supply a diesel injector with
12 volts.
High pressure fuel pump.
Do not separate the following components from the high pressure fuel pump (5):
High pressure fuel pump third piston deactivator (3)(no replacement parts).
High pressure fuel regulator (4)(no replacement parts).
Sealing ring (1)(no replacement parts).
High pressure outlet connector (3)(will cause a malfunction).
PS:HDi = High pressure Diesel injection
B1HP12CC

Downloaded from www.Manualslib.com manuals search engine 250
INJECTION
PROHIBITED OPERATIONS: HDi DIRECT INJECTION SYSTEM
Engines: RHY RHZ
XSARA PICASSO
High pressure fuel injection common rail. Do not separate the connectors (7)from the common injection rail (6)(malfunction).
Diesel injectors.
WARNING:Diesel and ultrasonic cleaners are prohibited.
Do not separate the following components from the diesel injector carrier (9):
Diesel injector (8)(no replacement parts).
Electromagnetic element (11)(destruction).
Do not alter the position of the nut (10)(malfunction).
Do not separate the connector (12)from a diesel injector.
It is forbidden to clean the carbon deposits from the diesel injector nozzle.
Identification: Injector carrier
There are two types of diesel injector carrier classed according to fuel flow.
Identification by engraving or paint mark
B1HP12EC
B1HP12DC
B1HP16PC
IMPERATIVE: When replacing a
diesel injector carrier, order a
component of the same class.
(See repair manual)
Identification markings:
«a»:Supplier identification.
«b»:PSA identification number.
«c»:Class identification.
Injector carrier
Class 1
Class 2
Engraving
1
2
Paint mark
Blue
Green
Location
On the upper part of the
coil near to the fuel return
aperture

Downloaded from www.Manualslib.com manuals search engine 251
INJECTION
SPECIFICATIONS OF THE DELPHI DIESEL INJECTION PUMP
PUMP TYPE REFERENCE
Dépollution
EquipmentL3
Transponder
XSARA
XSARA
8B
DWWJYDWLP 12
R8448 B
371 B

Downloaded from www.Manualslib.com manuals search engine 252
INJECTION
SPECIFICATIONS OF THE DELPHI DIESEL INJECTION PUMP XSARA
Engine
typePump
Type
ReferenceStatic timing
Initial advance
Compression
Time
(cylinder N° 4)Dynamic
timing
checking
(at idle)Reference
InjectorInjector
holder
+ injectorCode
colourInjector
needle lift
pressure
(Bar)Adjustments (rpm) Max. speed
Fast
idlingAntistall
IdlingUnladen
rpmLaden
rpm
WJYDWLP 12
R 8448 B/*RDNO
SDC
6903LDCR
0260
IAA135,5
±5950
±25875
±25875
±255350
± 125
Engine
TDC
Pegging hole.
Value «X»
engraved on
the pump.
(*) = See table page: 251.1500
+ 3
mm
shim
