2004 Citroen XSARA PICASSO Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 453
BRAKES
BRAKE SPECIFICATIONS
Engine type6FZ RFN 9HZ 9HY RHY
Master cylinder
23,8
Ø Master vac
mm Master cylinder travel
254/35
FT Piston Makes/CaliperBOSCH ZOH54/54
Disc Ventilated283
Disc thickness/minimum thickness26/24
Makes/Brake pad gradeFERODO/769 (37)
Rear brake caliper
Ø Supplier/Type
TRW C38
mm Disc plain247
RR Disc thickness/minimum thickness9/7
MakeGALFER
Brake lining gradeG 4554
Compensator – cutoff in BarsOn versions with ABS, there is no loadsensitive
rear braking compensator.
(*) ESP = Electronic Stability Program.All types
Ftec ESP (*)
1.8i 16V 2.0i 16V 1.4 HDi 2.0 HDi
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 454
BRAKES
B3FP7B9D
BRAKING SYSTEM SPECIFICATIONS
Without ABS
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 455
BRAKES
B3FP7B9DB3FP7BRD
BRAKING SYSTEM SPECIFICATIONS
With EPS (Electronic Stability Program)
With ABS
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 456
BRAKES
BRAKE SPECIFICATIONS XSARA PICASSO
Braking system specifications
“X”braking circuit.
Front: disc brakes, ventilated. Rear:drum brakes with automatic adjustment.
Cable operated handbrake acting on the rear wheels.
Load sensitive braking compensator
(non ABS versions).
(1) Hydraulic valve block «ABS Bosch 5.3»or(1) Hydraulic valve block + ECU.(2) Load sensitive braking compensator (according to version).
B3FP09HCB3FP08ND
2
1

Downloaded from www.Manualslib.com manuals search engine 457
BRAKES
B3FP11XD
HANDBRAKE (Adjustment)
XSARA PICASSO
Adjustment.
Remove the handbrake trim (1).
Unclip the sounddeadening (2).
Raise and support the vehicle with the rear wheels
hanging free.
Check the correct routing of the brake cables under the
vehicle.
Apply and release the handbrake
4 times.
Set the handbrake to the 5th notch.
Tighten the nut
(3)until the rear brakes are applied.
Pull the handbrake lever vigorously 4 to 5 times.
Set the handbrake to the 5th notch.
Check that the rear brakes are applied.
With the handbrake released, check that the wheelscan be turned freely by hand.
Lower the vehicle.Refit the sounddeadening
(2)and the handbrake trim (1).

Downloaded from www.Manualslib.com manuals search engine 458
BRAKESBLEEDING THE BRAKESXSARA PICASSO
Tools.Bleeding equipment of type «LURO» or similar.IMPERATIVE: For bleeding the secondary circuit, use ELIT, LEXIA or PROXIA diagnostic tools.
Draining.
Drain the brake fluid reservoir as empty as possible using a syringe.
Disconnect the brake fluid warning lamp connector.Retrieve the brake fluid reservoir from its supply pipes by pulling upwards.
Finish emptying the reservoir of brake fluid.
Clean the brake fluid reservoir.
Refit the brake fluid reservoir.
Reconnect the brake fluid warning lamp connector.
Filling.Refill the reservoir with brake fluid.WARNING:Use only the recommended hydraulic fluids.
Bleeding.
NOTE:Two technicians are required.
IMPERATIVE:During bleed operations, ensure that the level of brake fluid is maintained in the
reservoir and top it up, use only new brake fluid.
Bleed each wheel cylinder, proceeding in the following order:
Rear right hand wheel.
Front left hand wheel.
Rear left hand wheel.
Front right hand wheel.

Downloaded from www.Manualslib.com manuals search engine 459
ELECTRICAL
SYSTEM
STARTER MOTORS
Abbreviations and definitions
ALL TYPES
Coding of climates is as follows:
CLIMATES:C Hot
: Starting possible as low as 18°C.
T Temperate: Starting possible as low as 18°C.
F Cold: Starting possible as low as 25°C.
GF Very cold: Starting possible as low as 30°C.
Meaning of abbreviations:
BV
: Gearbox.
M: Manual gearbox.
A: Automatic gearbox.
MAP: Piloted manual gearbox.
DA: Powerassisted steering.
REFRI: Air conditioning.

Downloaded from www.Manualslib.com manuals search engine Table of class of starter motors
STARTER MOTORS
CLASS CLASS 2 CLASS 3 CLASS 4 CLASS 5 CLASS 6
Torque C
5.5 Nm 6 Nm 10 Nm 11.5 Nm 11.5 Nm
Maximum power for
a speed of 1200 rpm
I ≤ 275 A I ≤300 A I ≤430 A I ≤470 A I ≤500 A
ALL TYPES
460
ELECTRICAL
SYSTEM
Vehicles/models Starter type Class Climate
