2004 Citroen XSARA PICASSO Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 421
BRAKES
B3FP15XC
BLEEDING AND FILLING THE BRAKING SYSTEM
Tools.
[1]
Generic bleeding apparatus :«LURO»Bleeding, refilling.
Draining.
Drain the brake fluid reservoir (1)to the maximum(if necessary, use a clean syringe).
Disconnect the connector (4).
Uncouple the pipe (2).
Unscrew the shaft (3).
Remove the reservoir (1).
Empty the brake fluid reservoir (1).
Clean the brake fluid reservoir (1).
Refit:
The brake fluid reservoir
(1).
The shaft (3).
Couple the pipe (2).
Reconnect the connector (4).
Filling the braking system.WARNING:Use only those hydraulic fluids that are approved and recommended.
Fill the brake fluid reservoir (1).
Bleeding the braking system.WARNING:During the bleeding operation, take care to maintain the level of brake fluid in the reservoir
and to top it up, using only brake fluid that is clean and clear.
C2

Downloaded from www.Manualslib.com manuals search engine 422
BRAKES
B3FP15YCB3FP15ZD
BLEEDING AND FILLING THE BRAKING SYSTEM (Continued)
Bleeding the primary braking circuit.
WARNING:The ABS should not be active during the
bleeding operation.
Front brake caliper, Bleed screw
(5).A: Rear brake caliperB: Rear brake drum
Bleed screw
(6).
Bleed each wheel cylinder, proceeding in the following
order:
Front LH wheel.
Front RH wheel.Rear LH wheel.
Rear RH wheel.
C2

Downloaded from www.Manualslib.com manuals search engine 423
BRAKES
B3FP160C
BLEEDING AND FILLING THE BRAKING SYSTEM (Continued)
With the bleeding apparatus.
Connect the bleeding apparatus [1]on the brake fluid reservoir (1).
Adjust the apparatus pressure to
2 Bars.
For each circuit:
Connect a transparent tube onto the bleed screw, submerge the other end of the tube in a clean container.
Open the bleed screw, wait until the fluid is flowing out without air bubbles. Close the bleed screw.
Remove the bleeding apparatus
[1].
Check the brake fluid level
(should be between «MINI»level and «MAXI»level).
Fill if necessary with the approved and recommended synthetic brake fluid.
Without the bleeding apparatus.
NOTE:Two operators are necessary.
For each circuit:
Apply the brake pedal to place the circuit under pressure.
Connect a transparent tube onto the bleed screw, submerge the other end of the tube in a clean container.
Open the bleed screw, wait until the fluid is flowing out without air bubbles.
Close the bleed screw. Remove the tool
[1].
NOTE:Recommence the process a second time if that is necessary.
Check the brake fluid level
(should be between «MINI»level and «MAXI»level).
Fill if necessary with the approved and recommended synthetic brake fluid.
C2

Downloaded from www.Manualslib.com manuals search engine 424
BRAKESBRAKE SPECIFICATIONS (WHITHOUT ABS REF)
Engine typeHFX KFV KFU 8HX 8HW
Master cylinder
20,6
Ø Master vac203,2
mm Caliper/piston makesLUCAS/TRW C48/13 48
FT Disc Plain266 266
Disc thickness/minimum thickness13/1113/11
Ø
mm Disc Ventilated266
Disc thickness/minimum thickness22/20
Brake pad gradeTEXTRR T 4144
ØDrum / Max. thickness
mm Width203/205/38
RRMakeDON
Brake lining grade8259
Braking compensator (Vehicle without ABS) (CICR= Compensator integral to the wheel cylinder). REF= Electronic brakeforce distribution.
Supplier/Type/Cutoff pressure (Bar)RPO 9666 LUCAS LUCAS/CICR/35Supplier/Type/Cutoff pressure (Bar)RPO 9667 LUCAS LUCAS/CICR/27 1.1i
1.4i1.4i 16V 1.4 HDi
C3

Downloaded from www.Manualslib.com manuals search engine 425
BRAKES
BRAKE SPECIFICATIONS (WITH ABS REF)
Engine type HFX KFV KFU NFU 8HX 8HW 8HV 8HY
Master cylinder
22,2(*)
Ø Master vac
228,6
mm Caliper /piston LUCAS/TRW LUCAS/TRW LUCAS/TRW LUCAS/TRWmakesC 48/13 48 C 54/22 54 C 48/13 48 C 54/22 54
Disc Plain266 266
FT Disc thickness/minimum thickness13/11 13/11
Ø
mm Disc Ventilated266 266
Disc thickness/minimum thickness22/20 22/20
Brake pad gradeTEXTRR T 4144
Ø Cylinder or caliperLUCAS C38 HR 9/13
mm Disc Plain247 247
RR Disc thickness/minimum thickness9/7 9/7
Ø Drum / Max. thickness /
mm Width203/205/38 203/205/38
MakeDONGALFER DON GALFER
Brake lining grade8259 G 4554 8259 G 4554
(*)= With emergency braking system.REF= Electronic brakeforce distribution.NOTE:Braking compensators = The compensator and limiter functions for the main brakes are assured by the ABS REF system. 1.1i 1.4i 1.4i 16V 1.6i 16V 1.4 HDi 1.4 HDi 16V
C3

Downloaded from www.Manualslib.com manuals search engine 426
BRAKESBRAKE SPECIFICATIONS (WITH & WITHOUT ABS REF)
Engine typeKFV 8HX KFV NFU 8HX
Master cylinder
20,6 22,2(*)
ØMaster vac
203,2228,6
FT mm Makes /piston makesLUCAS/TRW C38 HR 9/13
Disc Ventilated266
Disc thickness/minimum thickness22/20
Brake pad gradeTEXTRR T 4144
ØCylinder or caliperLUCAS/TRW C 38/13 38
mmDiscPlain247
RR Disc thickness/minimum thickness9/7
ØDrum / Max. thickness /
mmWidth203/205/38203/205/38
MakeDONGALFERDON
Brake lining grade8259/1 G 4554 8259/1
(*)= With emergency braking system.(CICR = Compensator integral to the wheel cylinder)Braking compensator (Vehicle without ABS)REF= Electronic brakeforce distribution.
Supplier/Type/Cutoff pressure (Bar) :LUCAS/CICR/27
Braking compensator (Vehicle with ABS)NOTE:Braking compensators = The compensator and limiter functions for the main brakes are assured by the ABS REF system.
C3 PLURIEL
Sans ABS REF Ftec ABS REF
1.4i 1.4 HDi 1.4i 1.6i 16V 1.4 HDi

Downloaded from www.Manualslib.com manuals search engine 427
BRAKES
B3FP161D
BRAKE SPECIFICATIONS
Braking circuit without ABS REF (drum brakes at the rear)
Braking system specifications
Braking circuit at «X».
Front brakes with ventilated discs
(*).
Rear brakes with eitther drums or discs
(*).
Handbrake lever controlling cables acting on the rear
wheels.
The compensator and main brake limiter functions are
assured by the
ABS EBD system.
NOTE: REF= Electronic Brakeforce Distribution.
(*)= according to version.
C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 428
BRAKESBRAKE SPECIFICATIONS
Braking circuit with ABS REF (drum brakes at the rear)
B3FP162D
C3 C3 PLURIEL
