INJECTION
SPECIAL FEATURES: PARTICLE FILTER / CHECKING THE ADDITIVE PUMP
Engine: 9 HZ
IMPERATIVE: Respect the safety and cleanliness requirements.
Tools.
[1]
Manual pressure/vacuum pump: FACOM DA 16
[2]Additive container: ().1613.G Kit 1613
Checks.
IMPERATIVE: Respect the safety and cleanliness requirements specific to HDi engines.
IMPERATIVE: For all operations on the additive circuit, wear protective goggles and gloves that are
resistant to hydrocarbons.
Place the vehicle on a lift.
Raise the vehicle
To test the flow of the additive pump :
Uncouple the tube
(1).
Couple tool [2]on the outlet «a»of the additive reservoir.
Operate for 50 secondsthe actuator test «Additive pump»with the aid of LEXIA or PROXIA.
IMPERATIVE:The volume collected by the tool [2] should be 20 ± 5 ml.
NOTE:
Replace the additive pump if it is defective.
Couple the tube (1).
Operate the actuator test «Filling the tube: additive pump – additive injector», with the aid of LEXIAorPROXIA.
B1HP1UTC
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 278
INJECTION
SPECIAL FEATURES: PARTICLE FILTER / CHECKING THE ADDITIVE PUMP
Sealing of the additive injector.
Couple tool [1] to the tube (1).
Action the manual pump [1].
WARNING:The additive injector should open at a pressure of 100 ± 20 Bars.
Action the manual pump in vacuum
[1]at 800 m.bars.
WARNING:The downstream pressure should not fall rapidly.
NOTE:Replace the fuel tank if the injector is defective.
Couple the tube
(1).
Operate the actuator test «Filling the tube: additive pump – additive injector», with the aid ofLEXIAor PROXIA.
Check the additive level.
The checking of the additive level is done with reference to the gradations «a»marked on the additive
reservoir.
The top graduation indicates maximum filling
(3 Litres).
The difference between the two gradations equates to 0,25 Litres.
XSARA PICASSO
B1HP1UUC
B1KP019C

Downloaded from www.Manualslib.com manuals search engine 279
1.1iHFX
FR7 DE RFN 58 LZ RC 8 YLC
C2 1.4i KFV
1.6i 16V NFU FR7 ME 0,9 ± 0,1 RFN 58 HZ
1.1i HFX
FR7 DERFN 58 LZ RC 8 YLC
1.4i KFV
C3 1.4i 16V KFU VR8 SE 0,9 ± 0,05
1.6i 16V NFU FR7 ME RFN 58 HZ
C3 1.4i KFV FR7 DE RFN 58 LZ RC 8 YLC
PLURIEL1.6i 16VNFUFR7 MERFN 58 HZ
0,9 ± 0,05 0,9 ± 0,05 2.5 ± 0,2
1.4iKFWFR7 DE0,9 ±0,1 RFN 58 LZ RC 8 YLC mda.N
XSARA 1.6i 16V NFU FR7 ME RFN 58 HZ
2.0i 16V RFN FR8 ME RFN 52 HZ REC 9 YCL
RFSFR6 DE RFN 62 LZ
1.6i90 hp
NFVRFN 58 LZ
XSARA100 hpFR7 DE RC 8 YLC
PICASSO 1.8i 16V 6FZ
FR8 ME0,9 ± 0,1
RFN 52 HZ REC 9 YCL
2.0i 16V RFN
SPARKING PLUGS ALL TYPES
Vehicles
BOSCH Engine
typeEYQUEM
CHAMPION Electrode
gap settingTightening
torque
IGNITION
Electrode
gap settingElectrode
gap setting

Downloaded from www.Manualslib.com manuals search engine 280
SPEEDOMETERALL TYPES
An E.E.C. decree of 25 June 1976, regulates the speed displayed by the speedmeter in relation to the actual speed travelled.
This decree stipulates:
The speed indicated by a speedometer must never be lower than the actual vehicle speed.
Between the speed displayed «SD»and the speed travelled «ST», there must always be the following relationship:
ST < SD < 1.10 ST + 4 Kph
Example: For an actual speed of 100 Kphthe speed displayed by the speedometer may be between 100and 114 Kph.
The speed indicated by the speedometer may be influenced by:
The speedometer.
The tyres fitted to the vehicle.
The final drive ratio.
The speedometer drive ratio.
Any of these components can be checked without removing them from the vehicle
(see information note N° 78-85 TT of 19 October 1978).NOTE:Before replacing the speedometer, check the conformity of the following points:
The tyres fitted to the vehicle.
The gearbox final drive ratio.
The speedometer drive ratio.
CLUTCH
GEARBOX
TRANSMISSION

Downloaded from www.Manualslib.com manuals search engine CLUTCH
GEARBOX
TRANSMISSION
281
CLUTCH SPECIFICATIONS C2
Engine type HFX KFV NFU 8HX
Gearbox type Supplier
BVM BVM/BVMP (*)BVM/BVMP (*)BVM/BVMP (*)
MA 5/S MA 5 N/L MA 5 S/L MA 5/0
Mechanism / typeVALEO LUK
Engine type180 CP0 3400 200 P 3900
Bearing supplier / heightSKF 17 mm
Clutch disc11 R 10??
Ø of lining.Ext/Int180/127200/134
Quality of lining408
1.1i 1.4i 1.6i 16V1.4 HDi
(*): BVM = Manual gearbox.
: BVMP = Piloted manual gearbox.

Downloaded from www.Manualslib.com manuals search engine 282
CLUTCH
GEARBOX
TRANSMISSION
CLUTCH SPECIFICATIONS
C3 C3 PLURIEL
Engine type HFX KFV KFU NFU 8HX 8HW 8HV 8HY
Gearbox type Supplier
MA/5 BE4/5
Mechanism / typeVALEO ? LUK
Engine type180 CPO 3400200 MF
200 P 3900 230 P 4700
3850
Clutch disc11 R 10 X 200 VTB
Ø Garniture.Ext/Int180/127 ? 200/134 228/155
Quality of liningF408
1.1i 1.4i 16V 1.4 HDi1.4 HDi 16V1.4i 1.6i 16V

Downloaded from www.Manualslib.com manuals search engine 283
CLUTCH
GEARBOX
TRANSMISSION
CLUTCH SPECIFICATIONS XSARA
Engine type KFW NFU RFN RFS
Gearbox type Supplier
MA/5 MA/5 BE4/5
Mechanism / typeVALEO
Engine type180CPO 3400 200 CPR 3800 230 DNG 4700 215 DT 5250
Clutch disc180 XJF 73 C 200X(D95) 11A12X 230 DNG 4700 215 FD 95
Ø Garniture.Ext/Int180/127 200/137 228/155 215/147
Quality of liningF 408 F 808
1.4i 1.6i 16V2.0i 16V

Downloaded from www.Manualslib.com manuals search engine 284
CLUTCH
GEARBOX
TRANSMISSION
CLUTCH SPECIFICATIONS
XSARA
Engine type 8HZ WJY RHY RHZ
Gearbox type Supplier
BE4/5
Mechanism / typeLUK
Engine type200 P 4200 200 P 3700 230 P 4700 235 T 5700
Clutch disc215 F (D 93) 22 BX 228 228D
Ø Garniture.Ext/Int200/134 200/134 230/155 235/155
Quality of liningF 408F202
1.4 HDi 1.9 D2.0 HDi
