CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: HFX KFV NFU 8HX 8HW
(1)Retaining clip.(2)Secondary shaft.(3)Drive pinion (5th gear).(4) Bearing retaining clip screw.(5)Gearbox casing.(6)Intermediate plate.(7)Gearbox casing fixing screw.(8)Clutch bearing guide screw.(9) Clutch housing.(10)Bearing guide.(11)Primary shaft.(12)Differential housing.(13)Speedometer screw.(14)Counter drive.(15)Planet pinions.(16) Satellite pinions.(17)Differential gearwheel.(18)Driven pinion (1st gear).(19)1st / 2nd gear synchroniser and reverse gear driven pinion.(20)Driven pinion (2nd gear).(21) Driven pinion (3rd gear).(22) 3rd / 4th gear synchroniser.B2CP3SRP
C2 C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 302
CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: HFX KFV NFU 8HX 8HW
(23)Driven pinion (4th gear).(24)Driven pinion (5th gear).(25)5th gear synchroniser.
Tightening torques (m.daN).
(4)
Bearing retaining clip screw(x4):1,8 ± 0,2
(6)
Intermediate plate (11 fixing screws): 5 ± 0,5
(7)
Gearbox casing(15 fixing screws):1,9 ± 0,216 fixing screws RPO 9784
17 fixing screws RPO 9786

(8)Clutch bearing guide screw(3 fixing screws):0,6 ±0,15
B2CP3SRP
C2 C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 303
CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: HFX KFV NFU 8HX 8HW
Tightening torques (m.daN).
(26)
5th gear cover fixing screw(3 screws): 2,2 ± 0,2
(27) Reverse gear switch (1 screw): 2,5 ± 0,5
(28)Drain plug (1 screw):3,3 ± 0,3
(29) Topup plug (1 screw): 3,3 ± 0,3 (*)
(*) =
The oil topup plug is discontinued from RPO 9919
Features.This gearbox:
has no adjustment. has a reverse gear braking device
(5th gear synchroniser).
has a device for prohibiting a change from 5th gear into reverse gear.
The clutch control has a balljoint mounted declutch fork.
Lubrication.Oil capacity :2 ±0,15 Litres.Checking the oil level: No oil level check (*)Lubrication interval:Lubricated «for life».
NOTE:There should be a visual check on the sealing at each engine oil
change.
B2CP3SSD
C2 C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 304
CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: KFW NFU
«a»Identification label.
«b»Location for engraving of serial and gearbox nos.
B2CP3HTC
XSARA

Downloaded from www.Manualslib.com manuals search engine 305
CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: KFW NFU
(1)Primary shaft.(2)Clutch bearing guide.(3)Clutch housing.(4) Gearbox casing.(5) Intermediate plate.(6)Bearing retaining clip.(7) Drive pinion (5th gear).(8) Secondary shaft.(9)5th gear synchroniser.(10)Driven pinion (5th gear).(11)Driven pinion (4th gear).(12)3rd / 4th gear synchroniser.(13)Driven pinion (3rd gear).(14)Driven pinion (2nd gear).(15) 1st / 2nd gear synchroniser and reverse gear driven pinion.(16) Driven pinions (1st gear).(17)Differential gearwheel.(18)Satellite pinions.(19)Planet pinions.(20)Counter drive.(21)Speedometer screw.(22) Differential housing.B2CP167P
XSARA

Downloaded from www.Manualslib.com manuals search engine 306
CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: KFW NFU
Tightening torques (m.daN).
(23)
Clutch bearing guide (3 fixing screws): 0,6 ± 0,15.
(24)
Intermediate plate (11 fixing screws): 5 ± 0,5.
(25)
Rear cover (3 fixing screws):2,2 ±0,2.
(26)
Bearing retaining clip (4 fixing screws): 1,8 ± 0,2.
(27)
Secondary shaft nut (1 nut):14 ± 1.
(28)
Gearbox casing (15 fixing screws):1,8 ±0,2.
B2CP167P
XSARA

Downloaded from www.Manualslib.com manuals search engine 307
CLUTCH
GEARBOX
TRANSMISSION
MA/5 GEARBOX
Engines: KFW NFU
(29)Topup plug (x1): 2,5 ± 0,5.
(30)Drain plug (x1): 2,5 ± 0,5.
(31)Reverse gear switch (x1): 2,5 ± 0,5.
Strengthened MA gearboxes are marked with the letter «B»or «C»:«B»= Differential diameter 77 mm+ strengthened bearings.«C»= Differential diameter 77 mm+ strengthened bearings + strengthened
intermediate plate.
NOTE:All vehicles are equipped with clutch control by cable.
Features.
This gearbox:
has no adjustment.
has a reverse gear braking device
(5th gear synchroniser).
has a device for prohibiting a change from 5th gear into reverse gear.
The clutch control has a balljoint mounted declutch fork.
Lubrication.
Oil capacity : 2 ± 0,15 Litres.
Checking the oil level : Every 37,500 miles.
Lubrication interval : Lubricated «for life».
B2CP169D
XSARA

Downloaded from www.Manualslib.com manuals search engine 308
RECOMMENDATIONS PRECAUTIONS: MA PILOTED MANUAL GEARBOX
Safety requirements.
ESSENTIAL:Given the special features of the MA type piloted
manual gearbox, observe the requirements detailed below.
IMPERATIVE: Always disconnect the battery negative terminal
before operating on the actuators.
NOTE:
After disconnecting the battery, never try to remove the clutch
actuator on the vehicle before having checked that it is in the closed
position
(rod pushed in).
IMPERATIVE:After Sales checks done with the engine running must be
performed with «Neutral»engaged and the handbrake on (unless there
is a clear mention otherwise in the repair procedures).
IMPERATIVE:The areas of movement of the clutch fork and of the gear
engagement lever must always be kept free during the actuatoroperating phases.
CLUTCH
GEARBOX
TRANSMISSION
IMPERATIVE:When initialising the clutch actuator and/or gearbox
actuator, do not allow any person to walk or stand in front of the vehicle.
WARNING:When the engine is running, it is forbidden to perform
repairs on the clutch and gearbox actuators on the vehicle (whether
manually or using a diagnostic tool).
WARNING:Each time the driver’s door is opened and each time the
igntion is switched on, the gearbox ECU prompts the initialising of the
clutch and gearbox actuators
(there is movement of the clutch fork and
of the gear lever).
WARNING:Whether the ignition is switched on or not, an action on the
gear selector causes the clutch fork and the gear engagement lever to
move on the gearbox.
Engines: HFX KFV NFU 8HX
