2004 Citroen XSARA PICASSO Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 405
AXLES
SUSPENSION
STEERING
FRONT AXLE
Tightening torques m.daN.
(1)Damper nut: 4.5 ± 0.4
(2)Cup screw: 2.5 ± 0.2
(3)Suspension leg(4)Antiroll bar link rod balljoint: 3.7 ± 0.3
(5)Suspension leg swivel: 4.5 ± 0.4
(6) Antiroll bar(7)Antiroll bar link rod balljoint: 3.7 ± 0.3
(8)Lower swivel balljoint: 4 ± 0.4.
(9) Hub nut (greased): 32.5 ± 2
(10)Wheel bolt (face and threads not greased):9 ±1
(11) Lower arm front pivot: 7.6 ± 0.7
(12)Lower arm rear pivot and
antiroll bar bearing:6.8 ±0.6
(13) Screw under rear pivot : 3.5 ± 0.3 Lower arm in forged steel : 3.7 ± 0,3 Lower arm in plate steel: 3.1 ± 0,3Screw fixing subframe on bodyshell:8.5 ±0,8Screw fixing balljoint on lower arm (plate steel):4.5 ± 0,4
Antiroll bar
Engine
All TypesDiameter
21colour reference
WHITE Suspension leg angle :
Tab «a»towards the front.B3CP056P
B3CP057D
B3CP043D
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 406
AXLES
SUSPENSION
STEERING
REAR AXLE
Tightening torques m.daN.
(14)
Front silentblock on subframe: 9.4 ± 0.9
(15)
Antiroll bar bolt: 5.5 ± 0.5
(16)
Rear torsion bar
(17)Antiroll bar
(18)Tubular axle
(19) Front silentblock on bodyshell: 4 ± 0.4
(20)
Rear upper arm.
(21) Wheel bolt (face and threads not lubricated):9 ±1
(22)
Damper
(23)Rear silentblock on subframe:5.4 ± 0.5
(24)
Damper pin nut: 11 ± 1
(25)
Stub axle nuts (lubricated):25 ±2
(26)
Rear silentblock on bodyshell: 6.5 ± 0.6
Antiroll bar
Torsion bar
Engine
All Types19,6 PINK Ø (mm)Colour
referenceØ (mm)
21Colour
reference
ORANGE
B3DP078D
NOTE:The RH torsion bar can be identified by 1 paint line.
The LH torsion bar can be identified by 2 paint lines.
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 407
AXLES
SUSPENSION
STEERING
STEERING COLUMN SPECIFICATIONS
Left hand drive = Greenmarking.
Right hand drive = Whitemarking.
(1) Steering wheel(4)Steering column adjustment
Tightening torques m.daN.
(2)
Airbag to steering wheel fixing: 0.8 ± 0.1
(3)Steering wheel fixing: 3.3 ± 0.6
(5)Steering column to support fixing: 4 ± 0.1
(6) Steering cardan joint fixing:2.3 ± 0.2
B3EP116D
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 408
AXLES
SUSPENSION
STEERING
STEERING COLUMN SPECIFICATIONS
Tightening torques (m.daN).
(7)
Pivot balljoint nut: 4 ± 0.4
(8)
Steering rod adjusting lock nut: 4.5 ± 0.4
(9)
Balljoint on steering rack: 6 ± 0.6
(10)
Fixing steering on subframe: 8 ± 0.8
(11)
Hydraulic pipe connection: 2.4 ± 0.2
(12)
Power steering valve: 1.2 ± 0.2
(13)
Plunger flange screws: 1.2 ± 0.2
(14)
Steering ram screw on housing:9 ±1
(15)
Steering ram screw on yoke:9 ±1
NOTE:
When removing the steering, it is imperative to replace screws
(14)and (15)(new screws).
B3EP117D
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 409
AXLES
SUSPENSION
STEERING
Steering Rack pinion Number of teeth Number of steering Turning circle Turning circle
rack travel in rack wheel turns between walls between kerbs
Left hand drive
71,7 x 2
LH helix28 Teeth 3,22 12 m 11,48 m
Right hand driveRH helix
Engines Steering valve
NFV 6FZ RFN RHY
number of teeth :7
Length of the steering link rods (preadjustment):
Between balljoint centres =
392 mm.
Between the centre of the pivot balljoint and the contact face of the steering rack balljoint =
412 mm.
STEERING COLUMN SPECIFICATIONSXSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 410
AXLES
SUSPENSION
STEERING
POWERASSISTED STEERING SPECIFICATIONS
Tightening torques (m.daN).
Unions between pump unions and
power steering valve: 2 ± 0.3
(16)Fixing screw: 2.2 ± 0.3
(17)Fixing screw: 2.2 ± 0.3
(18)Fixing screw: 2.2 ± 0.3
NOTE:
Coat the threads with product «E3».
A pressure switch is implanted in the hydraulic piping between the
high pressure pump and the power steering valve. Opening pressure =
30 / 35 Bars.
Closing pressure = 25 Bars minimum.
Tightening torque = 2 ± 0.2.
Capacity of power steering circuit =
1 Litre.
Oil quality = TOTAL FLUIDE ATX.
Power steering pump: Supplier SAGINAW.
Pump adjustment = 100 ± 5 Bars.
Pump shaft threading 3/8 16 threads per inch.
B3EP118D
XSARA PICASSO

Downloaded from www.Manualslib.com manuals search engine 411
BRAKES
20,6
203,2
LUCAS.TRW/C 48/13/48
266
13/11
0,05
0,01
TEXTRR/T 4144
13/3
203/205
38
DON/8259/1
BRAKE SPECIFICATIONS (WITHOUT ABS)
Master cylinder
ØMaster vac
mm Caliper/piston makes
Disc Plain
FTDisc thickness/minimum thickness
Maximum runout (mm)
Difference in max. thickness
on same circumference (mm)
Supplier / Brake pad grade
Original thickness/minimum thickness
ØOriginal drum/maximum
RR mm Width
Supplier / grade1.1i1.4 HDi
HFXKFV 8HX
Engine type
C2
1.4i

Downloaded from www.Manualslib.com manuals search engine 412
BRAKESBRAKE SPECIFICATIONS (WITH ABS)
Engine type
Master cylinder
Master vac
ØCaliper/piston makes
FT
mm
DiscPlain
Ventilated
Disc thickness/minimum thickness
Supplier / Brake pad grade
Ø mm Disc Plain
Disc thickness/minimum thickness
RRSupplier / Brake pad grade
ØmmOriginal drum/
maximum/Width
Supplier / Lining grade
(*)
= With emergency braking assistance (AFU).
1.1i
HFX KFV NFU 8HX1.4i1.6i 16V 1.4 HDi
C2
22,2 (*)
228,6
LUCAS.TRW/C 48/13/48LUCAS.TRW LUCAS.TRW/C
C 54/22/54 48/13/48
266
266
13/1122/2013/11
TEXTRR/T 4144
247
9/7
LUCAS.TRW C 38 HR 9/13
203/205/38203/205/38
DON 8259/1 GALFER G 4554 DON 8259/1
