2004 Citroen XSARA PICASSO Workshop Manual

Downloaded from www.Manualslib.com manuals search engine 133
ENGINE
XSARA
AUXILIARY EQUIPMENT DRIVE BELT 2002
Powerassisted steering with air conditioning.
Tools.
[1]
Dynamic tensioner peg: () 0188 H
[2]Belt tension measuring instrument: 4122T
Removal.
Peg the dynamic tensioner (1)at "a", using tool [1].
Loosen the screw (2)of the roller (3).
Turn the roller (3)backwards.
Remove the belt.
NOTE:If it can not be pegged at "a":
Loosen the screw (2)of the roller (3).
Using a 7 mmsquare drive, turn the roller (3)at "b".
Peg the tensioner (1)at "a", using tool [1].
NOTE:If the belt is broken:
Support the engine using a jack (insert a wooden block between the housing and the jack).
Remove the right engine support. Using a square drive at
(b)turn the tool (3)in the direction of the arrow "a", so that it can be
pegged at "a"using the tool [1].
B1BP1SKC
Engine: WJY

Downloaded from www.Manualslib.com manuals search engine 134
ENGINEAUXILIARY EQUIPMENT DRIVE BELT 2002
Powerassisted steering with air conditioning (continued).
Refitting.
Refit the belt.
Using a
7 mm squaredrive at "b", turn the roller (3), until the tool [1]located at "a"becomes
free.
Tighten the screw
(2).
Remove the tool
[1].
B1BP1SLC
Engine: WJY
XSARA

Downloaded from www.Manualslib.com manuals search engine 135
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT
Engines: 8HX 8HW
With compressor and alternator .
B1BP2MKCB1BP2MJD
Tools.
[1]
Pliers for removing plastic pegs: 7504T
[2]Tensioner roller compression lever:().0194.E
[3]Tensioner roller setting peg Ø4 mm: ().0194.F
Removing.
Disconnect the battery negative cable.
Raise and support the vehicle, wheels hanging.
Remove the front RH wheel.
Move aside the splashshield, using tool
[1].
IMPERATIVE: In the case of belt reuse, mark the
direction of rotation of the belt. If the index on the
tensioner roller is outside the marks, change
the auxiliary equipment drive belt.
The alternator (1).
The aircon compressor (2).
Detension the auxiliary belt tensioner roller, using tool [2].
Position the peg [3].
Remove the auxiliary drive belt.
C2 C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 136
ENGINEAUXILIARY EQUIPMENT DRIVE BELT
Engines: 8HX 8HW
Markings on the dynamic tensioner roller.
«a»
Position of «maximum wear» of the auxiliary drive belt.«b»Normal position.
Refitting.
NOTE:
Check that the tensioner roller moves freely (no tight spot). If this is not the
case, replace the tensioner roller.
Respect the direction of fitting of the drive belt.
Complete the setting of the belt, of both sides, by means of the tensioner roller.
Make sure that the drive belt is correctly positioned in the
«V»grooves of the
various pulleys.
Move the tool
[2]on the tensioner roller to remove the peg [3].
B1EP18UD
C2 C3 C3 PLURIEL

Downloaded from www.Manualslib.com manuals search engine 137
ENGINE
XSARA
AUXILIARY EQUIPMENT DRIVE BELT 2002
Tools.
[1]
Dynamic tensioner compression lever: ().0188.Z
[2]Peg for dynamic tensioner roller: ().0194.F
Removing.
IMPERATIVE: Respect the safety and cleanliness requirements specific to high pressure
diesel injection engines (HDi).
Remove:
The front RH wheel.
The underengine sounddeadening.
The splashshield.
WARNING: Mark the direction of fitting of the accessories drive belt, if it is to be reused.
Compress the tensioner roller (1)by acting at «a»(clockwise), using tool [1].
Peg at «b», using tool [2].
Keeping the tensioner roller (1)compressed, remove the accessories drive belt.
IMPERATIVE: Check that the rollers (1) and (2) can turn freely (without play and without
tight spots).B1BP2VZD
Engine: 8HZ

Downloaded from www.Manualslib.com manuals search engine 138
ENGINEXSARA
AUXILIARY EQUIPMENT DRIVE BELT 2002
Refitting.
WARNING:
Belt to be reused, mark the direction of fitting of the belt.
Refit the accessories drive belt.
Compress the tensioner roller
(1)by acting at «a»(clockwise), using tool [1].
Remove tool
[2].
IMPERATIVE: Make sure the belt is correctly positioned in the grooves of the various
pulleys.
Complete the refitting in the opposite order to removal.
Engine: 8HZ
B1BP2VZD

Downloaded from www.Manualslib.com manuals search engine 139
ENGINE
AUXILIARY EQUIPMENT DRIVE BELT
Engines: 8HY 8HV
B1BP2MYDB1BP2MZC
Tools.
[1a]
Dynamic tensioner roller lever: ().0194E1
[1b]Lever extension: ().0194E2
[2]Accessories belt roller locking peg Ø 4 mm: ().0194F
Removing.
Pivot the tensioner roller support (1)(clockwise), using tools [1a]and [1b]at «a».
Remove the belt.
Immobilise the support
(1)of the tensioner roller, using tool [2].
Remove the auxiliary drive belt (2).
IMPERATIVE: Ensure that the tensioner rollers turn freely (no play, no tight spot).
Refitting.
Refit the belt.
Move the tool [1]on the tensioner roller to remove the peg [2].
ESSENTIAL: Make sure that the belt is correctly positioned in the various pulley
grooves.
C3

Downloaded from www.Manualslib.com manuals search engine 140
ENGINE
140
B1BP2Z6DB1BP2ZCD
AUXILIARY EQUIPMENT DRIVE BELT
Engines: 9HZ 9HY
Tools.
[1]
Dynamic tensioner compression lever: ().0188.Z
[2]Peg for dynamic tensioner roller: ().0194.F
Removing.
Remove the front RH wheel, the underengine sounddeadening and the splashshield.
Vehicle with air conditioning.WARNING:Mark the direction of fitting of the accessories drive belt, if it is to be reused.
Compress the tensioner roller (1)by acting at «a»(clockwise), using tool [1].
Peg at «b», using tool [2].
Remove the accessories drive belt.
IMPERATIVE:Check that the rollers (1) and (2) can turn freely (without play and without tight spots).
Refitting.
WARNING:
Belt to be reused, mark the direction of fitting of the belt.
Refit the accessories drive belt.
Compress the tensioner roller
(1)by acting at «a»(clockwise), using tool [1].
Remove tool [2].
IMPERATIVE: Make sure the belt is correctly positioned in the grooves of the various pulleys.
Complete the refitting in the opposite order to removal.
XSARA PICASSO
