2003 LEXUS LS430 park

Use the same procedures for the parking brake cable assy No.2 and No.3.
The procedures listed below are for the parking brake cable assy No.3.
1.REMOVE REAR WHEEL
2.SEPARATE REAR DISC BRAKE CALIPER ASSY LH
a. Remove the 2 bolts and separate the rear disc brake caliper assy LH.
HINT:
Do not disconnect the flexible hose from the rear disc brake caliper assy LH.
Do not twist or bend the rear brake caliper assy LH.
b. Hang the rear brake caliper assy LH with a piece of wire.
Fig. 175: Removing Bolts And Separate Rear Disc Brake Caliper Assy LH

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
3.REMOVE REAR DISC
a. Place matchmarks on the disc and rear axle hub.

b. Remove the disc.
HINT:
If the disc cannot be removed easily, turn the shoe adjuster until the wheel turns smoothly.
Fig. 176: Identifying Matchmarks On Disc And Rear Axle Hub

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
4.REMOVE PARKING BRAKE SHOE RETURN TENSION SPRING
a. Using SST, remove the brake shoe return tension spring.
SST 09703-30010

<0029004c004a001100030014001a001a001d000300350048005000520059004c0051004a0003002500550044004e004800030036004b00520048000300350048005700580055005100030037004800510056004c005200510003003600530055004c005100
4a[
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
5.REMOVE PARKING BRAKE SHOE ASSY LH NO.1
a. Using SST, remove the cap, shoe hold-down spring and pin.
SST 09718-00010
b. Disconnect the tension spring from the parking brake shoe assy LH No.1.
c. Remove the parkin
g brake shoe assy LH No.1 and shoe adjuster.

Fig. 178: Removing Cap, Shoe Hold-Down Spring And Pin
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
6.REMOVE PARKING BRAKE SHOE ASSY LH NO.2
a. Remove the tension spring from the lower shoe.
b. Using SST, remove the cap, shoe hold-down spring and pin.
SST 09718-00010
c. Remove the parking brake shoe assy LH No.2.

Fig. 179: Removing Cap, Shoe Hold-Down Spring And Pin
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
7.REMOVE PARKING BRAKE SHOE LEVER SUB-ASSY LH
a. Disconnect the parking brake cable assy No.3 from the parking brake shoe lever.

Fig. 180: Disconnecting Parking Brake Cable Assy No.3 From Parking Brake Shoe Lever
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
8.REMOVE OXYGEN SENSOR (SEE REPLACEMENT
)
9.REMOVE EXHAUST PIPE ASSY (SEE REPLACEMENT
)
10.REMOVE FRONT FLOOR HEAT INSULATOR NO.1 (SEE REPLACEMENT
)
11.REMOVE PARKING BRAKE CABLE ASSY NO.3
a. Remove the 2 nuts and parking brake cable assy No.3 from the rear axle carrier.

Fig. 181: Removing Nuts And Parking Brake Cable Assy No.3 From Rear Axle Carrier
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
b. Remove the 3 bolts and separate the parking brake cable assy No.3.
c. Remove the parking brake cable No.3 from the parking brake intermediate lever sub-assy.
d. Remove the 2 bolts and parking brake cable No.1 clamp from the body.
e. Remove the parking brake cable No.2 clamp and No.3 clamp from the parking brake cable assy
No.3.
f. Remove the parkin
g brake cable No.5 clamp and anchor block.

Fig. 182: Removing Bolts And Parking Brake Cable No.1 Clamp From Body
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
12.INSTALL PARKING BRAKE CABLE ASSY NO.3
a. Install the parking brake cable No.5 clamp and anchor block.
b. Install the parking brake cable No.2 clamp and No.3 clamp to the parking brake cable assy No.3.
c. Place the parking brake cable No.1 clamp to the body and tighten the 2 bolts.
Torque: 6 N.m (61 kgf.cm, 53 in.lbf)
d. Attach the parking brake cable assy No.3 to the parking brake intermediate lever sub-assy.
e. Attach the parking brake cable assy No.3 to the 2 clamps and tighten bolts A, B and C.
Torque:
Bolt A: 6 N.m (61 kgf.cm, 53 in.lbf)
Bolt B, C: 19 N.m (194 kgf.cm, 14 ft.lbf)
f. Install parking brake cable assy No.3 to the rear axle carrier with the 2 nuts.
Torque: 8 N.m (81 kgf.cm, 70 in.lbf)
