2002 CHEVROLET TRAIL BLAZER Owners Manual

3-21
2 NEXT: Press this button to go to the next selection on
the tape. If you press the button more than once, the
player will continue moving forward through the tape.
SEEK and a positive number will appear on the display.
Your tape must have at least three seconds of silence
between each selection for 2 NEXT to work. To forward
through each selection press the right SEEK PSCAN
arrow. The sound will mute while seeking.
3 REV: Press this button to reverse the tape rapidly.
Press it again to return to playing speed. The radio will
play the last selected station while the tape reverses. The
station frequency and 3 REV will appear on the display.
You may select stations during reverse operation by
using TUNE DISP and the SEEK PSCAN arrows.
4 FWD: Press this button to advance quickly to another
part of the tape. Press the button again to return to
playing speed. The radio will play the last selected
station while the tape advances. The station frequency
and 4 FWD will appear on the display. You may select
stations during forward operation by using TUNE DISP
and the SEEK PSCAN arrows.5 SIDE: Press this button to play the other side of
the tape.
6
RDM: Press this button to reduce background
noise. NR ON will appear on the display. Press it again
to turn Dolby off. NR OFF will appear on the display.
Dolby Noise Reduction is manufactured under a license
from Dolby Laboratories Licensing Corporation. Dolby
and the double
-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
 SEEK PSCAN
: SEEK PSCAN and a right
pointing arrow is the same as 2 NEXT, and a left
pointing arrow and SEEK PSCAN is the same as
1 PREV. If the button is held or pressed more than once,
the player will continue moving forward or backward
through the tape. SEEK and a positive or negative
number will appear on the display.
AM FM: Press this button to play the radio when
a tape is in the player. The tape will stop but remain in
the player.

3-22
TAPE AUX: With a cassette tape in the player and the
radio playing, press this button to play a cassette tape.
Press AM FM to return to the radio when a cassette tape
is playing. The inactive tape will remain safely inside
the radio for future listening.
EJT: Press this button to remove a tape. The radio
will play. Eject may be activated with the radio off.
Cassette tapes may be loaded with the radio off if this
button is pressed first.
Tight/Loose Tape Sensor Defeat
With the radio off and the ignition on, press and hold the
TAPE AUX button to disable the tight/loose tape
sensing feature to enable play of some tape head
cleaners and portable CD adapters. The radio will
display READY and flash the cassette icon. The
tight/loose tape sensing feature will then be disabled
until the next time a cassette is ejected.CD Adapter Kits
It is possible to use a portable CD player adapter kit
with your cassette tape player after activating the bypass
feature on your tape player.
To activate the bypass feature, use the following steps:
1. Turn the radio off.
2. Press and hold the TAPE AUX button for
five seconds. READY will appear on the display
for five seconds, indicating the feature is active.
3. Insert the adapter into the cassette slot. It will power
up the radio and begin playing.
This override routine will remain active until EJT
is pressed.

3-23
Radio/Cassette Tape Messages
(CAL ERR): This message is displayed when the radio
has not been calibrated properly for the vehicle. You
must return to the dealership for service.
(LOCKED): This message is displayed when the
THEFTLOCK
 system has locked up. You must return
to the dealership for service.
(CHK TAPE): If CHK TAPE appears on the radio
display, the tape won't play because of one of the
following errors.

The tape is tight and the player can't turn the tape
hubs. Remove the tape. Hold the tape with the open
end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.

The tape is broken. Try a new tape.

The tape is wrapped around the tape head. Attempt
to get the cassette out. Try a new tape.(CLEAN): If this message appears on the display, the
cassette tape player needs to be cleaned. It will still play
tapes, but you should clean it as soon as possible to
prevent damage to the tapes and player. See ªCare of
Your Cassette Tape Playerº in the Index. After you clean
the player, press and hold the EJT button for five
seconds to reset the CLEAN indicator. The radio will
display CLEANED to show the indicator was reset.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer.

3-24 AM-FM Stereo with Compact Disc Player
with Radio Data System (RDS) and
Automatic Tone Control (If Equipped)
Playing the Radio
VOL PWR: Press this control to turn the system on and
off. Turn this control clockwise to increase volume.
Turn it counterclockwise to decrease volume.AUTO VOL: Your system has a feature called
Speed
-Compensated Volume (SCV). With SCV, your
audio system adjusts automatically to make up for road
and wind noise as you drive.
Set the volume at the desired level. Press AUTO VOL to
adjust the SCV. AVOL will appear on the display. Each
time you press AUTO VOL, another volume setting
(LOW, MEDIUM, HIGH or OFF) will appear on the
display. The volume level should always sound the same
to you as you drive. Each volume setting allows for
more volume compensation at faster vehicle speeds.
NONE will appear on the display if the radio cannot
determine the vehicle speed. If you don't want to use
SCV, select OFF.
Finding a Station
AM FM: Press this button to switch between AM, FM1
and FM2. The display shows your selection.
TUNE DISP: Turn this control to choose radio stations.
Pressing this control will also display an RDS station
frequency or program type when the radio is on.
Pressing this control when the ignition is off will display
the clock.

3-25
 SEEK PSCAN
: To seek, press the right arrow to
tune to the next station and the left arrow to tune to the
previous station and stay there.
To scan your preset stations, press and hold one of
the arrows for more than two seconds. The radio will
produce one beep. Use preset scan to listen to each of
your favorite stations stored on your pushbuttons for
a few seconds. The radio will scan through each of the
stations stored on your pushbuttons, except those
stations with weak reception. Press one of the arrows or
one of the pushbuttons again to stop scanning. SCAN
will be displayed whenever the tuner is in the preset
scan mode. The channel number (P1 through P6) will
appear with the frequency. In FM mode, this function
will scan through the current band such as FM1 or FM2.Setting Preset Stations
The six numbered pushbuttons let you return to
your favorite stations. You can set up to 18 stations
(six AM, six FM1 and six FM2) by performing the
following steps:
1. Turn the radio on.
2. Press AM FM to select the band.
3. Tune in the desired station.
4. Press AUTO TONE to choose the bass and treble
equalization that best suits the type of station you are
listening to.
5. Press and hold one of the six numbered pushbuttons.
The radio will produce one beep. Whenever you
press that numbered pushbutton, the station you set
will return and the bass and treble equalization that
you selected will also be automatically selected for
that pushbutton.
6. Repeat the steps for each pushbutton.

3-26
Setting the Tone (Bass/Treble)
P
-TYPE LIST AUDIO: To adjust the bass, press and
release the P
-TYPE LIST AUDIO control until BASS
appears on the display. Then turn the control clockwise
to increase bass and counterclockwise to decrease bass.
The display will show the bass level.
To set the bass to the middle position, press and hold the
P
-TYPE LIST AUDIO control. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
To adjust the treble, press and release the P
-TYPE LIST
AUDIO control until TREB appears on the display.
Turn the control clockwise to increase treble and
counterclockwise to decrease treble. The display will
show the treble level. If a station is weak or noisy, you
may want to decrease the treble.To set treble to the middle position, press and hold
P
-TYPE LIST AUDIO control. The radio will produce
one beep and set the display level to the middle position.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
When you use this control, the radio's AUTO TONE
setting will return to manual.
AUTO TONE: This feature allows you to choose preset
bass and treble equalization settings designed for rock,
news, pop, jazz, classical and country stations.
Each time you press the AUTO TONE button, this
feature will change to one of the preset equalization
settings previously listed.
To return the bass and treble to the manual mode, press
and release the P
-TYPE LIST AUDIO control. See
ªSetting Preset Stationsº listed previously to program
the auto tone feature.

3-27
Adjusting the Speakers (Balance/Fade)
To adjust the balance, press and release the P
-TYPE
LIST AUDIO control until BAL appears on the display.
Turn the control clockwise to move the sound to the
right speakers and counterclockwise to move the sound
to the left speakers.
The middle position balances the sound between the
speakers. To set the balance to the middle position, press
the P
-TYPE LIST AUDIO control briefly, then press it
again and hold it until the radio emits one beep. The
balance will be set to the middle position and the display
will show the speaker balance.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
To adjust the fade, press and release the P
-TYPE LIST
AUDIO control until FADE appears on the display. Turn
the control clockwise to move the sound to the front
speakers and counterclockwise to move the sound to the
rear speakers.The middle position balances the sound between the
speakers. To set the fade to the middle position, press
the P
-TYPE LIST AUDIO control briefly, then press
it again and hold it until the radio emits one beep. The
fade will be set to the middle position and the display
will show the speaker balance.
To set all tone and speaker controls to the middle
position, press and hold the P
-TYPE LIST AUDIO
control when no tone or speaker control is active. The
radio will produce one beep and display ALL with the
level display in the middle position.
Using RDS
Your audio system is equipped with a Radio Data
System (RDS). RDS is a system that sends data along
with the audio of the FM station you are currently tuned
to. You can use RDS to display program information
and to control your radio. With RDS your radio can do
the following:

Seek only to stations with the types of programs you
want to listen to,

seek to stations with traffic announcements,

receive announcements concerning local and
national emergencies, and

receive and display messages from radio stations.

3-28
RDS features are only available on FM stations which
broadcast RDS information. The RDS features of your
radio rely on receiving specific RDS information from
these stations. These features will only work when the
RDS information is available. In rare cases, a radio
station may broadcast incorrect information that will
cause the radio features to work improperly. If this
happens, please contact the radio station.
When you are tuned to an RDS station, the station name
will appear on the display, instead of the frequency.
Most RDS stations provide their station name, the time
of day and a Program Type (PTY) for their current
programming. Some stations also provide the name of
the current program.
TUNE DISP: Press this control to change what appears
on the display while using RDS. Pressing this control
will also display an RDS station frequency or program
type when the radio is on. The display options are
station name, station frequency, PTY and the name of
the program (if available). Pressing and holding this
control will activate the RDS default display.Accessing RDS
To access RDS stations perform the following steps:
1. Push the SEEK TYPE button or turn the P
-TYPE
LIST AUDIO control to display the program
type list.
2. Turn the control either clockwise or
counterclockwise to select a program type. The list
is alphabetical. If you select ANY TYPE your radio
will seek to the first PTY available.
3. Push the SEEK TYPE button to activate search.
VOL PWR: Turn this control clockwise to increase
volume when RDS interrupts regular play. Turn it
counterclockwise to decrease volume.
P
-TYPE LIST AUDIO: Turn this control clockwise
or counterclockwise to select the Program Type (PTY)
you want to listen to. TYPE and a PTY will appear on
the display. Press the SEEK TYPE button and the radio
will seek to the first RDS broadcaster of the selected
program type. If the radio cannot find the desired
program type, NONE will appear on the display and the
radio will return to the last station you were listening to.
