2002 CHEVROLET TRAIL BLAZER Owners Manual

2-92
The DIC does not replace the need to maintain your
vehicle as recommended in the Maintenance Schedule
in this manual. Also, the oil change reminder will not
detect dusty conditions or engine malfunctions that may
affect the oil. If you drive in dusty areas, change your
oil after every 3,000 miles (5 000 km) or three months,
whichever occurs first, unless the DIC instructs you to
do so sooner. Also, the oil change reminder does not
measure how much oil you have in your engine. So, be
sure to check your oil level often. See ªEngine Oilº in
the Index.
Personalization Button
You can program certain features to a preferred setting
for up to two people. Press the personalization button to
scroll through the following personalization features. All
of the personalization options may not be available on
your vehicle. Only the options available will be
displayed on your DIC.

ALARM WARNING TYPE

AUTOMATIC LOCKING

AUTOMATIC UNLOCKING
SEAT POSITION RECALL (If Equipped)

PERIMETER LIGHTING

REMOTE LOCK FEEDBACK

REMOTE UNLOCK FEEDBACK

HEADLAMPS ON AT EXIT

TILT MIRROR IN REVERSE (If Equipped)

EASY EXIT SEAT (If Equipped)

DISPLAY UNITS (E/M)

DISPLAY LANGUAGE
The driver's preferences are recalled by pressing the
unlock button on the remote keyless entry transmitter
or by pressing the appropriate memory button 1 or 2
located on the driver's door.

2-93
Alarm Warning Type
Press the personalization button until ALARM
WARNING TYPE appears in the display. To select your
personalization for alarm warning type, press the select
button while ALARM WARNING TYPE is displayed
on the DIC. Pressing the select button will scroll
through the following choices:

ALARM WARNING: BOTH (default)

ALARM WARNING: OFF

ALARM WARNING: HORN

ALARM WARNING: LAMPS
If you choose BOTH, the headlamps will flash and the
horn will chirp when the alarm is active.
If you choose OFF, there will be no alarm warning
on activation.
If you choose HORN, the horn will chirp when the
alarm is active.
If you choose LAMPS, the headlamps will flash when
the alarm is active.
Choose one of the four options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature. For more
information on alarm warning type see ªContent
Theft
-Deterrentº in the Index.Automatic Locking
Press the personalization button until AUTOMATIC
LOCKING appears in the display. To select your
personalization for automatic locking, press the select
button while AUTOMATIC LOCKING is displayed on
the DIC. Pressing the select button will scroll through
the following choices:

LOCK DOORS OUT OF PARK (default)

LOCK DOORS MANUALLY

LOCK DOORS WITH SPEED
If you choose for the doors to lock out of park, the doors
will lock when the vehicle is shifted out of PARK (P).
If you choose for the doors to lock manually, the doors
will not be locked automatically.
If you choose for the doors to lock with speed,
the doors will lock when the vehicle speed is
above 8 mph (13 km/h) for three seconds.
Choose one of the three options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature. For more
information on automatic door locks see ªProgrammable
Automatic Door Locksº in the Index.

2-94
Automatic Unlocking
Press the personalization button until AUTOMATIC
UNLOCKING appears in the display. To select your
personalization for automatic unlocking, press the select
button while AUTOMATIC UNLOCKING is displayed
on the DIC. Pressing the select button will scroll
through the following choices:

UNLOCK ALL IN PARK (default)

UNLOCK ALL AT KEY OUT

UNLOCK DOORS MANUALLY

UNLOCK DRIVER IN PARK
If you choose for all the doors to unlock in park,
all of the doors will unlock when the vehicle is shifted
into PARK (P).
If you choose for all the doors to unlock at key out,
all of the doors will unlock when the key is taken out
of the ignition.
If you choose for the doors to unlock manually, the
doors will not be unlocked automatically.
If you choose for the driver's door to unlock in park, the
driver's door will be unlocked when the vehicle is
shifted into PARK (P).Choose one of the four options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature. For more
information on automatic door locks see ªProgrammable
Automatic Door Locksº in the Index.
Seat Position Recall (If Equipped)
Press the personalization button until SEAT POSITION
RECALL appears in the display. To select your
personalization for seat position recall, press the select
button while SEAT POSITION RECALL is displayed
on the DIC. Pressing the select button will scroll
through the following choices:

SEAT POSITION RECALL OFF (default)

SEAT POSITION RECALL AT KEY IN

SEAT POSITION RECALL ON REMOTE
If you choose seat recall off, the memory seat position
you saved will not be recalled.
If you choose seat recall at key in, the memory seat
position you saved will be recalled when you put the key
in the ignition.
If you choose seat recall on remote, the memory seat
position you saved will be recalled when you unlock the
vehicle with the remote keyless entry transmitter.

2-95
Choose one of the three options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature. For more
information on seat position recall see ªMemory Seat
and Mirrorsº in the Index.
Perimeter Lighting
Press the personalization button until PERIMETER
LIGHTING appears in the display. To select your
personalization for perimeter lighting, press the select
button while PERIMETER LIGHTING is displayed on
the DIC. Pressing the select button will scroll through
the following choices:

PERIMETER LIGHTING ON (default)

PERIMETER LIGHTING OFF
If you choose for perimeter lighting to be on, the
headlamps and back
-up lamps will come on for
40 seconds, if it is dark enough outside, when you
unlock the vehicle with the remote keyless entry
transmitter.
Choose one of the two options and press the
personalization button while it is displayed on the
DIC to select it and move on to the next feature.Remote Lock Feedback
Press the personalization button until REMOTE LOCK
FEEDBACK appears in the display. To select your
personalization for the feedback you will receive when
locking the vehicle with the remote keyless entry
transmitter, press the select button while REMOTE
LOCK FEEDBACK is displayed on the DIC.
Pressing the select button will scroll through the
following choices:

LOCK FEEDBACK: BOTH (default)

LOCK FEEDBACK: OFF

LOCK FEEDBACK: HORN

LOCK FEEDBACK: LAMPS
If you choose both, the parking lamps will flash each
time you press the button with the lock symbol on the
remote keyless entry transmitter and the horn will chirp
the second time you press the lock button.
If you choose off, there will be no feedback when
locking the vehicle.
If you choose horn, the horn will chirp the second time
you press the button with the lock symbol on the remote
keyless entry transmitter.

2-96
If you choose lamps, the parking lamps will flash each
time you press the button with the lock symbol on the
remote keyless entry transmitter.
Choose one of the four options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature.
Remote Unlock Feedback
Press the personalization button until REMOTE
UNLOCK FEEDBACK appears in the display. To select
your personalization for the feedback you will receive
when unlocking the vehicle with the remote keyless
entry transmitter, press the select button while
REMOTE UNLOCK FEEDBACK is displayed on the
DIC. Pressing the select button will scroll through the
following choices:

UNLOCK FEEDBACK: LAMPS (default)

UNLOCK FEEDBACK: BOTH

UNLOCK FEEDBACK: OFF

UNLOCK FEEDBACK: HORNIf you choose lamps, the parking lamps will flash each
time you press the button with the unlock symbol on the
remote keyless entry transmitter.
If you choose both, the parking lamps will flash each
time you press the button with the unlock symbol on the
remote keyless entry transmitter and the horn will chirp
the second time you press the unlock button.
If you choose off, there will be no feedback when
unlocking the vehicle.
If you choose horn, the horn will chirp the second time
you press the button with the unlock symbol on the
remote keyless entry transmitter.
Choose one of the four options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature.

2-97
Headlamps on at Exit
Press the personalization button until HEADLAMPS
ON AT EXIT appears in the display. To select your
personalization for how long the headlamps will stay on
when you turn off the vehicle, press the select button
while HEADLAMPS ON AT EXIT is displayed on the
DIC. Pressing the select button will scroll through the
following choices:

HEADLAMP DELAY: 10 SEC (default)

HEADLAMP DELAY: 20 SEC

HEADLAMP DELAY: 40 SEC

HEADLAMP DELAY: 60 SEC

HEADLAMP DELAY: 120 SEC

HEADLAMP DELAY: 180 SEC

HEADLAMP DELAY OFF
The amount of time you choose will be the amount of
time that the headlamps stay on after you turn off the
vehicle. If you choose off, the headlamps will turn off
as soon as you turn off the vehicle.
Choose one of the seven options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature.Tilt Mirror in Reverse (If Equipped)
Press the personalization button until TILT MIRROR IN
REVERSE appears in the display. To select your
personalization for tilt mirror in reverse, press the select
button while TILT MIRROR IN REVERSE is displayed
on the DIC. Pressing the select button will scroll
through the following choices:

TILT MIRROR: OFF (default)

TILT MIRROR: PASSENGER

TILT MIRROR: DRIVER

TILT MIRROR: BOTH
If you choose off, neither outside mirror will be tilted
down when the vehicle is shifted into REVERSE (R).
If you choose passenger, the passenger's outside
mirror will be tilted down when the vehicle is shifted
into REVERSE (R).
If you choose driver, the driver's outside mirror
will be tilted down when the vehicle is shifted
into REVERSE (R).
If you choose both, the driver's and passenger's
outside mirror will be tilted down when the vehicle is
shifted into REVERSE (R).

2-98
Choose one of the four options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature. For more
information on tilt mirror in reverse see ªCurb View
Assist Mirrorº in the Index.
Easy Exit Seat (If Equipped)
Press the personalization button until EASY EXIT
SEAT appears in the display. To select your
personalization for seat position exit, press the select
button while SEAT POSITION EXIT is displayed on the
DIC. Pressing the select button will scroll through the
following choices:

SEAT POSITION EXIT OFF (default)

SEAT POSITION EXIT ON
If you choose for the easy exit seat feature to be on, the
driver's seat will move all of the way rearward when the
vehicle is turned off. If you choose for this feature to be
off, no seat exit recall will occur.
Choose one of the two options and press the
personalization button while it is displayed on the DIC
to select it and move on to the next feature. For more
information on seat position exit see ªMemory Seat and
Mirrorsº in the Index.Display Units (ENG/MET)
Press the personalization button until DISPLAY UNITS
appears in the display. To select English or metric, press
the select button while DISPLAY UNITS is displayed
on the DIC. Pressing the select button will scroll
through the following choices:

UNITS: ENGLISH

UNITS: METRIC KM/L

UNITS: METRIC L/100KM
If you choose English, all information will be displayed
in English units. For example, distance in miles and fuel
economy in miles per gallon.
If you choose metric KM/L, all information will be
displayed in metric units. For example, distance in
kilometers and fuel economy in KM/L.
If you choose metric L/100KM, all information will be
displayed in metric units. For example, distance in
kilometers and fuel economy in L/100KM.
Choose one of the three options and press the
personalization button while it is displayed on the DIC
to select it and end out of the personalization options.

2-99
Display Language
To select your personalization for display language,
press the select button while DISPLAY LANGUAGE is
displayed on the DIC. Pressing the select button will
scroll through the following languages:

English

French

Spanish

German

Arabic

Portuguese

Japanese

Italian
Arabic, Portuguese, Japanese and Italian will only be
available as choices if they are enabled in the vehicle.
Choosing any of the above languages will display all of
the information on the DIC in the desired language.If you accidentally choose a language that you don't
want or understand, press and hold the personalization
button and the trip information button and the same
time. The DIC will begin scrolling through the
languages in their particular language. English will be in
English, French will be in French and so on. When you
see the language that you would like, release both
buttons. The DIC will then display the information in
the language you chose.
Choose one of the eight options and press the
personalization button while it is displayed on the
DIC to select it.
Select Button
The select button is used to reset certain functions and
turn off or acknowledge messages on the DIC display.
The select button also toggles through the options
available in each personalization menu. For example,
this button will reset the trip odometers, turn off the
FUEL LEVEL LOW message, and toggle through
the languages you can select the DIC to display
information in.
