2002 CHEVROLET TRAIL BLAZER Owners Manual

2-84
Change Engine Oil Light
United States Canada
This light is displayed when the engine oil needs to
be changed.
Once the engine oil has been changed, the CHANGE
ENG OIL light must be reset. Until it is reset, the light
will be displayed when the engine is on. For more
information on resetting the system, see ªOil Life
Systemº in the Index.
Security Light
United States Canada
This light will come on briefly when you turn the
key toward START. The light will stay on until the
engine starts.
If the light flashes, the Passlock

system has entered a
tamper mode. If the vehicle fails to start, see ªPasslockº
in the Index.
If the light comes on continuously while driving and
stays on, there may be a problem with the Passlock
system. Your vehicle will not be protected by Passlock,
and you should see your dealer.
Also, see ªContent Theft
-Deterrentº in the Index for
additional information regarding the SECURITY light.

2-85
Cruise Control Light (If Equipped)
United States Canada
The CRUISE light appears whenever you set your cruise
control. See ªCruise Controlº in the Index.
Reduced Engine Power
United States Canada
This light is displayed when a noticeable reduction in
the vehicle's performance may occur. The vehicle may
be driven at a reduced speed when the reduced engine
power light is on but acceleration and speed may be
reduced. The performance may be reduced until the next
time you drive your vehicle. If this light stays on, see
your dealer as soon as possible for diagnosis and repair.
This light may also come on if there is a problem
with the Electronic Throttle Control (ETC) system.
If this happens, take the vehicle in for service as soon
as possible.

2-86
Service Four-Wheel-Drive Warning Light
(If Equipped)
United States Canada
This light should come on briefly when you turn on the
ignition, as a check to show you it is working.
The SERVICE 4WD light comes on to indicate that
there may be a problem with the drive system and
service is required. Malfunctions can be indicated by
the system before any problem is apparent, which may
prevent serious damage to the vehicle. This system is
also designed to assist your service technician in
correctly diagnosing a malfunction.
Check Gages Light
United States Canada
The CHECK GAGES light will come on briefly when
you are starting the engine.
If the light comes on and stays on while you are driving,
check your coolant temperature and engine oil pressure
gages to see if they are in the warning zones.

2-87
Gate Ajar
United States Canada
If this light comes on, your liftgate or liftglass is ajar.
Try closing the liftgate or liftglass again. Never drive
with the liftgate or liftglass even partially open.
Fuel Gage
United States Canada
When the ignition is on, the fuel gage tells you about
how much fuel you have remaining.

2-88
Here are four things that some owners ask about. None
of these show a problem with your fuel gage:

At the gas station, the gas pump shuts off before the
gage reads full.

It takes a little more or less fuel to fill up than the
gage indicated. For example, the gage may have
indicated the tank was half full, but it actually took a
little more or less than half the tank's capacity to fill
the tank.

The gage moves a little when you turn a corner or
speed up.

The gage doesn't go back to empty when you turn
off the ignition.Low Fuel Light
United States Canada
The light next to the fuel gage will come on briefly
when you are starting the engine.
This light comes on when the fuel tank is low on fuel.
To turn it off, add fuel to the fuel tank. See ªFuelº in
the Index.

2-89
Driver Information Center (DIC)
(If Equipped)
The DIC display is located on the instrument panel
cluster above the steering wheel. The DIC can display
information such as the trip odometer, fuel economy and
personalization features.
A.Trip Information: This button will display the
odometer, trip odometer and the timer.
B.Fuel Information: This button will display the
current range, average fuel economy, instant fuel
economy and engine oil life.
C.Personalization: This button will change personal
options available on your vehicle.
D.Select: This button resets certain functions and turns
off or acknowledges messages on the DIC.
DIC Operation and Displays
The DIC comes on when the ignition is on. After a short
delay the DIC will display the current driver and the
information that was last displayed before the engine
was turned off.
If a problem is detected, a warning message will appear
on the display. Pressing the select button will
acknowledge any current warning or service messages.
The DIC has different modes which can be accessed
by pressing the four buttons on the DIC. These buttons
are trip information, fuel information, personalization
and select. The button functions are detailed in
the following.
Trip Information Button
Use the trip information button to scroll through the
odometer, TRIP A, TRIP B and TIMER.

2-90
Odometer
Press the trip information button until the odometer
appears on the display. This shows the total distance the
vehicle has been driven in either miles or kilometers.
Pressing the reset stem located on the instrument cluster
with the vehicle off will also display the odometer.
Trip A and Trip B
Press the trip information button until TRIP A or TRIP B
is displayed. This shows the current distance traveled
since the last reset for each trip odometer in either miles
or kilometers. Both odometers can be used at the
same time.
Each trip odometer can be reset to zero separately by
pressing select while the desired trip odometer is
displayed. You can also reset the trip odometers with the
reset stem on the cluster. If you press and hold the reset
stem for four seconds, the display will show the distance
traveled since the last ignition cycle.Timer
The DIC can be used as a stopwatch. Press the select
button while TIMER is displayed to start the timer. The
display will show the amount of time that has passed
since the timer was last reset (not including time the
ignition is off). Time will continue to be counted as long
as the ignition is on, even if another display is being
shown on the DIC. The timer will record up to 99 hours,
59 minutes and 59 seconds (99:59:59) after which the
display will roll back to zero.
To stop the counting of time, press the select button
briefly while TIMER is displayed.
To reset the timer to zero, press and hold the select
button while TIMER is displayed.
Fuel Information Button
Use the fuel information button to scroll through the
range, average fuel economy, instant fuel economy and
the GM Oil Life System
.

2-91
Fuel Range
Press the fuel information button until RANGE appears
to display the remaining distance you can drive without
refueling. It's based on fuel economy and the fuel
remaining in the tank. The display will show LOW if
the fuel level is low.
The fuel economy data used to determine fuel range is
an average of recent driving conditions. As your driving
conditions change, this data is gradually updated. Fuel
range cannot be reset.
Average Fuel Economy
Press the fuel information button until AVG appears in
the display. Average fuel economy is how many miles
per gallon your vehicle is getting based on current and
past driving conditions.
Press and hold the select button while AVG. ECON is
displayed to reset the average fuel economy. Average
fuel economy will then be calculated starting from that
point. If the average fuel economy is not reset, it will be
continually updated each time you drive.Instant Fuel Economy
Press the fuel information button until INST appears
in the display. Instant fuel economy is how many miles
per gallon your vehicle is at the particular moment in
time. The instant fuel economy cannot be reset.
GM Oil Life System

Press the fuel information button until ENGINE OIL
LIFE appears in the display. The GM Oil Life System

shows an estimate of the oil's remaining useful life. It
will show 100% when the system is reset after an oil
change. It will alert you to change your oil on a schedule
consistent with your driving conditions.
Always reset the engine oil life after an oil change.
To reset the Oil Life System press and hold the select
button while ENGINE OIL LIFE is displayed. Be
careful not to reset the engine oil life accidentally at
any time other than when the oil has just been changed.
It can't be reset accurately until the next oil change.
