2001 TOYOTA AVALON check engine

Z05730
BatteryIgnition
SwitchWarning Light
21
54 3
Z14203
Engine Coolant Temperature Gauge
Ignition
Switch
BatterySender
Gauge
Z15788
Engine Coolant Temperature Gauge
Ignition
Switch
BatteryTest Bulb
(3.4 W)
Wire Harness Side
1
I13322
A
DC
B BE-58
- BODY ELECTRICALCOMBINATION METER
1662 Author
: Date
:
2001 AVALON (RM808U)
12. INSPECT FUEL LEVEL WARNING LIGHT
(a) Disconnect the connector from the sender gauge.
(b) Connect terminals 1 and 3 on the wire harness side con-
nector.
(c) Turn the ignition switch ON, check that the warning light
lights up.
If the warning light does not light up, test the bulb or inspect wire
harness.
13. INSPECT ENGINE COOLANT TEMPERATURE RE-
CEIVER GAUGE OPERATION
(a) Disconnect the connector from the sender gauge.
(b) Turn the ignition switch ON, check that the receiver gauge
needle indicates COOL.
(c) Ground terminal on the wire harness side connector
through a 3.4 W test bulb.
(d) Turn the ignition switch ON, check that the bulb lights up
and the receiver gauge needle moves toward the hot
side.
If operation is as specified, replace the sender gauge.
Then recheck the system.
If operation is not as specified, measure the receiver gauge re-
sistance.
14. INSPECT ENGINE COOLANT TEMPERATURE RE-
CEIVER GAUGE RESISTANCE
Measure the resistance between terminals with fixing pointer to
the stopper.
Tester connectionResistance (W)
A - B250
C - D250
If resistance value is not as specified, replace the receiver
gauge.

I07709
35.63 ± 0.1 W
Slide
rheostat
35.63 ±
0.1 W
Z15789
Warning Light
Ignition
Switch
BatteryWire Harness
N06640
BE1217
Warning Light
Ignition
Switch
Battery
- BODY ELECTRICALCOMBINATION METER
BE-59
1663 Author
: Date
:
2001 AVALON (RM808U)
15. INSPECT ENGINE COOLANT TEMPERATURE SEND-
ER GAUGE RESISTANCE
Connect the wire harness as shown in the illustration, and ad-
just the ammeter pointer to indicate º0º using the slide rheostat,
then read the rheostat indication.
Temperature °C (°F)Resistance (W)
50 (122.0)160 - 240
120 (248.0)17.1 - 21.2
If resistance value is not as specified, replace the engine cool-
ant sender gauge.
16. INSPECT LOW OIL PRESSURE WARNING LIGHT
(a) Disconnect the connector from the warning switch and
ground terminal on the wire harness side connector.
(b) Turn the ignition switch ON, check that the warning light
lights up.
If the warning light does not light up, test the bulb or inspect wire
harness.
17. INSPECT LOW OIL PRESSURE WARNING SWITCH
OPERATION
(a) Check that continuity exists between the terminal and
ground with the engine stopped.
(b) Check that no continuity exists between the terminal and
ground with the engine running.
HINT:
Oil pressure should be over 29 kPa (0.35 kgf/cm
2, 4.3 psi)
If operation is not as specified, replace the switch.
18. INSPECT BRAKE WARNING LIGHT
(a) Disconnect the connector from the brake fluid warning
switch.
(b) Release the parking brake pedal.
(c) Connect the terminals on the wire harness side of the lev-
el warning switch connector.
(d) Start the engine, check that the warning light lights up.
If the warning light does not light up, test the bulb or wire har-
ness.

N02346
ON OFF
1 2
Z11183
1
Z15790
Warning Light
Ignition
Switch
BatteryWire Harness Side
123 45
6789101112
BE-60
- BODY ELECTRICALCOMBINATION METER
1664 Author
: Date
:
2001 AVALON (RM808U)
19. INSPECT BRAKE FLUID LEVEL WARNING SWITCH
OPERATION
(a) Remove the reservoir tank cap and strainer.
(b) Disconnect the connector.
(c) Check that no continuity exists between the terminals with
the switch OFF (float up).
(d) Use a siphon, etc. to take fluid out of the reservoir tank.
(e) Check that continuity exists between the terminals with
the switch ON (float down).
(f) Pour the fluid back in the reservoir tank.
If operation is not as specified, replace the switch.
20. INSPECT PARKING BRAKE WARNING SWITCH CON-
TINUITY
(a) Check that continuity exists between terminal and switch
body with the switch ON (switch pin released).
(b) Check that no continuity exists between terminal and
switch body with the switch OFF (switch pin pushed in).
If operation is not as specified, replace the switch or inspect
ground point.
21. INSPECT REAR LIGHTS WARNING LIGHT
(a) Disconnect the connector from the light failure sensor and
ground terminal 4 on the wire harness side connector.
(b) Start the engine, check that the warning light lights up.
If the warning light does not light up, test the bulb or inspect wire
harness.

I03099
BE0B4-04
- BODY ELECTRICALENGINE IMMOBILISER SYSTEM
BE-181
1785 Author
: Date
:
2001 AVALON (RM808U)
INSPECTION
INSPECTION TRANSPONDER KEY COIL CONTINUITY
Check that continuity exists between terminal 1 and 2.
If continuity is not as specified, replace the coil.

I18944
0.4 °
3 m (9.84 ft) H 20.9 mm
(0.823 in.)
7
V RH Line
90 °
V LH Line4V LH LineV Line V RH Line 65
6
V LH LineV Line
V RH Line 6
5
6
H4
O: step No.
7
H4
20.9 mm
(0.823 in.)
20.9 mm
(0.823 in.) 1,342mm (52.8 in.) Low Beam:
High Beam:20.9 mm
(0.823 in.)
20.9 mm
(0.823 in.)
1,342mm (52.8 in.)
1,342mm
(52.8 in.) Hight Bearm
Low Bearm BE-24
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
1628 Author
: Date
:
2. ADJUST HEADLIGHT AIM ONLY
(a) Place the vehicle in the following conditions.

The area around the headlight is not deformed.

The vehicle is parked on a level surface.

Tire inflation pressure is the specified value.

A driver is in the driver's seat and the vehicle is in a state ready for driving (with a tank full).

The vehicle has been bounced several times.
(b) Check the headlight aiming.
(1) Prepare a thick white paper.
(2) Stand the paper perpendicular to the ground at the position 9.84 ft away from the headlights.
(3) Ensure that the center line of the vehicle and the paper face forms a 90-degree angle as shown
in the illustration.
(4) Draw a horizontal line (H line) on the paper, showing where the headlights should strike.
(5) Draw a vertical line (V line) to where the center line of the vehicle is to be.
(6) Draw 2 vertical lines (by connecting the low and high beam center marks) to where the both head-
lights should strike (V RH and V LH lines).
(7) Draw a horizontal line (by connecting the both low beam center marks) to where the headlights
should strike (H RH and H LH lines).
HINT:
The H RH and H LH line is 0.4° below the horizontal line (H line) of the light axis.
(8) Start the engine.
(9) Turn the headlights ON.
(10) Check that the headlights properly strike the position shown in the illustration.
(11) If not, adjust the lights in the vertical direction.
HINT:
As shown in the illustration, adjust each aim of the RH and LH lights.
(c) When adjusting it in the vertical direction:
Using adjusting bolt, adjust the headlight aim to within the specified range.

N10192
BO2PN-01
- BODYSLIDING ROOF
BO-77
1862 Author
: Date
:
2001 AVALON (RM808U)
SLIDING ROOF
ON-VEHICLE INSPECTION
INSPECT SLIDING ROOF GLASS ALIGNMENT
(a) Start the engine and check the operation time of the slid-
ing roof.
Operation time:
Approx. 6 secs.
(b) Check for abnormal noise or binding during operation.
(c) With the sliding roof fully closed, check for water leakage.
(d) Check for a difference in level between the sliding roof
weatherstrip and roof panel.
Except rear corners:
0 ± 1.5 mm (0 ± 0.059 in.)
Rear corners:
0 + 1.5 mm (0 + 0.059 in.)
0 - 1.0 mm (0 - 0.039 in.)

D07259DLC3
TOYOTA Hand-held TesterBR155-01
BR-52
- BRAKEABS & VSC ACTUATOR
1451 Author
: Date
:
2001 AVALON (RM808U)
ABS & VSC ACTUATOR
ON-VEHICLE INSPECTION
1. CONNECT TOYOTA HAND-HELD TESTER:
(a) Connect the TOYOTA hand-held tester to the DLC3.
(b) Start the engine and run it at idle.
(c) Select the ACTIVE TEST mode on the TOYOTA hand-
held tester.
Please refer to the TOYOTA hand-held tester operator's
manual for further details.
2. INSPECT ACTUATOR MOTOR OPERATION
(a) With the motor relay ON, check the actuator motor opera-
tion noise.
(b) Turn the motor relay OFF.
(c) Depress the brake pedal and hold it for about 15 seconds.
Check that the brake pedal cannot be depressed.
(d) With the motor relay ON, check that the pedal does not
pulsate.
NOTICE:
Do not keep motor relay ON for more than 5 seconds con-
tinuously. When operating it continuously, set the interval
of more than 20 seconds.
(e) Turn the motor relay OFF and release the brake pedal.
3. INSPECT RIGHT FRONT WHEEL OPERATION
NOTICE:
Never turn ON the solenoid which is not described below.
(a) With the brake pedal depressed, perform the following
operations.
(b) Turn the SFRH and SFRR solenoid ON simultaneously,
and check that the pedal cannot be depressed.
NOTICE:
Do not keep solenoid ON for more than 10 seconds contin-
uously. When operating it continuously, set the interval of
more than 20 seconds.
(c) Turn the SFRH and SFRR solenoid OFF simultaneously,
and check that the pedal can be depressed.
(d) Turn the motor relay ON, and check that the pedal re-
turns.
NOTICE:
Do not keep motor relay ON for more than 5 seconds con-
tinuously. When operating it continuously, set the interval
of more than 20 seconds.
(e) Turn the motor relay OFF and release the brake pedal.
4. INSPECT OTHER WHEEL OPERATION
As in the same procedure, check the solenoids of other wheels.
HINT:
Left front wheel: SFLH, SFLR
Right rear wheel: SRRH, SRRR
Left rear wheel: SRLH, SRLR
5. CLEAR DTC (See page DI-252)

BR2237
BR0KW-04
BR2238
GOODNO GOOD
2nd3rd
1st
- BRAKEBRAKE BOOSTER ASSEMBLY
BR-21
1420 Author
: Date
:
2001 AVALON (RM808U)
BRAKE BOOSTER ASSEMBLY
ON-VEHICLE INSPECTION
1. OPERATING CHECK
(a) Depress the brake pedal several times with the engine off
and check that there is no change in the pedal reserve
distance.
(b) Depress the brake pedal and start the engine. If the pedal
goes down slightly, operation is normal.
2. AIR TIGHTNESS CHECK
(a) Start the engine and stop it after 1 or 2 minutes. Depress
the brake pedal several times slowly.
If the pedal goes down farthest the 1st time, but gradually rises
after the 2nd or 3rd time, the booster is air tight.
(b) Depress the brake pedal while the engine is running, and
stop the engine with the pedal depressed.
If there is no change in the pedal reverse travel after holding the
pedal for 30 seconds, the booster is air tight.
