- DIAGNOSTICSENGINE
DI-49
205 Author: Date:
2001 AVALON (RM808U)
DTC P0136 Oxygen Sensor Circuit Malfunction (Bank 1
Sensor 2)
CIRCUIT DESCRIPTION
Refer to DTC P0125 on page DI-43.
DTC No.DTC Detecting ConditionTrouble Area
P0136
Voltage output of heated oxygen sensor remains at 0.4 V or
more or 0.55 V or less when vehicle is driven at 50 km/h (31
mph) or more after engine is warmed up (2 trip detection logic)Open or short in heated oxygen sensor circuit
Heated oxygen sensor
HINT:
Bank 1 refers to the bank that includes cylinder No.1.
Sensor 2 refers to the sensor farther away from the engine body.
WIRING DIAGRAM
Refer to DTC P0125 on page DI-43.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
1 Are there any other codes (besides DTC P0136) being output?
YES Go to relevant DTC chart (See page DI-14).
NO
2 Check for open and short in harness and connector between ECM and heated
oxygen sensor (See page IN-30).
NG Repair or replace harness or connector.
OK
DI07Q-09
Page 935 of 1897
A06104
ON
HTS
(+)
(-)
- DIAGNOSTICSENGINE
DI-51
207 Author: Date:
2001 AVALON (RM808U)
DTC P0141 Oxygen Sensor Heater Circuit Malfunction
(Bank 1 Sensor 2)
CIRCUIT DESCRIPTION
Refer to DTC P0125 on page DI-43.
DTC No.DTC Detecting ConditionTrouble Area
P0141
When heater operates, heater current exceeds 2.35 A (2 trip
detection logic)Open or short in heater circuit of heated oxygen sensor
Htd htP0141Heater current of 0.2 A or less when heater operates (2 trip
detection logic)Heated oxygen sensor heater
ECM
HINT:
Bank 1 refers to the bank that includes cylinder No.1.
Sensor 2 refers to the sensor farther away from the engine body.
WIRING DIAGRAM
Refer to DTC P0125 on page DI-43.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
1 Check voltage between terminal HTS of ECM connector and body ground.
PREPARATION:
(a) Remove the glove compartment (See page SF-82).
(b) Turn the ignition switch ON.
CHECK:
Measure the voltage between terminal HTS of the ECM con-
nector and body ground.
OK:
Voltage: 9 - 14 V
OK Check and replace ECM (See page IN-30).
NG
2 Check resistance of heated oxygen sensor heater (See page SF-81).
NG Replace heated oxygen sensor.
DI6T3-01
Page 938 of 1897
A11083
Fusible
Link Block
Battery FL
MainB-O
B-W
2
2
2
2
2
21
1
1
1
1
1L
R
Y
W
GE5
IG Switch
No.1
No.2
No.3
No.4
No.5
No.6
Injector
W-B
ED
5
6
21
311
2
3
4#10
#20
#30
#40
#50
#60
E01
E02ECM
112B
2G
AM2
41 B
F6F7
11J
67
IF1 1C
2CIG23
5
W-RE4
E4
E4
E4
E4
E4E5
W-B
B-W
B-W
B-W
B-W
B-W22
2
2C2F
7
7
W-R
4
1
B
Driver Side J/BEngine Room J/B
W-B
EB
G DDL J8
J/C
B-WB-W B-WB-W B-W
IG2 Relay
W-B
B-O2
- DIAGNOSTICSENGINE
DI-59
215 Author: Date:
2001 AVALON (RM808U)
HINT:
When the 2 or more codes for a misfiring cylinder are recorded repeatedly but no Random Misfire code is
recorded, it indicates that the misfires were detected and recorded at different times.
WIRING DIAGRAM
CONFIRMATION DRIVING PATTERN
(a) Connect the TOYOTA hand-held tester or OBD II scan tool.
(b) Record the DTC and the freeze frame data.
(c) Use the TOYOTA hand-held tester to set to the check mode (See page DI-3).
(d) Drive the vehicle several times with the engine speed, load and its surrounding range shown with the
ENGINE SPD, CALC LOAD in the freeze frame data or the MISFIRE RPM, MISFIRE LOAD in the data
list.
If you have no TOYOTA hand-held tester, turn the ignition switch OFF after the symptom is simulated the
first time. Then repeat the simulation process again.
HINT:
In order to memorize DTC of misfire, it is necessary to drive around MISFIRE RPM, MISFIRE LOAD in the
data list for the following period of time.
Engine SpeedTime
Idling3 minutes 30 seconds or more
1,000 rpm3 minutes or more
2,000 rpm1 minute 30 seconds or more
3,000 rpm1 minute or more
Page 943 of 1897
A03315
Knock Sensor 1
(on Right Bank)
Knock Sensor 2
(on Left Bank)EB1 1
1W
W1
2W
WE4ECM
27
28KNKR
KNKLE1
E1 E4 EB1 DI-64
- DIAGNOSTICSENGINE
220 Author: Date:
2001 AVALON (RM808U)
DTC P0325 Knock Sensor 1 Circuit Malfunction (Bank 1)
DTC P0330 Knock Sensor 2 Circuit Malfunction (Bank 2)
CIRCUIT DESCRIPTION
Each of knock sensor is fitted to the right bank and left bank of the cylinder block to detect engine knocking.
This sensor contains a piezoelectric element which generates a voltage when it becomes deformed, which
occurs when the cylinder block vibrates due to knocking. If engine knocking occurs, ignition timing is retarded
to suppress it.
DTC No.DTC Detecting ConditionTrouble Area
P0325No knock sensor 1 signal to ECM with engine speed between
2,000 rpm and 5,600 rpmOpen or short in knock sensor 1 circuit
Knock sensor 1 (looseness)
ECM
P0330No knock sensor 1 signal to ECM with engine speed between
2,000 rpm and 5,600 rpmOpen or short in knock sensor 2 circuit
Knock sensor 2 (looseness)
ECM
If the ECM detects the above diagnosis conditions, it operates the fail-safe function in which the corrective
retard angle value is set to the maximum value.
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
DTC P0325 is for the right bank knock sensor circuit.
DTC P0330 is for the left bank knock sensor circuit.
DI07T-09
Page 946 of 1897
A11084
Right Bank VVT Sensor (Camshaft Position Sensor)
Crankshaft Position Sensor1
2
1
2
B-W B-W
L
L16
2410ECM
VV1+
NE+
NE-
E2
21LB-W
LE4
E5
VV2+ 22 Left Bank VVT Sensor (Camshaft Position Sensor)E5
E4 CC
C
CJ8 J/C
- DIAGNOSTICSENGINE
DI-67
223 Author: Date:
2001 AVALON (RM808U)
DTC P0335 Crankshaft Position Sensor ºAº Circuit Mal-
function
CIRCUIT DESCRIPTION
Crankshaft position sensor (NE signal) consists of a magnet, iron core and pickup coil.
The NE signal plate has 34 teeth and is installed the crankshaft timing pulley. The NE signal sensor gener-
ates 34 signals at every engine revolution. The ECM detects the standard crankshaft angle based on the
G (VV) signal, and the actual crankshaft angle and the engine speed by the NE signal.
DTC No.DTC Detecting ConditionTrouble Area
P0335
No crankshaft position sensor signal to ECM during cranking
(2 trip detection logic)Open or short in crankshaft position sensor circuit
Crankshaft position sensor
P0335No crankshaft position sensor signal to ECM with engine
speed 600 rpm or more (2 trip detection logic)
Crankshaft osition sensor
Crankshaft timing pulley
ECM
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
Perform troubleshooting of DTC P0335 first. If no trouble is found, troubleshoot the following mechani-
cal systems.
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected. When troubleshooting, it is useful for
determining whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel
ratio was lean or rich, etc. at the time of the malfunction.
DI07U-09
Page 948 of 1897
- DIAGNOSTICSENGINE
DI-69
225 Author: Date:
2001 AVALON (RM808U)
DTC P0340 Camshaft Position Sensor Circuit Malfunc-
tion
CIRCUIT DESCRIPTION
Camshaft position sensor (G (VV) signal) consists of a magnet, iron core and pickup coil.
The G (VV) signal plate has 3 teeth, on its outer circumference and is installed the camshaft timing gear.
When the camshafts rotate, the protrusion on the signal plate and the air gap on the pickup coil change,
causing fluctuations in the magnetic field and generating an electromotive force in the pickup coil.
The NE signal plate has 34 teeth and is installed the crankshaft timing pulley. The NE signal sensor gener-
ates 34 signals at every engine revolution. The ECM detects the standard crankshaft angle based on the
G (VV) signal and the actual crankshaft angle and the engine speed by the NE signal.
DTC No.DTC Detecting ConditionTrouble Area
P0340
No camshaft position sensor signal to ECM during cranking (2
trip detection logic)Open or short in camshaft position sensor circuit
Camshaft position sensor
P0340No camshaft position sensor signal to ECM with engine speed
600 rpm or more
Camshaft osition sensor
Camshaft timing gear
ECM
WIRING DIAGRAM
Refer to DTC P0335 on page DI-67.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
1 Check resistance of camshaft position sensor (See page IG-1).
Reference: INSPECTION USING OSCILLOSCOPE
Refer to DTC P0335 on page DI-67.
NG Replace camshaft position sensor.
OK
2 Check for open and short in harness and connector between ECM and camshaft
position sensor (See page IN-30).
NG Repair or replace harness or connector.
DI07V-09
Page 954 of 1897
A11666
ECM
Vapor Pressure Sensor
2B6
P-B
VSV for EVAP
B-R
2
15 V
VC
PTNK
E1
E2
EVP1
E01
E01
TBP
3
2
Engine Room J/B
B-W
W-B
P
1
WE5
E82
17
18
7
3
E7
EFI Relay
PL-R
ID1 II215 4
5
E5
ID1 9
6 2G
4 2
53
2
1 EFI
No.1
From
Battery
20
G
VSV for Pressure
Switching ValveCCV
2
110
318
1
VSV for CCV
14
E01 L-R L-R
W WID1
ID1 II2
E5
E8 B-W
2B
2B 2FEFI
No.2
4
EDID1II1 G
B-W B-W
2
P-B
L-OFrom
Terminal
MREL of
ECM
B
B-W
- DIAGNOSTICSENGINE
DI-75
231 Author: Date:
2001 AVALON (RM808U)
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
If DTC P0441, P0446, P0450 or P0451 is output after DTC P0440 or P0442, first troubleshoot DTC
P0441, P0446, P0450 or P0451. If no malfunction is detected, troubleshoot DTC P0440 or P0442 next.
Ask the customer whether, after the MIL came on, the customer found the fuel tank cap loose and tight-
ened it. Also ask the customer whether the fuel tank cap was loose when refuelling. If the fuel tank cap
was loose, it was the cause of the DTC. If the fuel tank cap was not loose or if the customer was not
sure if it was loose, troubleshoot according to the following procedure.
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected. When troubleshooting, it is useful for
determining whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel
ratio was lean or rich, etc. at the time of the malfunction.
When the ENGINE RUN TIME in the freeze frame data is less than 200 seconds, carefully check the
vapor pressure sensor.
Page 960 of 1897
- DIAGNOSTICSENGINE
DI-81
237 Author: Date:
2001 AVALON (RM808U)DTC No.
DTC Detecting ConditionTrouble Area
P0441
Pressure in charcoal canister and fuel tank does not drop dur-
ing purge control (2 trip detection logic)Vacuum hose cracks, holed blocked, damaged or discon-
nected ((1), (2), (3), (4), (5), (6), (7), (8), (9), (10) and (11) in
Fig 1)P0441
During purge cut-off, negative pressure incomming in the char-
coal canister and fuel tank will not stop. (2 trip detection logic)
Fig. 1)
Fuel tank cap incorrectly installed
Fuel tank cap cracked or damaged
Open or short in vaporpressure sensorcircuit
When VSV for pressure switching valve is ON, ECM judges
that there is no continuity between vapor pressure sensor, fuel
tank and charcoal canister (2 trip detection logic)
Open or short in vapor pressure sensor circuit
Vapor pressure sensor
Open or short in VSV circuit for EVAP
VSV for EVAP
O h t i VSV i it f CCV
P0446
When VSV for pressure switching valve is turned OFF, pres-
sure in fuel tank is maintained at atmospheric pressure (2 trip
detection logic)
Open or short in VSV circuit for CCV
VSV for CCV
Open or short in VSV circuit for pressure switching valve
VSV for pressure switching valve
When VSV for CCV is ON, pressure in charcoal canister and
fuel tank is maintained at atmospheric pressure (2 trip detec-
tion logic)
g
Fuel tank cracked, holed or damaged
Charcoal canister cracked, holed or damaged
Fuel tank over fill check valve cracked damaged
ECM
WIRING DIAGRAM
Refer to DTC P0440 or P0442 on page DI-74.
INSPECTION PROCEDURE
HINT:
If DTC P0441, P0446, P0450 or P0451 is output after DTC P0440 or P0442,first troubleshoot DTC
P0441, P0446, P0450 or P0451. If no malfunction is detected, troubleshoot DTC P0440 or P0442 next.
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected. When troubleshooting, it is useful for
determining whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel
ratio was lean or rich, etc. at the time of the malfunction.
When the ENGINE RUN TIME in the freeze frame data is less than 200 seconds, carefully check the
vapor pressure sensor.
TOYOTA hand-held tester:
1 Check whether hose close to fuel tank have been modified, and check whether
there are signs of any accident near fuel tank or charcoal canister (See page
DI-74, step 1).
NG Repair or replace.
OK
2 Check that fuel tank cap is TOYOTA genuine parts (See page DI-74, step 2).
NG Replace to TOYOTA genuine parts.
