DI-98
- DIAGNOSTICSENGINE
254 Author: Date:
2001 AVALON (RM808U)
WIRING DIAGRAM
Refer to DTC P0440 or P0442 on page DI-74.
INSPECTION PROCEDURE
HINT:
If DTC P0441, P0446, P0450 or P0451 is output after DTC P0440 or P0442, first trouble shoot DTC
P0441, P0446 P0450 or P0451. If no malfunction is detected, troubleshoot DTC P0440 or P0442 next.
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected. When troubleshooting, it is useful for
determining whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel
ratio was lean or rich, etc. at the time of the malfunction.
When the ENGINE RUN TIME in the freeze frame data is less than 200 seconds, carefully check the
VSV for EVAP, charcoal canister and vapor pressure sensor.
1 Check voltage between terminals VC and E2 of ECM connector (See page
DI-74, step 9).
NG Check and replace ECM (See page IN-30).
OK
2 Check voltage between terminals PTNK and E2 of ECM connectors (See page
DI-74, step 10).
OK Check and replace ECM (See page IN-30).
NG
3 Check for open and short in harness and connector between vapor pressure sen-
sor
and ECM (See page IN-30).
NG Repair or replace harness or connector.
OK
Replace vapor pressure sensor.
Page 978 of 1897
A00022
4-Pulse
Engine
ECM
Multi Display From
Speed Sensor4-Pulse
ABS Actuator
& ECU
A11086
Multi Display
18
M3 E73F V-W V-WECM
SPD5 V
122
3C 1J/B No.3
- DIAGNOSTICSENGINE
DI-99
255 Author: Date:
2001 AVALON (RM808U)
DTC P0500 Vehicle Speed Sensor Malfunction
CIRCUIT DESCRIPTION
This sensor is mounted in the combination meter. It contains a magnet which is rotated by the speedometer
cable.
Turning the reed switch ON and OFF 4 times for every revolution of the speedometer.
It is then transmitted to the Engine ECM. The Engine ECM determines the vehicle speed based on the fre-
quency of these pulse signals.
DTC No.DTC Detecting ConditionTrouble Area
No vehicle speed sensor signal to Engine & ECT ECU underCombination meter
P0500/61
No vehicle speed sensor signal to Engine & ECT ECU under
th f ll i diti (2 t i d t ti l i )
Combination meter
Ohtid iitP0500/61the following conditions: (2 trip detection logic)Open or short in speed sensor circuitg( g)
Vehicle is being drivenECM
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
DI082-09
Page 981 of 1897
P01559
Throttle Valve
From
Air
Cleaner
Signal
ECM
ValveIAC Valve
To Cylinders Intake Air Chamber
A11664
From Battery2G1 2
4 EFI
No.1EFI Relay
1 23
52A
2B 2F
J7
J/C IAC Valve
G-B
BR
21
3E4ECM
RSO
E01
EC26
A B-W
L-O
BRA
4EFI
No.2
B
W-B
EDEngine Room J/B
EBA
From
Terminal
MREL of
ECM
DI-102
- DIAGNOSTICSENGINE
258 Author: Date:
2001 AVALON (RM808U)
DTC P0505 Idle Control System Malfunction
CIRCUIT DESCRIPTION
The rotary solenoid type IAC valve is located in front of the in-
take air chamber and intake air bypassing the throttle valve is
directed to the IAC valve through a passage.
In this way the intake air volume bypassing the throttle valve is
regulated, controlling the engine speed.
The ECM operates only the IAC valve to perform idle-up and
provide feedback for the target idling speed.
DTC No.DTC Detecting ConditionTrouble Area
P0505Idle speed continues to vary greatly from the target speed (2
trip detection logic)
Open or short in IAC valve circuit
IAC valve is stuck or closed
Open or short in A/C signal circuit
Air induction system
ECM
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
DI083-09
Page 985 of 1897
DI-106
- DIAGNOSTICSENGINE
262 Author: Date:
2001 AVALON (RM808U)
DTC P1130 A/F Sensor Circuit Range/Performance Mal-
function (Bank 1 Sensor 1)
DTC P1150 A/F Sensor Circuit Range/Performance Mal-
function (Bank 2 Sensor 1)
CIRCUIT DESCRIPTION
Refer to DTC P0125 on page DI-43.
DTC No.DTC Detecting ConditionTrouble Area
Voltage output* of A/F sensor remains at 3.8 V or more, or 2.8
V or less, during engine running after the engine is warmed up
(2 trip detection logic)
*: Output value changes at inside of ECM only
Open or short in A/F sensor circuit
A/F sensor
P1130
P1150Voltage output* of A/F sensor does not change from 3.30 V,
during engine running after the engine is warmed up (2 trip
detection logic)
*: Output value changes at the inside of ECM onlyAir induction system
Fuel pressure
Injector
ECM
Open or short in A/F sensor circuit (2 trip detection logic)
HINT:
After confirming DTC P1130, use the OBD II scan tool or TOYOTA hand-held tester to confirm voltage
output of A/F sensor (AFS B1 S1/O2S B1 S1) from the CURRENT DATA.
The A/F sensor's output voltage and the short-term fuel trim value can be read using the OBD II scan
tool or TOYOTA hand-held tester.
The ECM controls the voltage of the AFR+, AFL+, AFR- and AFL- terminals of the ECM to the fixed
voltage. Therefore, it is impossible to confirm the A/F sensor output voltage without the OBDII scan
tool or TOYOTA hand-held tester.
OBD II scan tool (excluding TOYOTA hand-held tester) displays the one fifth of the A/F sensor output
voltage which is displayed on the TOYOTA hand-held tester.
WIRING DIAGRAM
Refer to DTC P0125 on page DI-43.
DI2H7-03
Page 990 of 1897
- DIAGNOSTICSENGINE
DI-1 11
267 Author: Date:
2001 AVALON (RM808U)
DTC P1133 A/F Sensor Circuit Response Malfunction
(Bank 1 Sensor 1)
DTC P1153 A/F Sensor Circuit Response Malfunction
(Bank 2 Sensor 1)
CIRCUIT DESCRIPTION
Refer to DTC P0125 on page DI-43.
DTC No.DTC Detecting ConditionTrouble Area
P1133
P1153
After engine is warmed up, and during vehicle driving at engine
speed 1,400 rpm or more and vehicle speed 60 km/h (38 mph)
or more, if the response characteristic of A/F sensor becomes
deteriorated (2 trip detection logic)
Open or short in A/F sensor circuit
A/F sensor
Air induction system
Fuel pressure
Injector
ECM
WIRING DIAGRAM
Refer to DTC P0125 on page DI-43.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
1 Are there any other codes (besides DTC P1133, P1153) being output?
YES Go to relevant DTC chart (See page DI-14).
NO
2 Connect OBDII scan tool or TOYOTA hand-held tester, and read value for volt-
age output of A/F sensor.
PREPARATION:
(a) Connect the OBD II scan tool or TOYOTA hand-held tester to the DLC3.
(b) Warm up the A/F sensor with the engine speed at 2,500 rpm for approx. 90 sec.
CHECK:
Read the voltage of the A/F sensor on the screen of the OBD II scan tool or TOYOTA hand-held tester when
you perform all the following conditions.
DI2H8-03
Page 994 of 1897
A02032
HAFL ON
HAFR
(+)
(-)
- DIAGNOSTICSENGINE
DI-1 15
271 Author: Date:
2001 AVALON (RM808U)
DTC P1135 A/F Sensor Heater Circuit Malfunction (Bank
1 Sensor 1)
DTC P1155 A/F Sensor Heater Circuit Malfunction (Bank
2 Sensor 1)
CIRCUIT DESCRIPTION
Refer to DTC P0125 on page DI-43.
DTC No.DTC Detecting ConditionTrouble Area
P1135
When the heater operates, heater current exceeds 8 A
(2 trip detection logic)Open or short in heater circuit of A/F sensor
A/F h tP1135
P1155Heater current of 0.25 A or less when the heater operates
(2 trip detection logic)A/F sensor heater
ECM
WIRING DIAGRAM
Refer to DTC P0125 on page DI-43.
INSPECTION PROCEDURE
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
1 Check voltage between terminals HAFL, HAFR of ECM connector and body
ground.
PREPARATION:
(a) Remove the glove compartment (See page SF-83).
(b) Turn the ignition switch ON.
CHECK:
Measure the voltage between terminals HAFL, HAFR of the
ECM connector and body ground.
OK:
Voltage: 9 - 14 V
OK Check and replace ECM (See page IN-30).
NG
2 Check resistance of A/F sensor heater (See page SF-79).
DI2H9-03
Page 997 of 1897
A11669
14
3 2
B-R
L LG-B
L-Y
LG 1
4
2
43
21
43
21
43
21
43
2
Ignition Coil
with Igniter
No.2
No.3
No.4
No.5
No.6
Noise
Filter B-Y W-BB-W
GR
13 No.1B-W
B-W B-W B-W
B-WB-Y
B-Y B-Y B-Y B-Y B-Y
W-B
W-B
W-B
W-B W-B
1
B-W
B-WW-B
B-W
B-W
B-WW-B W-B W-B
B-W
W-BIGT1
IGF IGT2
IGT3
IGT4
IGT5
IGT6 11
12
13
14
15
16
25 E4
E4
E4
E4
E4
E4
E4ECM
Battery
EC ED
115
2B
B-O
2F 1C28
3
IG Switch72
14 IG2 Reray
2G
2C 2CIG2
AM2 72
1J B-O
7
6W-R
W-R4
IF1Engine Room J/B
Driver Side J/BB
Fusible
Link
Block
FL
Main 1F6 F7
B-W
1 B-Y
B-Y B-Y B-Y
W-B
DI-1 18
- DIAGNOSTICSENGINE
274 Author: Date:
2001 AVALON (RM808U)
WIRING DIAGRAM
INSPECTION PROCEDURE
HINT:
If DTC P1300 is displayed, check No.1 ignition coil with igniter circuit.
If DTC P1305 is displayed, check No.2 ignition coil with igniter circuit.
If DTC P1310 is displayed, check No.3 ignition coil with igniter circuit.
If DTC P1315 is displayed, check No.4 ignition coil with igniter circuit.
If DTC P1320 is displayed, check No.5 ignition coil with igniter circuit.
If DTC P1325 is displayed, check No.6 ignition coil with igniter circuit.
If DTCs P1300, P1315 and P1325, are output simultaneously, IGF1 circuit may be open or short.
If DTCs P1305, P1310 and P1320, are output simultaneously, IGF2 circuit may be open or short.
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame
records the engine conditions when the malfunction is detected. When troubleshooting, it is useful for
determining whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel
ratio was lean or rich, etc. at the time of the malfunction.
1 Check spark plug and spark (See page DI-58).
Page 1002 of 1897
- DIAGNOSTICSENGINE
DI-123
279 Author: Date:
2001 AVALON (RM808U)
DTC P1335 Crankshaft Position Sensor Circuit Malfunc-
tion (During engine running)
CIRCUIT DESCRIPTION
Refer to DTC P0335 on page DI-67.
DTC No.DTC Detecting ConditionTrouble Area
P1335No crankshaft position sensor signal to ECM with engine
speed 1,000 rpm or more
Open or short in crankshaft position sensor circuit
Crankshaft position sensor
Crankshaft timing pulley
ECM
WIRING DIAGRAM
Refer to DTC P0335 on page DI-67.
INSPECTION PROCEDURE
Refer to DTC P0335 on page DI-67.
HINT:
Read freeze frame data using TOYOTA hand-held tester or OBD II scan tool. Because freeze frame records
the engine conditions when the malfunction is detected. When troubleshooting, it is useful for determining
whether the vehicle was running or stopped, the engine was warmed up or not, the air-fuel ratio was lean
or rich, etc. at the time of the malfunction.
DI085-09
