2001 PEUGEOT EXPERT DAG Owners Manual

136

STEERING WHEEL ADJUSTMENTI-817
IMPORTANT
As a safety measure,
these manoeuvres must not be carried out when driving.
The height of the steering wheel can be adjusted.
When stationary, first adjust your seat to the most suitable position.
Unlock the steering wheel by pushing the adjustment control.Adjust the height of the steering wheel then lock it by pulling the adjustment control fully towards you. Make sure that you can see all the displays on the fascia panel.

COMBI 5/6-SEATER19I-10
These models are fitted with two individual front seats as standard. FIVE SEATER CONFIGURATION
The basic version offers a three-
seater bench in second row. The bench can be removed. SIX SEATER CONFIGURATION
The 6-seater version offers a two- seater bench instead of the indivi-dual front passenger seat.

COMBI 8/9-SEATERI-10
20
EIGHT SEATER CONFIGURATION
This version offers a three-seater bench for the third row.
In this case, in order to provide access to the third row, the second row offers a two-seater bench on the left and a single seat on the right.

COMBI 8/9-SEATER21I-10
NINE SEATER CONFIGURATION
This version offers a two-seater bench instead of the individual front passenger seat.The three-seater bench of the third row can be:
- folded.
- tilted.
- removed.

DASHBOARD*I-11
22
18 17 16 15
12 3 45 6 7
14 13 12 11 10 9 8* According to model or country

DASHBOARD*23I-11
1Left hand air vent & Side glass demister vent.
2 Controls for: ¥ Lighting ¥ Direction indicators ¥ Horn ¥ Foglamp
3 Instrument panel.
4 Controls for: ¥ Windscreen wash ¥ Windscreen wiper
5 Centre air vents. 6
Radio housing or oddments pocket.
7 Right hand air vent & Side glassdemister vent.
8 Glovebox.
9 Heating/ventilation controls.
10 Ashtray & Cigar lighter.
11 Gear lever. 12
Controls for: ¥ Hazard warning lamps.
¥ Heated glass of hinged rear
doors.
¥ Air conditioning
¥ Demisting and defrosting of the rear view mirrors.
13 Steering lock and ignition switch.
14 Fuse box access.
15 Adjusting the headlamps.
16 Cruise control lever.
17 Bonnet release lever.
18 Cruise control switch.
* According to model or country

INSTRUMENT PANEL*I-12
24
Display
¥ Digital clock.
¥ Maintenance indicator.
¥ Engine oil level indicator.
¥ Total mileage recorder.
¥ Trip mileage recorder.
Coolant temperature gauge Fuel gauge
Dashboard lighting rheostat See Page 31 Changing the time See Page 30
Display control:
¥ Total mileage recorder.
¥ Trip mileage recorder.
¥ Resetting the trip mileage recorder to zero. Tachometer Do not enter the red zone
* According to model or country
