2001 PEUGEOT EXPERT DAG Owners Manual

STEERING LOCK - IGNITION - STARTER51II-1
WARNING
NEVER REMOVE THE IGNITION KEY BEFORE THE VEHICLE IS COMPLETELY STATIONARY. NEVER ATTEMPT TO MOVE THE VEHICLE BEFORE STARTING THE ENGINE AND WAITING FOR THE HYDRAULIC LOW PRESSURE WAR-
NING LAMP TO GO OUT. IF THE ENGINE IS NOT RUNNING, THE STEERING
WILL NOT HAVE POWER ASSISTANCE AND THERE MAY BE NO RESERVE OF PRESSURE AVAILABLE TO OPERATE THE FOOTBRAKE. THERE IS ALSO ARISK OF THE STEERING LOCK ENGAGING AND THE SAFETY FEATURES NOT OPERATING IF THE IGNITION IS NOT SWITCHED ON. ONLY IN AN
EMERGENCY SITUATION SHOULD YOU ATTEMPT TO MOVE A VEHICLE
WITHOUT STARTING THE ENGINE. TAKE ALL THE NECESSARY SAFETY
PRECAUTIONS AND BE PREPARED TO USE THE PARKING BRAKE TO STOP THE VEHICLE.
When parking, remove the ignition key and turn the steering wheel until the steering column locking peg engages.
Steering lock
S With the key removed and the steering lock peg engaged, the steering column is locked; the lock peg will engage in
a number of positions of the steering wheel. The key can only be removed in position S.
A The steering is unlocked - to enable the key to be turned to position A, it may be necessary to turn the steering slightly.
M Running position.
D Starting position.
For starting and stopping the engine, see Ç Starting È.

STARTINGII-2
52
Ensure that the gear lever is in the neutral position.
PETROL Starting the engine Do not depress the accelerator pedal. Operate the starter motor (maximum 10 seconds) until the engine starts.
At temperatures below 0¡C, depress the clutch pedal to ease starting, then release it slowly. Release the key as soon as the engine starts. Note: If it does not work at first, switch off the ignition, wait for ten seconds, then operate the starter again as described
above.

STARTING53II-2
WARNING
DO NOT RUN THE ENGINE IN AN ENCLOSED OR POORLY VENTILATED AREA
DIESEL Starting the engine
Turn the ignition key to the ignition position. Wait for the preheater lamp to go out, then operate the starter motor until the engine starts.
If the engine does not start, switch off the ignition and start again.At temperatures below 0¡C, depress the clutch pedal to ease starting. Release the pedal slowly when the engine has started. Note:
Do not depress the accelerator pedal while operating the starter.
Advice
Vehicles equipped with a Turbo:
Turbo equipped engines MUST be allowed to return to idle for several seconds before switching off the ignition. Failure to do so could cause serious damage to the turbo unit.
Flicking the throttle pedal as the ignition is turned off can lead to severe damage to the turbo unit.

BRAKESII-3
54
Handbrake
To create a passage between the front seats, the handbrake lever is mounted
to the left of the driverÕs seat. The handbrake is operated by pulling the lever firmly up - pressing the foot-
brake will reduce the effort required to apply the handbrake. The handbrake is capable of holding the vehicle on all slopes likely to be
encountered but increased effort will be needed on steep slopes.
In all circumstances, as a precautionary measure, engage first gear.On steep slopes, turn the steering towards the kerb.
To release the brake, pull the lever lightly up, press the button on the end of the lever and return the lever to the fully down position. The warning lamp will come on if the handbrake is on or not fully released when the engine is running .

BRAKES55II-4
ABS - Anti-lock Braking System* This system improves vehicle safety by preventing the wheels from locking under emergency braking or when
braking on surfaces offering poor adhesion.
It thus also allows control of the steering to be retained. The operation of the various electronic components of the system is continuously monitored, both before and during your
journey. On switching on the ignition, the ABS lamp will light for approximately two seconds. If it stays on or lights when
driving, the ABS computer has detected a fault and has disconnected the ABS system. If the lamp lights whilst driving, it
again indicates that a fault has been detected and that the ABS system is inactive. In both situations, the normal braking
system is not affected and will continue to function as a conventional braking system without ABS. Nevertheless, to re-
establish the full safety features of the ABS system, It is recommended that the vehicle be examined by a dealer as soonas possible.
On slippery roads (loose stones, snow, ice, etc.), it is imperative to drive with caution.
* According to model or country
Protection fuses under the dashboardF12
(under the bonnet)
MF4 (with ABS)

CRUISE CONTROL*II-5
56
The cruise control device will automatically maintain a constant road speed
(minimum 25 mph) as selected by the driver. The cruise control stalk Ais located below the direction indicator/lighting
switch. Cruise control master switch B Press the switch to turn on ; the warning lamp lights.
Press the switch to turn off ; the warning lamp goes out.
Selecting a cruising speedCan only operate when fourth or fifth gears are selected and the road speed exceeds 25 mph. Drive at the desired speed and register it by flicking stalk Aup or down. The
speed is now memorised and automatically regulated.The regulated speed can be exceeded by depressing the accelerator (when overtaking for example). Releasing the accelerator pedal will cause the speed to be regulated automa- tically to the memorised speed. Briefly pushing the control stalk upwards will increase the regulated speed and pushing it downward will reduce the regulated speed.
* According to model or country
0A
AB

CRUISE CONTROL*57II-5
BEWARE
Cruise control must only be used where road condi- tions permit. Do not use it on congested roads nor
when weather and road conditions are poor.
Disengaging the cruise control The cruise control will be disengaged on pressing either the clutch or brake pedal. Flicking stalk
Atoward you will also disengage the crui-
se control.The memorised speed is not cancelled. Recalling the memorised speed Following a disengagement, flick the stalk Arapidly
upwards or downwards and your vehicle will resume the last speed memorised. Increasing the memorised speed Move stalk Aupwards, hold until the new speed is rea-
ched and then release the stalk to memorise it. Reducing the memorised speed Move stalk Adownwards, hold until the new speed is
reached and then release the stalk to memorise it. (Minimum regulated speed = 25 mph). Cancelling the cruise control operation Either when the vehicle is stationary: ignition switched
off. Or Press switch B. The warning lamp will go out. AdviceDo not position your foot under the accelerator pedal
while the cruise control is operating. Your reactions maybe impeded and movement of your foot restricted.
* According to model or country
Protection fuses (under the dashboard)F3

GEAR LEVERII-6
58
Manual gearbox gear lever Reverse gear*
To select reverse, lift the ring under- neath the handle and push the gearlever to the left then forwards. Reverse gear can only be enga- ged when the vehicle is stationa-
ry, engine at idle.
* According to specification.
