1997 TOYOTA CELICA Owners Manual

44
CAUTION!

Always make sure the shoulder
belt is positioned across the cen-
ter of child's shoulder. The belt
should be kept away from child's
neck, but not falling off child's
shoulder. Failure to do so could re-
duce the amount of protection in
an accident and increase the
chance of injury.

High-positioned lap belts and
loose-fitting belts both could in-
crease the chance of injury due to
sliding under the lap belt during an
accident. Keep the lap belt as low
on your hip bone as possible.

For the safety, do not place the
shoulder belt under child's arm.

After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt is not twisted.

Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and
buckle.

If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your
Toyota dealer immediately. Do not
use the seat until the seat belt is
fixed.
2. To remove the child restraint system,
press the buckle-release button and al-
low the belt to retract.
ProCarManuals.com

45
If your child restraint system requires
the use of a top strap, latch the hook
onto the anchor bracket and tighten
the top strap.
See the following instructions to install the
anchor bracket.CoupeÐOn the filler panel behind the
rear seat
a. Using the illustration as a guide, run
your fingers across the trim of the filler
panel itself to locate the position of the
holes underneath.
b. Make a hole in the covering directly
above the hole in the filler panel.
c. Insert a 15 mm (0.6 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5±24.7 NV m (1.68±2.52 kgf-
V m, 12.2±18.2 ftV lbf).
ÐTop strap anchors and
locations (Coupe on liftback
only)
ProCarManuals.com

46
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra-
tion.
If your child restraint system does not pro-
vide any of the necessary parts, ask you
Toyota dealer. (See ÐChild restraint sys-
tem.º)
Liftback (right seat)ÐOn the luggage
compartment floor
a. Using the illustration as a guide, un-
cover the anchor by rolling back the car-
pet on the luggage compartment floor.
The anchor hole is sealed.
b. Remove the seal of the anchor.
c. Insert a 15 mm (0.6 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5Ð24.7 N Vm (1.68Ð2.52
kgf Vm, 12.2Ð18.2 ftl Vbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox. If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent en
try of exhaust emissions, water
or dirt.
ProCarManuals.com

47
Liftback (left seat)ÐOn the luggage
compartment wall
a. Using the illustration as a guide, re-
move the cap of the anchor.
b. Insert a 15 mm (0.6 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5Ð24.7 NVm (1.68Ð2.52
kgf Vm, 12.2Ð18.2 ft Vlbf)
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox.To change the steering wheel angle,
hold the steering wheel, pull up the
lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION!

Do not adjust the steering wheel
while the vehicle is moving.

After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Tilt steering wheel
ProCarManuals.com

47
Liftback (left seat)ÐOn the luggage
compartment wall
a. Using the illustration as a guide, re-
move the cap of the anchor.
b. Insert a 15 mm (0.6 in.) spacer and
tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5Ð24.7 NVm (1.68Ð2.52
kgf Vm, 12.2Ð18.2 ft Vlbf)
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox.To change the steering wheel angle,
hold the steering wheel, pull up the
lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
When the steering wheel is in a low posi-
tion, it will spring up as you release the
lock release lever.
CAUTION!

Do not adjust the steering wheel
while the vehicle is moving.

After adjusting the steering wheel,
try moving it up and down to make
sure it is locked in position.
Tilt steering wheel
ProCarManuals.com

48
Adjust the mirror so you can see the
side of your vehicle in the mirror.
Be careful when judging the size or dis-
tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex
mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
With power windows
Without power windows To adjust a mirror, use the switches.
1. Master switchÐTo select the m
irror to
be adjusted
Place the switch at Lº (left) or Rº (right).
2. Control switchÐTo move the mirror
push the switch in the desired direction.
If the engine is not running, the key must
be in the ACCº position.
If ice should jam the mirror, do not
operate the control or scrape the
mirror face. Use a spray de-icer tofree the mirror.
NOTICE
ÐPower rear view mirror
control
Outside rear view mirrorsÐ
ProCarManuals.com

49
The rear view mirrors can be folded
backward for parking in restricted
areas.
To fold the rear view mirror, push back-
ward.To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror.
Daylight drivingÐLever at position 1
The reflection in the mirror has greater
clarity at this position.
Night drivingÐLever at position 2
Remember that by reducing glare you
also lose some rear view clarity.
Anti-glare inside rear view
mirror
ÐFolding rear view mirrors
ProCarManuals.com

Part 1Headlights and turn signals51
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-4
Lights, Wipers
and Defogger

Headlights and turn signals

Emergency flashers

Instrument panel light control

Front fog lights

Interior lights

Personal lights

Ignition switch light

Luggage compartment light

Windshield wipers and washer

Rear window wiper and washer

Rear window defogger
HEADLIGHTS
To turn on the following lights: Twist
the headlight/turn signal lever knob.
Position 1ÐParking, tail, license plate,
side marker and instrument panel lights
Position 2ÐHeadlights and all of the
above
The lights automatically turn off when the
driver's door is opened with the ignition
turned off. To turn them on again, turn the
key to the ONº position or actuate the
headlight switch. If you are going to park
for over one week, make sure the head-
light switch is off.
NOTICE
To prevent the battery from being discharged, do not leave the lights
on for a long period when theengine is not running.
Daytime running light system (Canada
only)
The headlights turn on when the parking
brake is released with the engine started,
even with the light switch in the OFFº
position. They will not go off until the igni-
tion switch is turned off.
To turn on the other exterior lights and in-
strument panel lights, twist the knob to the
position 1.
Under the daytime running light system,
the headlights turn on at reduced intensi-
ty. Twist the knob to the position 2 to turn
to full intensity for driving at night.
