1997 TOYOTA CELICA Owners Manual

108
Heating
For best results, set controls to:Fan speedÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone)
Air intakeÐ FRESH (outside air)
Air flowÐ FLOOR
Air Conditioning ÐOFF

For quick heating, select recirculated
air for a few minutes. To keep the win-
dows from fogging, select fresh after
the vehicle interior has been warmed.

Press the A/Cº button on for dehumid-
ified heating.

Choose floor/windshield air flow to
heat the vehicle interior while defrost-
ing or defogging the windshield. Air conditioning
For best results, set controls to:
Fan speedÐAny setting except OFFº
Temperature Ð Towards COLD
(blue zone)
Air intakeÐ FRESH (outside air)
Air flowÐ PANEL
Air Conditioning ÐON
For quick cooling, move the air intake
selector to recirculate for a few min-
utes.
Ventilation
For best results, set controls to:
Fan speedÐAny setting except OFFº
Temperature Ð Towards COLD
(blue zone)
Air intakeÐ FRESH (outside air)
Air flowÐ PANEL
Air conditioning ÐOFF
Defogging and defrosting
The inside of the windshield
For best results, set controls to:
Fan speedÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone) to heat;
COLD (blue zone)
to cool
Air intake -FRESH (outside air)
Air flow -WINDSHIELD
Vehicles with A/Cº button-
Pressing the windshield button turns on
the defroster-linked air conditioning. At
this time, the A/Cº button indica tor comes
on regardless of whether or not the A/Cº
button is pressed in. This is to clean up the
front view more quickly.
When the A/Cº button is not pressed in,
pressing another airflow button turns off
the air conditioning.

On humid days, do not blow cold air on
the windshieldÐthe difference be-
tween the outside and inside tempera-
tures could make the fogging worse.
ProCarManuals.com

109
The outside of the windshield
For best results, set controls to:Fan speedÐAny setting except OFFº
Temperature Ð Towards WARM
(red zone)
Air intakeÐ FRESH (outside air)
Air flowÐ WINDSHIELD
Vehicles with A/Cº buttonÐ
Turning the air flow control knob to wind-
shield position turns on the defroster-
linked air conditioning. At this time, the
A/Cº button indicator comes on regard-
less of whether or not the A/Cº button is
pressed in. This is to clean up the front
view more quickly.
When the A/Cº button is not pressed in,
moving the air flow control lever to anoth-
er position turns off the air conditioning.

To heat the vehicle interior while de-
frosting the windshield, choose floor/
windshield air flow.
If air flow control is not satisfactory, check
the instrument panel vents. The instru-
ment panel vents may be opened or
closed as shown.
ÐInstrument panel vents
ProCarManuals.com

11 0ProCarManuals.com

Part 1Clock111
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1-8
Other equipment

Clock

Cigarette lighter and ashtray

Glovebox

Auxiliary

Cup holder

Luggage cover

Floor mat
The digital clock indicates the time.
The key must be in the ``ACCº or ``ON''
position.
To reset the hour: Push the Hº button.
To reset the minutes: Push the Mº button.
If quick adjustment to a full hour is de-
sired, push the :00º button.
For example, if the :00º button is de-
pressed when the time is between
1:01Ð1:29, the time will change to 1:00.
If the time is between 1:30Ð1:59, the time
will change to 2:00. Once the electrical power source has
been disconnected from the clock, the
time is automatically set to 1:00 (one
o'clock).
When the instrument panel lights are
turned on, the brightness of the time indi-
cation will be reduced.
ProCarManuals.com

11 2
CIGARETTE LIGHTER
To use the cigarette lighter, press it in.
When it becomes heated, it automati-
cally pops out ready for use.
If the engine is not running, the key must
be in the ºACCº position.
Do not hold the cigarette lighter pressed
in.
Use a Toyota genuine cigarette lighter or
equivalent for replacement.ASHTRAY
To use the ashtray, open the cover.
When finished with your cigarette, thor-
oughly extinguish it in the ashtray to pre-
vent other cigarette butts from catching
fire. After using the ashtray, close the ash-
tray cover completely.
To remove the ashtray, open the ashtray
cover and pull it out.To reduce the chance of injury in
case of an accident or sudden stop
while driving, always close the ash-
tray cover completely after using.
CAUTION
!
To use the glovebox, do this.
To open: Pull the lever.
With the instrument panel lights on, the
glovebox light will come on when the glo-
vebox is open.
To lock: Insert the master key and turn it
clockwise.
To reduce the chance of injury in
case of an accident or sudden stop,
always keep the glovebox door
closed while driving.
CAUTION
!
Cigarette lighter and ashtray Glovebox
ProCarManuals.com

11 3
To open the auxiliary box, press on the
knob and pull out the box lid.
To reduce the chance of injury in
case of an accident or a sudden
stop, always keep the auxiliary box
closed while driving. CAUTION
!
The cup holder is designed for holding
cups or drink-cans fit snugly in its
holes.
To use the cup holder, pull it out.
When the cup holder is pulled out to the
first click, you can also use the ashtray.


Do not place anything else on the
cup holder, as such items may be
thrown about and possibly injure
people in the vehicle during sud-
den braking or an accident.

Keep the cup holder shut when not
in use.
CAUTION!
Auxiliary box Cup holder Luggage cover
ProCarManuals.com

11 4
When you open the back door, the lug-
gage cover tilts up for easy access to
the luggage compartment.
For additional luggage space, unhook the
cords and lift the cover out of the retain-
ers.
ProCarManuals.com

11 5
Use a floor mat of the correct size.
If the floor mat has a hole, then it is de-
signed for use with a locking clip. Fix the
floor mat and locking clip into the hole in
the floor carpet.
Make sure the floor mat is properly
placed on the floor carpet. If the
floor mat slips and interferes with
the movement of the pedals during
driving, it may cause an accident.CAUTION
!
Floor mat
