1997 TOYOTA CELICA Owners Manual

139
4. Make the cable connection in the or-
der a, b, c, d.
a. Connect the clamp of the positive (red)
jumper cable to the positive (+) terminal
on the discharged battery.
b. Connect the clamp at the other end of
the positive (red) jumper cable to the posi-
tive (+) terminal on the booster battery.c. Connect the clamp of the negative
(black) cable to the negative (-) terminal
on the booster battery.
d. Connect the clamp at the other end of
the negative (black) jumper cable to a sol-
id, stationary, unpainted, metallic point of
the vehicle with the discharged battery.
The recommended connecting points are
shown in the following illustrations:Connecting point for 7A-FE engine
Connecting point for 5S-FE engine
ProCarManuals.com

140
Do not connect it to or near any part that
moves when the engine is cranked.
NOTICE
When making the connections, to avoid serious injury, do not lean
over the battery or accidentally letthe jumper cables or clamps touchanything except the correct batteryterminals or the ground.
5. Start your engine in the normal way. Af-
ter starting, run it at about 2000 rpm for
several minutes with the accelerator ped-
al lightly depressed.
6. Carefully disconnect the cables in the
exact reverse order: the negative cable
and then the positive cable.
7. Carefully dispose of the battery cover
clothsÐthey may now contain sulfuric
acid.
8. If removed, replace all the battery vent
plugs.
If the cause of your battery discharging is
not apparent (for example, lights left on),
you should have it checked. If your engine stalls while driving
0
1. Reduce your speed gradually, keep-
ing a straight line. Move cautiously off the
road to a safe place.
2. Turn on your emergency flashers.
3. Try starting the engine again.
If the engine will not start, see If your ve-
hicle will not startº.
If the engine is not running, the
power assist for the brakes and
steering will not work so steering
and braking will be much harder
than usual. CAUTION
!
If your engine coolant temperature
gauge indicates overheating, if you
experience a loss of power, or if you
hear a loud knocking or pinging noise,
the engine has probably overheated.
You should follow this procedure
0
1. Pull safely off the road, stop the ve-
hicle and turn on your emergency flash-
ers. Put the transmission in Pº (automat-
ic) or neutral (manual) and apply the
parking brake. Turn off the air conditioning
if it is being used.
2. If coolant or steam is boiling out of the
radiator or reservoir, stop the engine. Wait
until the steam subsides before opening
the hood. If there is no coolant boiling over
or steam, leave the engine running and
make sure the electric cooling fan is oper-
ating. If it is not, turn the ignition off.
To help avoid personal injury, keep
the hood closed until there is no
steam. Escaping steam or coolant is
a sign of very high pressure. CAUTION
!
3. Visually check to see if the engine drive
belt (water pump belt) is broken or loose.
Look for obvious coolant leaks from the ra-
diator, hoses, and under the vehicle. How-
ever, note that water draining from the air
conditioning is normal if it has been used.
If your engine stalls while
driving
If your vehicle overheats
(7A-FE engine)
ProCarManuals.com

141
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.CAUTION
!
4. If the engine drive belt is broken or the
coolant is leaking, stop the engine imme-
diately. Call a Toyota dealer for assis-
tance.
5. If the engine drive belt is O.K. and
there are no obvious leaks, check the
coolant reservoir. If it is dry,
add coolant to
the reservoir while the engine is running.
Fill it about half full.
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure. CAUTION
!
6. After the engine coolant temperature
has cooled to normal, again check the
coolant
level in the reservoir. If necessary,
bring it up to half full again. Serious cool-
ant loss indicates a leak in the system.
You should have it checked as soon as
possible at your Toyota dealer. If your engine coolant temperature
gauge indicates overheating, if you
experience a loss of power, or if you
hear a loud knocking or pinging noise,
the engine has probably overheated.
You should follow this procedure
0
1. Pull safely off the road, stop the ve-
hicle and turn on your emergency flash-
ers. Put the transmission in Pº (automat-
ic) or neutral (manual) and apply the
parking b rake. Turn off the air conditioning
if it is being used.
2. If coolant or steam is boiling out of the
radiator or reservoir, stop the engine. Wait
until the steam subsides before opening
the hood. If there is no coolant boiling over
or steam, leave the engine running and
make sure the electric cooling fan is oper-
ating. If it is not, turn the ignition off.
To help avoid personal injury, keep
the hood closed until there is no
steam. Escaping steam or coolant is
a sign of very high pressure. CAUTION
!
3. Look for obvious coolant leaks from
the radiator, hoses, and under the vehicle.
However, note that water draining from
the air conditioning is normal if it has been
used.
When the engine is running, keep
hands and clothing away from the
moving fan and engine drive belts.
CAUTION
!
4. If the coolant is leaking, stop the en-
gine immediately.
Call a Toyota dealer for
assistance.
5. If there are no obvious leaks, check
the coolant reservoir. If it is dry, add cool-
ant to the reservoir while the engine is
running. Fill it about half full.
Do not attempt to remove the radiator
cap when the engine and radiator are
hot. Serious injury could result from
scalding hot fluid and steam blown
out under pressure. CAUTION
!
6. After the engine coolant temperature
has cooled to normal, again check the
coolant
level in the reservoir. If necessary,
bring it up to half full again. Serious cool-
ant loss indicates a leak in the system.
You should have it checked as soon as
possible at your Toyota dealer.
If your vehicle overheats
(5S-FE engine)
ProCarManuals.com

142
1. Reduce your speed gradually, keep-
ing a straight line. Move cautiously off the
road to a safe place well away from the
traffic. Avoid stopping on the center divid-
er of a highway. Park on a level spot with
firm ground.
2. Stop the engine and turn on your
emergency flashers.
3. Firmly set the parking brake and put
the transmission in Pº (automatic) or re-
verse (manual).
4. Have everyone get out of the vehicle
on the side away from traffic.
5. Read the following instructions thor-
oughly.
CAUTION!
When jacking, be sure to observe the
following to reduce the possibility of
personal injury:

Follow jacking instructions.

Use the jack only for lifting your ve-
hicle during wheel changing.

Never get beneath the vehicle when
supported by a j ack.

Do not start or run the engine while
your vehicle is supported by the
jack.
NOTICE
Do not continue driving with a deflated tire. Driving even a short
distance can damage a tire beyondrepair.
Compact spare tire
The compact spare tire is designed for
temporary emergency use only.
The compact spare tire is identified by the
distinctive wording TEMPORARY USE
ONLYº molded into the side wall of the tire.
The standard tire should be repaired and
replaced as soon as possible.
To keep the compact spare tire notice-
able, do not hide the wheel by a wheel
cover or such.
If you have a flat tireÐ
ProCarManuals.com

143
The compact spare tire saves space in
your luggage compartment, and its lighter
weight helps to i mprove fuel economy and
permits easier installation in case of a flat
tire.
The compact spare tire can be used many
times, if necessary. It has tread life of up
to 4800 km (3000 miles) depending on
road conditions and your driving habits.
When tread wear indicators appear on the
tire, replace the tire.
See also the tire section in Chapter 7-2 for
details on the tread wear indicators and
other service infomation.

The compact spare tire was de-
signed especially for your Toyota.
Do not use it on any other vehicle.

Do not exceed 80 km/h (50 mph)
when driving with the compact
spare tire.

Avoid sudden acceleration, sud-
den deceleration, and sharp turns
with the compact spare tire. CAUTION
!
NOTICE
Your ground clearance is reduced when the compact spare tire is
installed so avoid driving overobstacles and drive slowly onrough, unpaved roads and speedbumps. Also, do not attempt to gothrough an automatic car wash asthe vehicle may get caught,
resulting in damage.
With a compact spare tire
Without a compact spare tire
ÐRequired tools and spare
tire
ProCarManuals.com

144
1. Get the required tools and sparetire.
1 Jack handle
2 Jack
3 Tool bag (Canada)
4 Spare tire
5 Wheel nut wrench (U.S.A.)
To prepare yourself for an emergency,
you should familiarize yourself with the
use of the jack, each of the tools and their
storage locations.
Turn the jack joint by hand.
To remove: Turn the joint in direction 1 un-
til the jack is free.
To store: Turn the joint in direction 2 until
the jack is firmly secured to prevent it fly-
ing forward during a collision or sudden
braking.To remove the spare tire:
1. Loosen the nut and remove it.
2. Remove the spare tire cover.
3. Loosen the bolt and remove it.
4. Remove the spacer.
Then t ake the spare tire out of the vehicle.
When storing the spare tire, put it in place
with the outer side of the wheel facing up.
Then secure the tire by repeating the
above removal steps in reverse order to
prevent it from flying forward during a col-
lision or sudden braking.
ProCarManuals.com

145
2. Block the wheel diagnoally oppo-site the flat tire to keep the vehicle
from rolling when it is jacked up.
When blocking the wheel, place a wheel
block from the front for the front wheels or
from the rear for the rear wheels.3. Remove the wheel ornament.
Pry off the wheel ornament, using the bev-
eled end of the wheel nut wrench as
shown.
Do not try to pull the ornament by
hand. Take due care in handling the
ornament to avoid unexpected
personal injury. CAUTION
!
4. Loosen all the wheel nuts.
Always l
oosen the wheel nuts before rais-
ing the vehicle.
The nuts turn counterclockwise to loosen.
To get maximum leverage, fit the wrench
to the nut so that the handle is on the right
side, as shown above. Grab the wrench
near the end of the handle and pull up on
the handle. Be careful that the wrench
does not slip off the nut.
Do not remove the nuts yetÐjust unscrew
them about one-half turn.
ÐRemoving wheel ornament
(steel wheels only) ÐLoosening wheel nuts
ÐBlocking the wheel
ProCarManuals.com

146
5. Position the jack at the correct jack
points as shown.
Make sure the jack is positioned on a level
and solid place.6. After making sure that no one is in
the vehicle, raise it high enough so
that the spare tire can be installed.
Remember you will need more ground
clearance when putting in the spare tire
than when removing the flat tire.
To raise the vehicle, insert the jack handle
into the jack (it is a loose fit) and turn it
clockwise. As the j ack touches the vehicle
and begins to lift, double-check that it is
properly positioned.
Never get under the vehicle when
the vehicle is supported by the jack
alone. CAUTION
!
ÐPositioning the jack ÐRaising your vehicle
ProCarManuals.com
