1997 TOYOTA CELICA Owners Manual

147
7. Remove the wheel nuts and change
tires.
Lift the flat tire straight off and put it aside.
Roll the spare wheel into position and
align the holes in the wheel with the bolts.
Then lift up the wheel and get at least the
top bolt started through its hole. Wiggle
the tire and press it back over the other
bolts.Before putting on wheels, remove any
corrosion on the mounting surfaces with a
wire brush or such. Installation of wheels
without good metal-to-metal contact at
the mounting surface can cause wheel
nuts to loosen and eventually cause a
wheel to come off while driving. Therefore
after the first 1600 km (1000 miles), check
to see that the wheel nuts are tight.8. Reinstall all the wheel nuts finger
tight.
Reinstall the wheel nuts (tapered end in-
ward) and tighten them as much as you
can by hand. Press back on the tire back
and see if you can tighten them more.
ÐChanging wheels ÐReinstalling wheel nuts
ProCarManuals.com

148
9. Lower the vehicle completely and
tighten the wheel nuts.
Turn the jack handle counterclockwise to
lower the vehicle.
Use only the wheel nut wrench and turn it
clockwise to tighten the nuts. Do not use
other tools or any additional leverage oth-
er than your hands, such as a hammer,
pipe or your foot. Make sure the wrench is
securely engaged over the nut.
Tighten each nut a little a time in the order
shown. Repeat the process until all the
nuts are tight.10. Reinstall the wheel ornament.
Align the cutout of the wheel ornament-
with the valve stem as shown. Then tap it
firmly with the side or heel of hand to snap
it into place.
Take due care in handling the
ornament to avoid unexpected
personal injury. CAUTION
!
11. Check the air pressure of the
replaced tire.
Adjust
the air pressure to the specification
designated in Part 8. If the pressure is
lower, drive slowly to the nearest service
station and fill to the correct pressure.
Do not forget to reinstall the tire inflation
valve cap as dirt and moisture could get
into the valve core and possibly cause air
leakage. If the cap is missing, have a new
one put on as soon as possible.
12.Restow all the tools, jack and flat
tire securely.
As soon as possible after changing
wheels, tighten the wheel nuts to the
torque specified in Part 8 with a torque
wrench, have a technician repair the flat
tire and replace the spare tire with it.
Before driving, make sure all the
tools, jack and flat tire are securely
in place in their storage location to
reduce the possibility of personal
injury during a collision or sudden
braking. CAUTION
!
ÐLowering your vehicle
ÐReinstalling wheel ornament
(steel wheels only) ÐAfter changing wheels
ProCarManuals.com

149
If towing is necessary, we recommend
you to have it done by your Toyota
dealer or a commercial tow truck ser-
vice. In consultation with them, have
your vehicle towed using either (a) or
(b).
Only when you cannot receive a tow-
ing service from a Toyota dealer or
commercial tow truck service, tow
your vehicle carefully in accordance
with the instructions given in
ÐEmergency towingº in this part.
Proper equipment will help ensure that
your vehicle is not damaged while being
towed. Commercial operators are gener-
ally aware of the state/provincial and local
laws pertaining to towing.
Your vehicle can be damaged if it is towed
incorrectly. Although most operators
know the correct procedure, it is possible
to make a mistake. To avoid damage to
your vehicle, make sure the following few
precautions are observed. If necessary,
show this page to the tow truck driver.
TOWING PRECAUTIONS:
Use a safety chain system for all towing,
and abide by the state/provincial and local
laws. The wheels and axle on the ground
must be in good condition. If they are
damaged, use a towing dolly. (a) Towing with wheel lift type truck
From frontÐRelease the parking brake.
NOTICE
When lifting wheels, take care to ensure adequate ground clearance
for towing at the opposite end of theraised vehicle. Otherwise, the
bumper and/or underbody of thetowed vehicle will be damaged
during towing.
From rearÐ

Manual transmission:
We recommend using a towing dolly
under the front wheels. If you do not
use a towing dolly, place the ignition
key in the ACCº position and put the
transmission in neutral.
NOTICE
Do not tow with the key removed or in the LOCKº position when
towing from the rear without atowing dolly. The steering lockmechanism is not strong enough to
hold the front wheels straight.
If your vehicle needs to be
towedÐ
ProCarManuals.com

150

Automatic transmission:
Use a towing dolly under the front
wheels.
NOTICE
Never tow a vehicle with an automatic transmission from the
rear with the front wheels on theground, as this may cause seriousdamage to the transmission.
(b) Using flat bed truck
(c) Towing with sling type truck
NOTICE
Do not tow with sling type truck, either from the front or rear. This
may cause body damage.
If towing is necessary, we recommend
you to have it done by your Toyota
dealer or a commercial tow truck ser-
vice.
If towing service is not available in an
emergency, your vehicle may be tem-
porarily towed by a cable or chain se-
cured to either emergency towing eye-
lets under the vehicle. Use extreme
caution when towing vehicle.
A driver must be in the vehicle to steer it
and operate the brakes.
Towing in this manner may be done only
on hard-surfaced roads for a short dis-
tance and at low speeds. Also, the
wheels, axles, drive train, steering and
brakes must all be in good condition.
ÐEmergency towing
ProCarManuals.com

151
CAUTION!
Use extreme caution when towing
vehicles. Avoid sudden starts or
erratic driving maneuvers which
would place excessive stress on the
emergency towing hook or eyelet and
towing cable or chain. The hook or
eyelet and towing cable or chain may
break and cause serious injury or
damage.
NOTICE
Use only a cable or chain specifically intended for use in towing vehicles.
Securely fasten the cable or chain tothe towing eyelet provided.
Before towing, release the parking brake
and put the transmission in neutral (manu-
al) or Nº (automatic). The key must be in
ACCº (engine off) or ONº (engine run-
ning).
CAUTION!
If the engine is not running, the power
assist for the brakes and steering will
not work so steering and braking will
be much harder than usual.
If you cannot shift the selector lever
out of Pº position to other positions
even though the brake pedal is de-
pressed, use the shift lock override
button as follows:
1. Turn the ignition key to LOCKº
position. Make sure the parking brake
is set.
2. Pry up the cover with a flat-bladed
screwdriver or equivalent.3. Insert your finger into the hole to
push down the shift lock override but-
ton. You can shift out of Pº position
only while pushing the button.
4. Shift into Nº position.
5. Insert the cover.
6. Start the engine. For your safety,
keep the brake pedal depressed.
Be sure to have the system checked by
your Toyota dealer as soon as possible.
If you cannot shift automatic
transmission selector lever
ProCarManuals.com

152
If the power mechanism for the con-
vertible top should become inopera-
tive, you may operate the convertible
top manually. Have the system
checked as soon as possible at your
Toyota dealer.
RAISING THE CONVERTIBLE TOP
MANUALLY
1. Open the trunk and remove the cov-
er from the front trim. Push the manual
control switch on the MANUALº side.
2. Lower the sun visors. Check that all
the side windows and quarter win-
dows are lowered.
If the battery is discharged and the win-
dows cannot be lowered, open both side
doors.3. From the rear seat, place one hand
on top of the rear seatback. With the
other hand, grasp the convertible top
edge at the center and slowly raise the
top half way.4. Move to the front seat, grasp the
handle which is under the convertible
top and pull the top fully forward.
If the convertible top does not
raise or lower
ProCarManuals.com

153
5. While holding the convertible top
against the windshield frame, push
the latch handles fully forward till they
are hooked.
Visually check that the latch handles are
fully seated in the strikers. Also, pull on
the convertible top side rails to make sure
the top is securely hooked.6. Return the manual control switch
to the opposite side of the MANUALº
position, attach the cover, and close
the trunk. Raise all the side windows,
quarter windows, and sun visors.LOWERING THE CONVERTIBLE TOP
MANUALLY
1. Open the trunk and remove the cov-
er from the front trim. Push the manual
control switch on the MANUALº side.
ProCarManuals.com

154
2. Lower all the side windows, quarter
windows, and sun visors. Then pull
the latch handles fully backward.
If the battery is discharged and the win-
dows cannot be lowered, open both side
doors.3. Place your palms under either front
convertible top side rail around it's
center and lower the convertible top
all the way down. Raise the sun visors.
To prevent personal injury, do not
grasp the convertible top side rails. CAUTION
!
4. Return the manual control switch
to the opposite side of the MANUALº
position, attach the cover, and close
the trunk.
