1997 TOYOTA CELICA Owners Manual

155
Many Toyota dealers can make a new
key if you can give them the key num-
ber.
See the suggestion given in Keysº in
Chapter 1-2.
If your keys are locked in the vehicle and
you cannot get a duplicate, many Toyota
dealers can still open the door for you, us-
ing their special tools. If you must break a
window to get in, we suggest breaking the
smallest side window because it is the
least expensive to replace. Be extremely
cautious to avoid cuts from the glass.
If you lose your keys
ProCarManuals.com

156ProCarManuals.com

Part 5Protecting your Toyota from
corrosion157
CORROSION
PREVENTION
AND APPEARANCE
CARE

Protecting your Toyota from
corrosion

Washing and waxing your
Toyota

Cleaning the interior
Toyota, through its diligent research, de-
sign and use of the most advanced
technology available, has done its part to
help prevent corrosion and has provided
you with the finest quality vehicle
construction. Now, it is up to you. Proper
care of your T oyota can help ensure long-
term corrosion prevention.
The most common causes of corro-
sion to your vehicle are:

The accumulation of road salt, dirt and
moisture in hard-to-reach areas un-
der the vehicle.

Chipping of paint, or undercoating
caused by minor accidents or by
stones and gravel.
Care is especially important if you live
in particular areas or operate your ve-
hicle under certain environmental
conditions:

Road salt or dust control chemicals will
accelerate corrosion, as will the pres-
ence of salt in the air near the sea-
coast or in areas of industrial pollution.

High humidity accelerates corrosion
especially when temperatures range
just above the freezing point.

Wetness or dampness to certain parts
of your vehicle for an extended period
of time, may cause corrosion even
though other parts of the vehicle may
be dry.

High temperatures will cause corrosion
to those components of the vehicle
which are prevented from quick-drying
due to lack of proper ventilation.
The above signifies the necessity to keep
your vehicle, particularly the underside,
as clean as possible and to repair any
damage to paint or protective coatings as
soon as possible.
To help prevent corrosion on your To-
yota, follow these guidelines:
Wash your vehicle frequently: It is, of
course, necessary to keep your vehicle
clean by regular washing, but to prevent
corrosion, the following points should be
observed:

If you drive on salted roads in the winter
or if you live near the ocean, you should
hose off the undercarriage at least
once a month to minimize corrosion.

High pressure water or steam is effec-
tive for cleaning the vehicle's under-
side and wheel housings. Pay particu-
lar attention to these areas as it is
difficult to see all the mud and dirt. It will
do more harm than good to simply wet
the mud and debris without removing
them. The lower edge of doors, rocker
panels and frame members have drain
holes which should not be allowed to
clog with dirt as trapped w ater in these
areas can cause corrosion.
ProCarManuals.com

158

Wash the underside of the vehicle
thoroughly when winter is over.
See Washing and waxing your Toyotaº
for more tips.
Check the condition of your vehicle's
paint and trim. If you find any chips or
scratches in the paint, touch them up im-
mediately to prevent corrosion from start-
ing. If the chips or scratches have gone
through the bare metal, have a qualified
bodyshop make the repair.
Check the interior of your vehicle. Wa-
ter and dirt can accumulate under the floor
mats and could cause corrosion. Occa-
sionally check under the mats to make
sure the area is dry. Be particularly careful
when transporting chemicals, cleansers,
fertilizers, salt, etc; these should be trans-
ported in proper containers. If a spill or
leak should occur, immediately clean and
dry the area.
Use mud shields on your wheels. If you
drive on salted or gravel roads, mud
shields help protect your vehicle. Full-
size shields, which come as near to the
ground as possible, are the best. We rec-
ommend that the fittings and the area
where the shields are installed be treated
to resist corrosion. Your Toyota dealer will
be happy to assist in supplying and instal-
ling the shields if they are recommended
for your area. Do not park your vehicle in a damp,
poorly ventilated garage.
If you wash
your vehicle in the garage, or if you drive
it in covered with water or snow, your ga-
rage may be so damp it will cause corro-
sion. Even if your garage is heated, a wet
vehicle can corrode if the ventilation is
poor. Washing your Toyota by hand
Work in the shade and wait until the ve-
hicle body is not hot to the touch.
CAUTION
When cleaning under floor or chas-
sis, be careful not to injure your
hands.!
Convertible models-For washing instruc-
tions for the convertible top, see Convert-
ible topº.
1. Rinse off loose dirt with a hose. Re-
move any mud or road salt from the un-
derside of the vehicle or in the wheel
wells.
Washing and waxing your
Toyota
ProCarManuals.com

159
Convertible models: Spray water on the
side windows or top seals from above, at
a 455 angle to the ground.
NOTICE
(convertible models): Do not spray water at side windowsand top seals in a way which maycause water to enter the vehicle.
2. Wash with a mild car-wash soap,
mixed according to the manufacturer's in-
structions. Use a soft cotton mitt and keep
it wet by dipping it frequently into the wash
water. Do not rub hard-let the soap and
water remove the dirt. Aluminum
wheels: Use only a mild soap or
neutral detergent.
Plastic bumpers: Wash carefully. Do not
scrub w ith abrasive cleaners. The bumper
faces are soft.
Road tar: Remove with turpentine or
cleaners that are marked safe for painted
surfaces.
NOTICE
Do not use gasoline or strong solvents, which may be toxic or
cause damage.
3. Rinse thoroughly Ð dried soap can
cause streaking. In hot weather you may
need to rinse each section right after you
wash it.
4. To prevent water spots, dry the ve-
hicle using a clean soft cotton towel. Do
not rub or press hard Ð you might scratch
the paint.
Automatic car wash
Coupe and liftback models may be
washed in an automatic car wash, but re-
member that the paint can be scratched
by some type of brushes, unfiltered wash-
ing water, or the washing process itself.
Scratching reduces paint durability and
gloss, especially on darker colors. The
manager of the car wash should be able
to advise you whether the process is safe
for the paint on your vehicle.
NOTICE
(convertible models): Do not run convertible modelsthrough automatic car washer orpossible damage to the convertible
top may result.
Waxing your Toyota
Polishing and waxing is recommend-
ed to maintain the original beauty of
your Toyota's finish.
1. Always wash and dry the vehicle be-
fore you begin waxing, even if you are us-
ing a combined cleaner and wax.
2. Use a good quality polish and wax. If
the finish has become extremely weath-
ered, use a car-cleaning polish, followed
by a separate wax. Carefully follow the
manufacturer 's instructions and precau-
tions. Be sure to polish and wax the
chrome trim as well as the paint.
3. Wax the vehicle again when water
does not bead but remains on the surface
in large patches.
NOTICE
Always remove the plastic bumpers if your vehicle is re-painted and
placed in a high heat paint waxingbooth. High temperatures could
damage the bumpers.
ProCarManuals.com

160
Convertible top
Wash using mild soap suds, lukewarm
water and a sponge.
NOTICE
Do not use harsh or abrasive cleaners or bleaching agents on the
top material or damage may result.
If further cleaning is required after using
soap and water, a mild foaming cleaner
can be used. First, rinse the top, then use
a mild foaming cleaner on the entire top.
Scrub with a small soft bristle handbrush.
Add water as needed until the cleaner
gets soapy. Use a cloth or sponge to re-
move dirt so it will not be ground into the
top. Be careful to keep any cleaner from
drying on the body paint as it may cause
streaks.
After the top has been cleaned, rinse ve-
hicle with cl ean water to remove all traces
of cleaner.
After cleaning, always make sure the top
is completely dry before your lowered it.
Lowering the top while wet or damp may
cause interior water damage, water stains
or mildew of the top material.
CAUTION
Do not wash the vehicle floor with
water, or allow water to get into the
floor when cleaning the vehicle in-
terior or exterior. W ater may get into
audio components or other electri-
cal components above or under the
floor carpet (or mat) and cause a
malfunction; and it may cause body
corrosion.!
Vinyl interior
The vinyl upholstery may be easily
cleaned with a mild soap or detergent
and water.
First vacuum over the upholstery to re-
move loose dirt. Then, using a sponge or
soft cloth, apply the soap solution to the vi-
nyl. After allowing it to soak in for a few
minutes to loosen the dirt, remove the dirt
and wipe off the soap with a clean damp
cloth. If all the dirt does not come off, re-
peat the procedure. Commercial foam-
ing-type vinyl cleaners are also available
which work well. Follow the manufactur-
er's instructions.
NOTICE
Do not use solvent, thinner, gas- oline or window cleaner on the in-
terior.
Carpets
Use a good foam-type shampoo to
clean the carpets.
Begin by vacuuming thoroughly to re-
move as much dirt as possible. Several
types of foam cleaners are available,
some are in aerosol cans and others are
powders or liquids which you mix with wa-
ter to produce a foam. To shampoo the
carpets, use a sponge or brush to apply
the foam. Rub in overlapping circles.
Do not apply water ± the best results are
obtained by keeping the carpet as dry as
possible. Read the shampoo instructions
and follow them closely.
Seat belts
The seat belts may be cleaned with
mild soap and water or with lukewarm
water.
Use a cloth or sponge. As you are clean-
ing, check the belts for excessive wear,
fraying, or cuts.
NOTICE
Do not use dye or bleach on the belts-it may weaken them.
Windows
The windows may be cleaned with any
household window cleaner.
Cleaning the interior
ProCarManuals.com

161
When cleaning the inside of thewindows, be careful not to scratch
or damage the heater wires on therear window.
NOTICE
Air conditioning control panel, car au-
dio, instrument panel, console panel,
and switches
Use a soft damp cloth for cleaning.
Soak a clean soft cloth in water or luke-
warm water then lightly wipe off any dirt.

Do not use organic substances(solvents, karosene, alcohol, gas-
oline, etc.) or alkaline or acidicsolutions. These chemicals can
cause discoloring, staining orpeeling of the surface.
If you use cleaners or polishingagents, make sure their ingredi-
ents do not include the sub-stances mentioned above.
If you use a liquid car freshener,do not apply the liquid onto the ve-
hicle's interior surfaces. It may contain the ingredients men-
tioned above. Immediately cleanany spill using the method men-
tioned above.
NOTICE
Leather Interior
The leather uphostery may be cleaned
with neutral detergent for wool.
Remove dirt using a soft cloth dampened
with 5 % solution of neutral detergent for
wool. Then throughly wipe off all traces of
detergent with a clean damp cloth.
After cleaning or whenever any part of the
leather gets wet, dry with a soft clean
cloth. Allow the leather to dry in a vente-
lated shaded area.

If a stain should fail to come outwith a neutral detergent, apply a
cleaner that does not contain anorganic solvent.
Never use organic substancessuch as benzine, alcohol or gaso-
line, or alkaline or acid solutionsfor cleaning the leather as these
could cause discoloring.
Use of a nylon brush or syntheticfiber cloth, etc. may scratch thefine grained surface of the leather.
Mildew may develop on soiled
leather upholstery. Be especially
careful to avoid oil spots. Try tokeep your upholstery always
clean.
NOTICE
Long exposure to direct sunlightmay cause the leather surface to
harden and shrink. Keep your ve-hicle in a shaded area, especially
in the summer.
The interior of your vehicle is apt
to heat up on hot summer days, soavoid placing on the upholsteryitems made of vinyl or plastic or
containing wax as these tend tostick to leather when warm.
Improper cleaning of the leather
upholstery could result in discol-oration or staining.
If you have any questions about the
cleaning of your Toyota, your local To-
yota dealer will be pleased to answer
them.
ProCarManuals.com

162ProCarManuals.com
