1997 FORD WINDSTAR Owners Manual

64
*
[AS12027(ALL)04/95]3.
Load discs into disc magazine slots (numbered 1 through 10)
one at a time with labeled surfaces upward, starting with
bottom slot number 1 (Figure 3).
[AS12030(ALL)05/95]
10-1/2 pica
art:0050267-A[AS12033(ALL)04/95]4.
Insert loaded disc magazine into chamber unit with the
arrow on top of the disc magazine pointing toward the
changer (Figure 4).Make sure magazine is fully inserted
into changer.
[AS12036(ALL)06/95]
7-1/2 pica art:0050268-A*
[AS12039(ALL)09/95]
NOTE: To remove one or more compact disc(s) from the disc
magazine, push the corresponding lever(s) (numbered
1 to 10 on the side of the disc magazine) to the left.
Disc(s) will partially come out for easy removal.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

Electronic Sound Systems
65
*
[AS12045(ALL)01/95]5.
Close unit by sliding changer panel door to the left.
[AS12048(ALL)05/95]
The Compact Disc Changer center floor console unit is now
ready to play using the controls of your High-Level Audio
System.
*
[AS12051(ALL)04/95]
How to Operate the Ford 10-CD Changer Using the
Controls on the Radio
[AS12054(ALL)07/95]
If your vehicle is equipped with the Ford 10-CD Changer
System, you can operate it through the controls of your
High-Level Audio System.
*
[AS12057(ALL)05/95]
Several of the controls on the radio operate in the same manner
in CD mode as they do in radio or cassette mode: turning the
power on, volume control and adjusting the bass, treble, speaker
balance or fade.
*
[AS12060(ALL)02/95]
How to begin CD Changer play
*
[AS12063(ALL)09/95]
NOTE: Radio power must be on to operate the Compact Disc
Changer.
[AS12066(ALL)04/95]
Push the ªPLAY PROGº button to begin CD play. (The radio
will revert to the CD mode when ªPLAY PROGº button is
pushed and there is no cassette stored or playing in the cassette
deck.) The 10-CD Changer will automatically begin playing the
first track (selection) of the first disc loaded in the trunk unit.
The display will indicate ªCD-##º for track number. Three
seconds after displaying ªTR-##º, the display will indicate
ª##-##º (CD number-Track number).
*
[AS12069(ALL)02/95]
How to change the disc being played
[AS12072(ALL)04/95]
When in the CD mode, you can change discs by pressing the
ªFFº button (to select the next discs) or the ªREWº button (to
select previous discs). Play willl begin on the first track of the
selected disc.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

66
*
[AS12075(ALL)04/95]
If either button is pressed and held, the CD Changer will
continue fast-forwarding or reversing through the discs in the
disc magazine. During these functions, the display will indicate
the disc number.
*
[AS12078(ALL)10/95]
How to change the track being played
*
[AS12081(ALL)02/96]
Press the right (
a) side of the ªSEEKº button to seek forward
to the next track of current disc. If the button is held and the
last track is reached, the disc changer will automatically begin
playing the last track of the current disc. After the last track has
been completed, the disc changer advances to the next disc and
begins play of track 1. The display indicates the track number
while seeking.
[AS12084(ALL)02/96]
Press the left (
b) side of the ªSEEKº button to seek in reverse
to the previous track on the current disc. If a selection has been
playing for three seconds or more and you press the left (
b)
side of the ªSEEKº button, the CD Changer will replay that
selection from the beginning.
*
[AS12087(ALL)04/95]
Operating the CD Compression feature
*
[AS12090(ALL)05/96]
The compression feature will bring soft and loud passages closer
together for a more consistent listening level.
[AS12093(ALL)04/95]
To turn the compression on, press the Dolby B noise reduction
kbutton. (While in the CD Changer mode, the Dolby button
controls the compression function.) When the compression
feature is activated, the display will indicate ªCº.
*
[AS12096(ALL)06/96]
HowtostopCDplay
[AS12099(ALL)03/96]
While in the CD Changer mode, press the ªEJCTº button to
stop CD play and resume radio play. Also, loading a cassette
into the cassette deck will stop CD play and begin cassette play.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

Electronic Sound Systems
67
*
[AS21050(ALL)08/95]
Rear Seat Radio Controls
*
[AS21055(ALL)08/95]
Using the Rear Seat Radio Controls
[AS21060(ALL)12/93]
Rear seat radio controls are standard equipment on all models.
*
[AS21065(ALL)12/93]
The rear seat radio controls are located behind the driver on the
left hand side of the vehicle. These controls duplicate several
radio functions of the radio and allow the use of headphones in
the vehicle.
[AS21068(ALL)04/95]
7-1/2 pica art:0060676-B
Rear Seat Radio Controls
*
[AS21070(ALL)06/95]
How to turn the rear seat radio controls on and off
[AS21075(ALL)04/96]
Press memory preset buttons ª1º and ª3º simultaneously on the
face of your radio to turn the rear seat radio controls on. A
headphones symbol (j) will appear in the display when the
rear seat controls are on. Press ª1º and ª3º simultaneously
again to turn rear seat radio controls off.
*
[AS21080(ALL)03/96]
How to adjust the volume
*
[AS21085(ALL)12/93]
Press the right (+) side of the ªVOLUMEº rocker switch to
increase volume, and push the left (-) side to decrease the
volume of the rear speakers.
[AS21090(ALL)09/95]
NOTE: Rear seat control volume can be set no higher than
current radio setting unless speakers are turned off.
See note underHow to turn speakers on and off.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

68
*
[AS21095(ALL)06/95]
Setting the AM or FM frequency band
*
[AS21100(ALL)06/95]
Push the ªBANDº button to change the frequency band.
*
[AS21105(ALL)06/95]
Using the ªMEMORYº button
*
[AS21110(ALL)06/95]
Push the ªMEMORYº button to access the station you have set
into memory button 1 on the face of the radio. Successively
pushing this button will access, numerically, all stations set into
the Station Memory Preset buttons (1 through 5).
*
[AS21115(ALL)06/95]
How to turn the speakers on and off
*
[AS21120(ALL)06/95]
When the rear seat controls are on, push the ªSPKRS ON-OFFº
button to turn all speakers off. Push again to turn all speakers
on.
[AS21125(ALL)04/96]
NOTE: Turning the ignition off, then on again will not turn
the speakers back on, if previously turned off by the
ªSPKRS ON-OFFº button on the rear seat controls.
*
[AS21130(ALL)06/95]
Using the ªSEEKº function
[AS21135(ALL)04/96]
Press the right (
a) side of the ªSEEKº rocker switch to seek to
the next radio station. Press the left (
b) side of the ªSEEKº
rocker switch to seek to the previous radio station.
*
[AS21140(ALL)09/95]
NOTE: When using the rear seat controls with a High-Level
Audio System, the ªSEEKº function on the rear seat
controls will also function with cassettes, seeking the
next (ªSEEK
aº) or previous (ª
bSEEKº) selection
on the tape.
*
[AS21145(ALL)06/95]
Using headphones with the rear seat controls
*
[AS21150(ALL)10/95]
Two 3.5 mm headphone jacks have been provided on the rear
seat controls. Plug headphone(s) into the provided jack(s) to
operate headphones.
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

Electronic Sound Systems
69
[AS21200(ALL)09/94]
33-1/2 pica
art:0060677-A
Electronic Stereo Radio
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

70
[AS21250(ALL)09/94]
33-1/2 pica
art:0060678-A
Electronic Stereo Radio with Cassette
File:04wnass.ex
Update:Mon Jul 8 14:13:42 1996

Electronic Sound Systems
71
%*
[AS21300(ALL)09/95]
Electronic Stereo and Stereo Cassette
Radios
*
[AS21400(ALL)03/96]
Using the Controls on Your New Radio
*
[AS21500(ALL)08/95]
How to turn the radio on and adjust the volume
*
[AS21701(ALL)10/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS21950(ALL)02/96]
Press the right (+) side of the ªVOLUMEº button to increase the
volume. Press the left (s) side of the button to decrease the
volume. Illuminated bars in the display show the relative
volume level.
*
[AS21975(ALL)02/96]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off, the volume will remain
in the position it was set at when radio power was
switched off.
*
[AS22100(ALL)03/96]
Selecting the AM or FM frequency band
*
[AS22225(ALL)02/96]
Push the ªAM/FMº button to select the desired frequency band.
Pushing the button more than once will alternate between AM,
FM1 and FM2. These functions are used with the station
memory buttons described underHow to tune radio stations.
*
[AS22300(ALL)02/96]
How to tune radio stations (Stereo Radio)
*
[AS22400(ALL)02/96]
There are three ways for you to tune in to a particular station.
You can manually locate the station by using the ªTUNEº
button, ªSEEKº the station or select the station by using the
memory preset buttons, which you can set to any desired
frequency.
