1997 FORD WINDSTAR Owners Manual

176
[SS14700(ALL)01/96]
24 pica art:0050170-D
Figure 2: Securing the detachable shoulder belt
[SS14800(ALL)12/95]
Refer to ªSeatsº in this section for information on removing and
installing seats.
[SS14900(ALL)12/95]
After re-installing the second row bench seat, make sure that the
safety belt is not twisted before you insert it into the detachable
anchor. A twisted safety belt may cause the retractor to work
improperly. Then insert the detachable anchor tongue into the
detachable anchor until you hear a ªsnapº and feel the latch
engage.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seatingan dSafet yRestraints
177
WARNING
Whe nreinstallin garea rsea tin you rvehicl eit mus tbe

178
*
[SS16100(ALL)01/96]
To switch the retractor from the emergency locking mode to the
automatic locking mode, perform the following steps:
*
[SS16200(ALL)02/96]1.
Buckle the lap/shoulder combination belt.
*
[SS16300(ALL)12/95]2.
Grasp the shoulder portion of the belt and pull downward
until all of the belt is extracted, and when allowed to retract,
a clicking sound will be heard. At this time, the belt retractor
is in the automatic locking mode (child restraint mode).
[SS16400(ALL)12/95]3.
A clicking sound will be heard as the belt is allowed to
retract. This indicates that the retractor is in the automatic
locking mode.
[SS16500(ALL)12/95]
NOTE: When the combination lap/shoulder belt is unbuckled
and allowed to retract completely, the retractor will
switch back to the vehicle sensitive (emergency)
locking mode. See detailed instructions under Safety
Seats for Children later in this chapter.
%*
[SS16600(ALL)12/95]
Lap Belts
*
[SS16700(ALL)12/95]
The lap belt in the center of the rear seat does not adjust
automatically. You must adjust it to fit snugly and as low as
possible around your hips. Do not wear it around your waist.
%*
[SS16800(ALL)01/96]
If you need to lengthen the belt, unfasten it and tip the belt
tongue at a right angle to the belt. Pull the belt tongue over
your lap until it reaches the buckle.
*
[SS16900(ALL)01/96]
If you need to shorten the belt, pull on the loose end of the
webbing until the belt fits snugly.
[SS17000(ALL)12/95]
To unfasten the belt, push the release button on the buckle.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

Seating and Safety Restraints
179
[SS17100(ALL)12/95]
10-1/2 pica
art:0050085-A
Unfastening the lap belt in the center rear seating position
%*
[SS17200(ALL)03/96]
Safety Belt Maintenance
*
[SS17300(ALL)02/96]
Check the safety belt systems periodically to make sure that
they work properly and are not damaged.
*
[SS17400(ALL)03/96]
All safety belt assemblies, including retractors, buckles, front
seat belt buckle support assemblies (slide bar) (if so equipped),
child safety seat tether bracket assemblies (if so equipped), and
attaching hardware, should be inspected after any collision. Ford
recommends that all safety belt assemblies used in vehicles
involved in a collision be replaced. However, if the collision was
minor and a qualified technician finds that the belts do not
show damage and continue to operate properly, they do not
need to be replaced. Safety belt assemblies not in use during a
collision should also be inspected and replaced if either damage
or improper operation is noted.
%*
[SS17700(ALL)02/96]
Safety Belt Extension Assembly
*
[SS17800(ALL)01/96]
For some people, the safety belt may be too short even when it
is fully extended. You can add about eight inches (20 cm) to the
belt length with a safety belt extension assembly (part number
611C22). Safety belt extensions are available at no cost from
your dealer.
File:06wnsss.ex
Update:Thu Jul 18 11:00:49 1996

180
WARNING
Failureto follo wthes einstruction swil laffec tthe
WARNING
Al loccupant sof th evehicle ,includin gthedriver ,should

Seatingan dSafet yRestraints
181
WARNING
Whe nusin gforward-facin gchil dseat smov ethe
WARNING
Do no tplac eobject sor moun tequipmen ton or nea rthe

182
WARNING
Do no tattemp tto service ,repair ,or modif ytheAi rBag

Seatingan dSafet yRestraints
183
WARNING
Severa lai rba gsyste mcomponent sge tho tafte rinflation.
