1997 FORD THUNDERBIRD Owners Manual

31
*
[AS04950( BC )02/96]
q
Adjusting speaker balance
[AS05000( BC )10/95]
Balance control allows you to adjust the
sound distribution between the right and left
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªBALº.
Push the top (+) side of the ªVOLUMEº
button to shift the sound to the right
speakers, and push the bottom (-) side to
shift the sound to the left speakers.
*
[AS05100( BC )04/96]
q
Adjusting speaker fader
[AS05200( BC )10/95]
Fade control allows you to adjust the sound
distribution between the front and rear
speakers. Push the ªAUDIOº button
repeatedly until the display reads ªFADEº.
Push the top (+) side of the ªVOLUMEº
button to shift the sound to the front
speakers, and push the bottom (-) side to
shift the sound to the rear speakers.
*
[AS05300( BC )10/95]
NOTE: Illuminated bars in the display show
relative levels of bass and treble, and
positions of speaker balance and fader
functions (left to right, front to rear).
%*
[AS06800( BC )10/95]
Using the Controls on Your New Compact
Disc Player
*
[AS07000( BC )03/96]
Your new Ford Compact Disc Player is capable
of playing 12 cmor8 cm discs, without an
adapter. The player operates when the power is
on and a disc is inserted (label side up). Handle
the disc by its edge only. (Be sure to read and
follow all of the care and cleaning instructions
underHow To Take Care of and Clean Your CD
Player and Discs.)
*
[AS07100( BC )09/95]
NOTE: If after you insert a disc, the disc is
ejected and ªERRORº begins scrolling
in the display, remove the disc and
reinsert it right side up (label side up).
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

32 [AS07200( BC )10/95]The digital display on your CD player will
either show the track (selection) number or the
elapsed time. (The display mode can be selected
by pressing the memory preset button #6.)
Indicators for play
b, stop
Xand compression
on (ªCº) are also in the display. (These features
are described later.)
*
[AS07300( BC )10/95]
Once a disc is inserted, operation of the CD
player will override that of the radio.
*
[AS07400( BC )09/95]
NOTE: The volume, bass, treble, balance and
fader controls on the radio are also
used with the CD player. Refer to
earlier operating instructions on these
controls.
*
[AS07500( BC )04/96]
How to insert a disc and begin play
*
[AS07550( BC )10/95]
Insert one disc,label side upinto the disc
opening. When inserted, the disc automatically
loads into the unit and play starts at the
beginning of the first track (selection).
*
[AS07600( BC )04/96]
When the disc reaches the end, the disc player
automatically returns to the beginning of the
disc and resumes playing.
*
[AS07610( BC )10/95]
How to change the track being played
[AS07620( BC )10/95]
Press the top
aside of the ªSEEKº button to
seek forward to the next track of the disc. If the
button is held and the last track is reached, the
disc player will automatically begin playing the
last track of the disc.
[AS07630( BC )10/95]
Press the bottom
bside of the ªSEEKº button
to seek the previous track on the disc.
[AS07650( BC )04/96]
NOTE: Once a disc is inserted, the disc
opening is secured to prevent the
accidental insertion of a second disc.
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

33
*
[AS07700( BC )10/95]
NOTE: The CD player has heat protection
circuitry to protect the laser diode. If
the temperature of the player reaches
167ÊF (75ÊC), theheat detection circuit
will shut off the player and ªTOO
HOTº will scroll in the display for
approximately five seconds (radio will
resume playing). When the temperature
returns to normal operating range, the
CD player will again be operational.
*
[AS07750( BC )10/95]
How to stop and restart the CD player
*
[AS07800( BC )04/96]
When a disc is loaded, the unit automatically
enters the play mode and the play indicator
a
illuminates. To stop temporarily, press the
ªPLAY/STOPº button or the ªAM/FMº button.
The stop indicator
Xin the display illuminates
and operation returns to the radio mode. To
resume CD play, press the ªPLAY/STOPº
button once again.
*
[AS07850( BC )10/95]
NOTE: If the ignition key is turned OFF
during play and then is set to the ON
or ACCESSORY position, the CD
player will resume playing in the mode
it was in when ignition was turned off.
*
[AS07900( BC )10/95]
How to fast forward or reverse your CD
player
*
[AS07950( BC )10/95]
To quickly search for a particular point in a
selection, press the ªFFº button (to fast forward)
or the ªREVº button (to reverse). While either
button is pressed, the disc goes forward or
backward at two different speeds depending on
how long the button is held down. (Pressing
either button for more than three seconds will
speed up the process.) Release the button at the
desired point (found by watching the elapsed
playing time in the display or by listening to the
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

34sound during fast forward or reverse). When
you have reached the beginning of track 1, the
CD player will begin playing.
*
[AS08000( BC )10/95]
When you have reached the end of the disc by
keeping the fast forward button pressed, the
display will show ªENDº and the player will go
into pause mode. Push the ªPLAY/STOPº
button to begin playing the first track of the
disc, press the ªREVº button to back up from
the end of the disc, or use the ªSEEKº function
to locate a desired track.
*
[AS08020( BC )10/95]
Using the ªSCANº function
[AS08030( BC )10/95]
Press the ªSCAN/TUNEº button to enter the
scan mode. Once in the scan mode, press the top
aor bottom
bhalf of the ªSEEKº button to
scan forward or reverse, respectively. The CD
player will begin scanning the disc, stopping on
each listenable track for approximately eight
seconds. This continues until you press the
ªSCAN/TUNEº button a second time. While in
the scan mode, the display shows the current
sampled track number.
*
[AS08040( BC )10/95]
Special features of your CD player
*
[AS08050( BC )10/95]
q
Compression
*
[AS08060( BC )10/95]
The compression feature will bring soft and
loud passages closer together for a more
consistent listening level.
*
[AS08070( BC )10/95]
To turn the compression on, press the
ªCOMPº button. When on, the compression
indicator (ªCº) will appear in the display.
Press the button again to turn off.
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

35
*
[AS08080( BC )10/95]
q
Automatic Disc Storage
*
[AS08090( BC )10/95]
If the disc is ejected from the CD player but
is not removed from the disc opening within
approximately 10 seconds, the player will
automatically reload the disc for storage,
unless the disc is automatically ejected due to
a ªfocus errorº (disc inserted upside down).
In this case, the disc will not be automatically
reloaded.
*
[AS08095( BC )04/96]
How to eject the disc
*
[AS08096( BC )10/95]
Push the ªEJECTº button to stop play, eject the
disc and resume radio operation of your audio
system.
*
[AS08097( BC )10/95]
NOTE: You can eject the disc while the radio
power and/or ignition is on or off.
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

36 % [AS21350(MBC )04/96]
full page art:0095103-AElectronic Stereo Radio with Cassette
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

37
% [AS21370(MBC )06/95]
Electronic Stereo Cassette Radio
*
[AS21400(MBC )03/96]
Using the Controls on Your New Radio
*
[AS21500(MBC )08/95]
How to turn the radio on and adjust the
volume
*
[AS22050(MBC )10/95]
Press the ªPOWERº button to turn the radio on.
Press it again to turn it off.
*
[AS22060(MBC )02/96]
Press the right (+) side of the ªVOLUMEº
button to increase the volume. Press the left (S)
side of the button to decrease the volume.
Illuminated bars in the display show the relative
volume level.
*
[AS22070(MBC )02/96]
NOTE: If the volume level is set above a
certain listening level when the
ignition switch is turned off, when the
ignition switch is turned back on, the
volume will come back to a ªnominalº
listening level. However, if the radio
power is turned off, the volume will
remain in the position it was set at
when radio power was switched off.
*
[AS22100(MBC )03/96]
Selecting the AM or FM frequency band
*
[AS22250(MBC )02/95]
Push the ªAM/FMº button to select the desired
frequency band or to stop/store cassette tape
(when in cassette mode). Pushing the button
more than once will alternate between AM, FM1
and FM2. These functions are used with the
station memory buttons described underHow to
tune radio stations.
%*
[AS22300(MBC )03/96]
How to tune radio stations
[AS22425(MBC )06/95]
There are four ways for you to tune in to a
particular station. You can manually locate the
station by using the Automatic Music Search
(ªAMSº) button, ªSEEKº the station, ªSCANº to
the station or select the station by using the
memory buttons, which you can set to any
desired frequency.
File:04rcasb.ex
Update:Thu May 30 10:55:25 1996

38 [AS22450(MBC )05/95]q
Using the ªAMSº function to manually tune
your radio
[AS22650(MBC )03/95]
You can change the frequency up or down
one increment at a time by first pressing the
ªAMSº button, (display shows ªTUNEº) then
pressing and releasing either the right
aor
left
bside of the ªSEEKº button. To change
frequencies quickly, press andhold down
either the right or left side of the ªSEEKº
button.
*
[AS22700(MBC )03/96]
Manual tuning adjusts your radio to any
allowable broadcast frequency, whether or
not a station is present on that frequency.
(SeeAll About Radio Frequenciesin this
section.)
*
[AS22800(MBC )04/96]
q
Using the ªSEEKº function
*
[AS22900(MBC )09/95]
This feature on your radio allows you to
automatically select listenable stations up or
down the frequency band. Press the right
(
a) side of the ªSEEKº button to select the
next listenable station up the frequency band.
Press the left (
b) side of the button to select
the next listenable station down the
frequency band. By holding the button down,
listenable stations can be passed over to reach
the desired station.
*
[AS23150(MBC )04/96]
q
Using the ªSCANº function
*
[AS23175(MBC )06/95]
Press the ªSCANº button to enter the scan
mode. The radio will begin scanning up the
frequency band, stopping on each listenable
station for approximately a five-second
sampling. This continues until you press the
ªSCANº button a second time. The display
flashes ªAMº or ªFM.º
