1997 FORD THUNDERBIRD Owners Manual

184 [ER17400( BC )04/96]To replace the wheel cover:
[ER17500( BC )12/95]
1. Place the tire valve stem hole in the wheel
cover over the tire valve stem. Align the
holes in the wheel cover mounting pad with
the center holes in the metal inserts. Install
and tighten the five screws.
[ER17600( BC )12/95]
2. Align the legs of the ornament with the slots
on the wheel cover. Strike the ornament with
the palm of your hand.
%*
[ER18800(MBC )01/96]
Anti-Theft Wheel Lug Nuts (If equipped)
*
[ER18900( BC )12/95]
If your vehicle has this option, one of the lug
nuts on each wheel locks and must be unlocked
with a special key. The key and registration card
are attached to the lug wrench and stored with
the spare tire. If you lose the key, send the
registration card to the manufacturer (not the
dealer) to get a replacement key.
*
[ER19100(MBC )12/95]
NOTE: If entire lug wrench/lug nut key
assembly is lost, see your nearest Ford
or Lincoln-Mercury dealer who has
access to a master set of keys.
*
[ER19200(MBC )12/95]
NOTE: DO NOT USE A POWER IMPACT
WRENCH ON THE LUG NUT KEY.
[ER19300(MBC )12/95]
quarter page art:0010357-B
The anti-theft lug nut and key
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

185
*
[ER19400(MBC )12/95]
Removing the anti-theft lug nut
*
[ER19500(MBC )02/96]
Insert the key over the locking lug nut. Make
sure that you hold the key square to the lug nut.
If you hold the key on an angle, you may
damage the key and the lug nut.
*
[ER19600(MBC )12/95]
Place the lug nut wrench over the lug nut key
and apply pressure on the key with the wrench.
Turn the wrench in a counterclockwise direction
to remove the lug nut.
*
[ER19700(MBC )12/95]
Reinstalling the anti-theft lug nut
*
[ER19800(MBC )12/95]
Insert the key over the locking lug nut. Place the
lug nut wrench over the lug nut key and, while
applying pressure on the key, install the lug nut.
%
*
[ER19900( ALL)02/96]
Jump-Starting Your Vehicle
*
[ER19950( ALL)02/96]
Your vehicle's battery may die if you leave the
lights on or any electrical equipment on after
you turn the engine off. If this happens, you
may be able to jump-start your vehicle with a
booster battery.
*
[ER20000( ALL)02/96]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[ER20100( ALL)02/96]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

186 %
*
[ER20200( ALL)02/96]
RWARNING
Applying too much pressure on the ends
when lifting a battery could cause acid to
spill. Lift the battery with a carrier or
with your hands on the opposite corners.
%*
[ER20300( ALL)02/96]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
*
[ER20400( ALL)02/96]
If the acid touches someone's skin, eyes, or
clothing, immediately flush the area with water
for at least 15 minutes. If someone swallows the
acid, have him or her drink lots of milk or water
first, then Milk of Magnesia, a beaten egg, or
vegetable oil. Call a doctor immediately.
*
[ER20500( ALL)02/96]
To avoid damaging your vehicle or your battery,
and to avoid injury to yourself, follow these
directions for preparing your vehicle to
jump-start and connecting the jumper cables in
the order they are given. If in doubt, call for
road service.
%*
[ER20600( ALL)02/96]
Preparing Your Vehicle
[ER20700( ALL)02/96]
NOTE: also see label on battery.
*
[ER20800( ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[ER20900( ALL)02/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

187
*
[ER21000( ALL)02/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER21100( ALL)02/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
*
[ER21200( ALL)02/96]
5. Turn on the heater fan in both vehicles.
Turning on the fan helps protect the
electrical system from voltage surges. Turn
off all other switches and lights in both
vehicles to prevent possible damage to either
vehicle's electrical systems.
%*
[ER21300( ALL)02/96]
Connecting the jumper cables
*
[ER21400( ALL)02/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER21500( ALL)02/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

188
*
[ER21600( ALL)02/96]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
[ER21700( ALL)02/96]
4. Connect the other end of that cable to a
good metallic surface on the engine or frame
of the disabled vehicle making sure it is
clear of any rotating engine components. The
following illustrations show where you can
find a metallic surface.
*
[ER21800( ALL)02/96]
RWARNING
Do not connect the end of the second
cable to the negative (S) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

189 [ER22000( BC )02/96]
full page art:0010334-D
The 3.8L SFI engine
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

190 [ER22100(BC )04/96]
full page art:0010666-GThe 4.6L SFI Engine
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

191
*
[ER22300( ALL)02/96]
Jump-Starting
*
[ER22400( ALL)02/96]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[ER22500( ALL)02/96]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[ER22600( ALL)02/96]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
%*
[ER22700( ALL)02/96]
Removing jumper cables
*
[ER22800( ALL)02/96]
1.Always remove the jumper cables in the
reverse order.Remove the negative (S) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[ER22900( ALL)03/96]
2. Remove the negative (S) cable from the
booster battery.
*
[ER23000( ALL)02/96]
3. Remove the positive (+) cable from the
booster battery.
*
[ER23100( ALL)02/96]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[ER23200( ALL)02/96]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
Driveability may be deteriorated slightly until all
drive modes are ªrelearned.ºYou may need to
use a battery charger to fully recharge the
battery.
