1997 FORD THUNDERBIRD Owners Manual

144
*
[TO05100( ALL)01/96]
Have the exhaust and body ventilation systems
checked whenever:
*
[TO05200( ALL)01/96]
q
your vehicle is raised for service
*
[TO05300( ALL)01/96]
q
the sound of the exhaust system changes
*
[TO05400( ALL)01/96]
q
your vehicle has been damaged in a collision
*
[TO05500( ALL)01/96]
Improve your ventilation by keeping all air inlet
vents clear of snow, leaves, and other debris.
[TO05600( ALL)12/95]
If the engine is idling while you are stopped in
an open area for long periods of time, open the
windows at least one inch (2.5 cm). Also, the
heating or air conditioning system should be set
to any function except MAX A/C or AUTO.
[TO05800( BCGV)12/95]
q
If you use the heater, set the fan speed on
MEDIUM or HIGH with the function control
on any position except OFF and the
temperature control at any desired position.
[TO06000( BCGV)12/95]
q
If you use the air conditioner, set the fan
speed on MEDIUM or HIGH with the
function control on any position except OFF
or MAX and the temperature control at any
desired position.
*
[TO06100( ALL)01/96]
Pushing
[TO06300( BCGV)01/96]
Vehicles with automatic transmissions cannot be
started by pushing. Follow the directions under
If Your Vehicle Needs a Jump-Start.
File:08rctob.ex
Update:Thu May 30 10:58:59 1996

145
Driving
%*
[GF00500( ALL)05/96]
Brakes
%*
[GF00600( ALL)01/96]
Applying the Brakes
[GF00700( ALL)12/95]
Braking non ABS models
[GF00900( B )12/95]
Your vehicle has standard power front disc
brakes and rear drum brakes, (anti-lock disc
brakes on all four wheels are optional). They
adjust automatically as the brake pads or linings
wear down.
*
[GF01200( ALL)01/96]
Apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
[GF01300( ALL)12/95]
On vehicles without anti-lock brakes, extreme
braking can make the wheels lock and slide,
possibly decreasing your control of the steering.
If you lock the wheels, release the brake pedal
and repeat the ªsqueezeº technique.
[GF01400( ALL)12/95]
Braking with ABS brakes
[GF01500( ALL)12/95]
On vehicles with anti-lock brakes, the wheels
will not lock and slide when you press down
hard on the brake pedal. The anti-lock brakes
automatically start releasing and reapplying the
front brakes independently and the rear brakes
together whenever your wheels start to lock. Do
not ªpumpº the brake pedal on vehicles
equipped with anti-lock brakes. When this
happens, you will feel the brake pedal pulse.
This ªpulseº may be an unfamiliar feeling but it
is normal and indicates the ABS is working as
designed.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

146
*
[GF01600( ALL)01/96]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[GF01700( ALL)02/96]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
%*
[GF01800( ALL)01/96]
Occasional brake squeal during light to moderate
stops does not affect the function of the brake
system and is normal. However, if the squeal
becomes louder or more frequent, have your
brakes inspected by your dealer or a qualified
service technician.
[GF01900( ALL)12/95]
Ford Motor Company has not found any
detrimental effects of popular mobile radio
transmitting equipment installed on vehicles
with the anti-lock brake system, if the equipment
is installed according to the manufacturer's
instructions. However, if mobile radio
transmitting equipment is installed in your
vehicle and, if either the anti-lock brake system
cycles or the check anti-lock light comes on at
any time other than right after you turn the key
to ON or during a sudden stop, have your
mobile radio dealer inspect the installation.
%*
[GF02000( ALL)01/96]
Parking Brake
*
[GF02100( ALL)03/96]
The parking brake should be used whenever
you park your vehicle.
[GF02300( BCGV)12/95]
The parking brake pedal is suspended just below
the bottom of the instrument panel to the left of
the brake pedal.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

147 [GF02500( BC )12/95]
To set the parking brake while parking your
vehicle, apply the brake pedal with your right
foot and hold it while you push the parking
brake down firmly with your left foot. The brake
system warning light will glow.
[GF02800( BC )12/95]
one third page art:0010315-A
The parking brake
*
[GF03100( BCGV)05/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
[GF03300( BC )12/95]
To release the parking brake, press down on the
pedal until you hear a click. Lift your foot off
the pedal. The brake is now released and will
reset to lock the next time you press the pedal,
located below the lower left corner of the
instrument panel. The Brake System Warning
Light will glow if the parking brake is not fully
released when the engine is running.
*
[GF03600( ALL)01/96]
Always check the Brake Warning Light each
time you start your engine. Driving with the
parking brake on will cause the brakes to wear
out quickly and will reduce the fuel economy.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

148
*
[GF03700( ALL)02/96]
RWARNING
If the parking brake is fully released, but
the Brake System light remains on, have
the brakes checked immediately. They
may not be working properly.
[GF03800( ALL)12/95]
The parking brake system is designed for static
parking only and is not designed to stop a
moving vehicle, but you can use the parking
brake to stop your vehicle in an emergency if
the normal brakes fail. However, since the
parking brake applies only the rear brakes, the
stopping distance will increase greatly and the
handling of your vehicle will be adversely
affected.
% [GF03900( ALL)12/95]Traction-Lok Axle (If equipped)
[GF04000( ALL)12/95]
This axle provides added traction on slippery
surfaces, particularly when one wheel is on a
poor traction surface. Under normal conditions
the Traction-Lok axle functions as a standard
rear axle.
*
[GF04100( ALL)03/96]
Extended use of other than matching size tires
on a Traction-Lok rear axle could result in a
permanent reduction in effectiveness. This loss of
effectiveness does not affect normal driving and
should not be noticeable to the driver.
*
[GF04200( ALL)05/96]
RWARNING
To avoid injury, never run the engine
with one wheel off the ground, such as
when changing a tire.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

149
%*
[GF04300( BCGV)03/96]
Traction Assist
TM
(If equipped)
*
[GF04400( BCGV)03/96]
Your vehicle may be equipped with the optional
Traction Assist
TM
system. This system helps
prevent wheel spin in order to improve tire
traction and is an especially useful feature when
you drive in hilly areas or on slippery, icy or
snowy roads.
[GF04500( BCGV)05/96]
Traction Assist
TM
works automatically by rapidly
applying and releasing the brakes to prevent one
or both of the rear drive wheels from spinning
during acceleration.
[GF04600( BC )04/96]
The Traction Assist
TM
system can be manually
turned off, to allow wheelspin if you want, by
pushing the traction assist switch (located in the
console). When the vehicle is not in the Traction
Assist
TM
mode the ªT/A OFFº indicator light
(located on the cluster) will illuminate to indicate
the system is off. The Traction Assist
TM
system
will automatically be on each time the engine is
started. During ordinary driving, it is
recommended to leave the system turned on.
The Traction Assist
TM
system will then always be
ready to operate when needed.
[GF04700( BC )12/95]
one quarter page art:0011288-B
The Traction Assist
TM
Switch
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

150 [GF04800( BCGV)12/95]During the Traction Assist
TM
function, which
most often occurs during low speed acceleration
on slippery surfaces, a noise may be heard
coming from the engine compartment. This noise
is created by the ABS pump and is normal and
may last for a few seconds during the
acceleration of the vehicle.
[GF04900( BCGV)05/96]
In general, this system improves your vehicle's
stability and acceleration performance when road
conditions warrant. Traction Assist
TM
is fully
effective up to approximately 25 mph
(40 km/h). At 25 mph (40 km/h) the function
begins to taper off until it no longer operates
above 34 mph (55 km/h).
[GF05000( BCGV)12/95]
If the Traction Assist
TM
system is cycled
excessively, the system will shut down to
prevent the rear brakes from overheating.
During this shutdown period, the word OFF in
the traction assist switch will be illuminated
showing that the traction assist system is
inoperative. A cooling down period is required
to prevent damage to the rear brakes. This time
period varies and depends on brake usage
during the cooling down period. Anti-Lock
braking is not affected and will function
normally during the cool down period.
%
*
[GF05200( ALL)01/96]
Steering Your Vehicle
%*
[GF05300( ALL)01/96]
Your vehicle comes with power steering. Power
steering uses energy from the engine to help
steer your vehicle.
%*
[GF05400( ALL)03/96]
If the amount of effort needed to steer your
vehicle changes at a constant vehicle speed, have
the power steering system checked. If the power
steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually
but it takes more effort.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

151
*
[GF05500( ALL)01/96]
Never hold the steering wheel to the extreme
right or left for more than five seconds if the
engine is running. This can damage the power
steering pump.
[GF05600( BCGV)12/95]
Speed Sensitive Power Steering
(If equipped)
[GF05800( BC )12/95]
The steering system in 4.6L engine vehicles is
speed sensitive. This means that the steering
effort is light for parking and heavier for
highway driving. However, if you have to
swerve around an object or another vehicle, your
steering will have full power assist.
%
*
[GF06500( ALL)12/95]
Driving with an Automatic
Overdrive Transmission
[GF06600(MBC )12/95]
The gearshift lever is floor mounted.
*
[GF06700( BCGV)12/95]
The automatic overdrive transmission operates
very much like a regular automatic transmission,
except it offers the extra overdrive feature.
%*
[GF06800( ALL)05/96]
Putting Your Vehicle in Gear
*
[GF06900( ALL)05/96]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
[GF07100(MBC )04/96]
To move the shifter out of P (Park), the ignition
key must be turned to the ON position and the
shift lever thumb button must be pushed in.
*
[GF07200( ALL)12/95]
To operate:
*
[GF07300( ALL)12/95]
1. Start the engine.
*
[GF07400( ALL)12/95]
2. Depress and hold the brake pedal.
*
[GF07500( ALL)12/95]
3. Move the gearshift lever out of P (Park).
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996
