1997 FORD THUNDERBIRD Owners Manual

95
*
[CF56400(MBC )03/96]
Triggering the Alarm System
*
[CF56500(MBC )01/96]
The armed system will be triggered if:
[CF56600(MBC )12/95]
q
any door is opened without disarming the
system first (see previous paragraphs)
*
[CF56700(MBC )12/95]
q
the trunk lock cylinder is removed
*
[CF56800(MBC )12/95]
NOTE: You can open the trunk with your key
without setting off the alarm.
[CF57100( BC )12/95]
q
the ignition key lock cylinder is forcibly
removed from the steering column.
%*
[CF57200(MBC )03/96]
Disarming a Triggered System
*
[CF57300(MBC )01/96]
The alarm can be disarmed by:
*
[CF57400(MBC )12/95]
q
unlocking a front door with the key
*
[CF57500(MBC )04/96]
q
using the UNLOCK control on the remote
entry transmitter
*
[CF57600(MBC )01/96]
NOTE: The flashing lights and honking horn
will shut off automatically within 2
minutes 45 seconds after the system is
triggered. It will trigger again if
another intrusion occurs. However, the
starter circuit remains disabled until
the system is disarmed.
*
[CF65000( ALL)05/96]
Remote Entry System
(If equipped)
*
[CF65100( ALL)04/96]
If your vehicle has the remote entry system, you
can lock and unlock the vehicle doors and open
the trunk without using a key. The remote also
has a personal alarm feature. The controls for
the system are located on the hand held
transmitter(s) that came with your vehicle.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996

96
*
[CF65200( ALL)01/96]
The system will work with up to four
transmitters. Your vehicle came with two
transmitters. Additional transmitters can be
ordered from your dealer.
*
[CF65300(MBC )01/96]
The remote entry features only operate with the
ignition in the OFF position.
[CF65500(MBC )12/95]
one third page art:0001000-A
Remote entry transmitter
%*
[CF65700( ALL)02/96]
Unlocking the doors and opening the
trunk
*
[CF65800( ALL)04/96]
To unlock the driver's door, press the UNLOCK
control.
*
[CF65900( ALL)04/96]
To unlock the other doors, press the UNLOCK
control a second time within five seconds of
unlocking the driver's door.
*
[CF66000( ALL)04/96]
To open the trunk, press the TRUNK control.
*
[CF66200( ALL)04/96]
Locking the doors
*
[CF66300( ALL)04/96]
To lock all the doors, press the LOCK control.
*
[CF66400(MBC )04/96]
If you would like a signal that the doors are
being locked, press the LOCK control again
within five seconds. The doors will lock again
and the horn will beep.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996

97 %
*
[CF67200( ALL)03/96]
Activating the remote personal alarm
*
[CF67300( ALL)04/96]
If you wish to activate the remote personal
alarm, press the PANIC control. This will honk
the horn and flash the parking lamps and tail
lamps for approximately two minutes and
forty-five seconds. You can turn it OFF by
pressing the PANIC control again or by turning
the ignition key to the RUN position.
[CF67400( ALL)05/96]
When you use the remote entry UNLOCK,
TRUNK or PANIC controls, the illuminated
entry system turns on the interior lights for 25
seconds. You can turn these lights off with the
LOCK control or by turning the ignition to the
RUN position. The interior lights will not turn
off if you have turned them on manually or if a
door is open.
%*
[CF68400( ALL)03/96]
Replacing the Batteries
*
[CF68500(MBC )01/96]
The remote entry transmitter is powered by two
coin type three-volt lithium 2016
batteries (included) that should last for several
years of normal use. If you notice a significant
decrease in operating range, the batteries should
be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or
at your Ford or Lincoln-Mercury dealer.
*
[CF68700( ALL)01/96]
NOTE: The operating range of the remote
entry system can also be affected by
weather conditions (such as very cold
temperatures) or structures around the
vehicle (buildings, other vehicles, radio
and TV towers, etc.). Typical operating
range will allow you to be up to 33
feet (10 meters) away from your
vehicle.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996

98
*
[CF68800(MBC )01/96]
quarter page art:0020790-A
Replacing the batteries
*
[CF68900(MBC )01/96]
The transmitter can be snapped apart to replace
the batteries by twisting a thin coin between the
two halves of the transmitter. DO NOT TAKE
THE FRONT PART OF THE TRANSMITTER
APART. When installing the new batteries, be
sure to place the positive (+) side down as
marked. Snap the two halves back together.
%*
[CF69000( ALL)02/96]
Replacement/additional transmitters
*
[CF69100(MBC )01/96]
In the event a transmitter is lost, return the
remaining transmitters to your dealer for
reprogramming of your remote entry system.
This is necessary to prevent further unauthorized
use of the lost transmitter.
*
[CF69600(MBC )01/96]
Additional transmitters may be purchased from
your dealer (remote entry system will work with
up to four transmitters). Return your existing
transmitters to your dealer so the remote entry
system can be reprogrammed with your new
and existing transmitters.
*
[CF70000( ALL)01/96]
THIS DEVICE COMPLIES WITH PART 15 OF
THE FCC RULES. OPERATION IS SUBJECT
TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE
HARMFUL INTERFERENCE, AND (2) THIS
DEVICE MUST ACCEPT ANY
INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE
UNDESIRED OPERATION.
File:05rccfb.ex
Update:Fri Jun 7 14:36:35 1996

99
Seating and Safety
Restraints
%*
[SS00200( ALL)05/96]
Seats
%*
[SS00300( ALL)05/96]
Head Restraints
*
[SS00400( ALL)01/96]
If you use them properly, head restraints will
help protect your head and neck in a collision.
*
[SS00500( ALL)01/96]
A head restraint helps protect you best if you
position it behind your head and not behind
your neck.
*
[SS00600( ALL)12/95]
Standard head restraints
*
[SS00700( ALL)12/95]
You can adjust the head restraints for your
comfort and protection.
[SS00800( ALL)12/95]
one third page art:0010048-C
Adjusting the head restraint
File:06rcssb.ex
Update:Thu May 30 10:58:44 1996

100 % [SS01200(MBC )12/95]Adjusting Manual Seats
*
[SS01400( ALL)01/96]
In the front seats, you can move the whole seat
forward or backward or tilt the back of the seat
forward or backward.
[SS01500(MBC )12/95]
To move the seats forward or backward:
[SS01700( BCGV)12/95]
1. Find the adjustment bar underneath the front
part of the seat.
[SS01900( BCGV)12/95]
2. Lift the bar to unlatch the seat.
*
[SS02100( ALL)01/96]
3. Move the seat to the desired position.
*
[SS02200( BCGV)01/96]
4. Release the bar to latch the seat in its new
position. Make sure the seat locks securely in
place.
[SS02400( BC )12/95]
quarter page art:0010252-A
The front seat adjustment bar
*
[SS02700(MBC )12/95]
To recline the front manual seats:
*
[SS02900( ALL)01/96]
1. On the side of the seat, find the handle for
the recliner.
*
[SS03000( ALL)01/96]
2. Lift the handle up and hold it in place.
*
[SS03100( ALL)12/95]
3. Lean against the back of the seat and adjust
it to the position you want. You can tilt the
seat back or bring it forward.
*
[SS03200( ALL)12/95]
4. Release the handle to lock the seat in its new
position.
File:06rcssb.ex
Update:Thu May 30 10:58:44 1996

101
*
[SS03400( ALL)01/96]
RWARNING
Never adjust the driver's seat or seatback
when the vehicle is moving.
*
[SS03500( ALL)02/96]
RWARNING
Always drive and ride with your seatback
upright and the lap belt snug and low
across the hips.
%*
[SS03700(MBC )01/96]
Seatback Recline
[SS03900( BC )12/95]
one third page art:0010256-A
Front seatback release levers
*
[SS04200( BC )12/95]
It is not necessary to use the emergency seatback
release lever for rear seat entry or exit. The
seatback remains unlocked with normal usage
and locks only during emergency stopping, upon
impact, or on steep downhill grades. The inertia
seatback latch will allow the seatback to rotate
approximately 5Ê forward before it locks. The
release is provided only to unlock the seatback
when parked on steep downhill grades or after a
collision.
File:06rcssb.ex
Update:Thu May 30 10:58:44 1996

102
*
[SS04300(MBC )02/96]
RWARNING
Check to see that the seat and seatback
are latched securely in position. Keep
floor area free of objects that would
prevent proper seat engagement. Never
attempt to adjust the seat while the
vehicle is in motion.
%*
[SS04500( BCGV)01/96]
Using the Power Seats (If equipped)
[SS04700( BC )12/95]
If your vehicle has power seats, you can adjust
them in several directions. The controls are on
the side of the seats.
[SS05000( BC )12/95]
half page art:0010258-F
The power controls on the driver's seat
File:06rcssb.ex
Update:Thu May 30 10:58:44 1996
