1997 FORD THUNDERBIRD Owners Manual

152 %
*
[GF07600( ALL)12/95]
Your vehicle is equipped with a Brake Shift
Interlock safety feature. This feature prevents the
gearshift from being moved from the P (Park)
position until the brake pedal is depressed. This
feature is active when the ignition is in the ON
position. If the gearshift lever CANNOT be
moved from P (Park) with the brake pedal
depressed:
*
[GF07700( ALL)12/95]
1. Turn the engine off and remove the ignition
key.
*
[GF07800( ALL)12/95]
2. Apply parking brake.
*
[GF07900( ALL)04/96]
3. Reinsert the ignition key and turn clockwise
to the first position.
*
[GF08000( ALL)01/96]
4. Depress the brake pedal, move the gearshift
lever to N (Neutral) and start the engine.
*
[GF08100( ALL)05/96]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL
YOU VERIFY THAT THE BRAKELAMPS
ARE WORKING.
*
[GF08200( ALL)05/96]
If you need to shift out of P (Park) by using the
alternate procedure described above, it is
possible that a fuse has blown and that your
brakelamps may also not be functional. Please
refer to the chapter titledRoadside Emergenciesin
this Owner Guide for instructions on checking
and replacing fuses.
[GF08300(MBC )12/95]
The console-mounted gearshift will lock in P
(Park) when you turn the key to the LOCK
position. When the gearshift is in any position
except P (Park), the ignition key cannot be
turned to LOCK or removed from the steering
column. TO REMOVE THE KEY, the gearshift
lever must be in P (Park).
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

153 % [GF08600( BC )12/95]
half page art:0010307-F
The positions of the console-mounted gearshift
*
[GF08700( ALL)01/96]
Once the gearshift is secure in the desired
position, release the brake pedal and use the
accelerator as necessary.
%*
[GF08800( ALL)05/96]
R (Reverse)
*
[GF08900( ALL)05/96]
With the gearshift in the R (Reverse) position,
the vehicle will move backward. You should
always come to a complete stop before shifting
into or out of R (Reverse).
*
[GF09000( ALL)01/96]
N (Neutral)
[GF09100( ALL)12/95]
As in P (Park), there is no power transferred
through the transmission. However, the final
drive is not locked so the wheels are free to
rotate. The vehicle may be started in the N
position, but the ignition key cannot be
removed.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

154 %
*
[GF09200( ALL)05/96]
Driving
[GF09400(MBC )05/96]
Your vehicle's gearshift is console-mounted on
the floor. The Transmission Control Switch (TCS)
is located on the gearshift handle. The
Transmission Control Indicator Light (O/D OFF)
is located on the instrument panel. You can put
the gearshift lever in any of the several
positions.
[GF09700(MBC )12/95]
The OVERDRIVE OFF light is off (not
illuminated) during normal vehicle operation.
This allows the transmission to upshift and
downshift from 1st through 4th gears. When the
TCS is pressed, the Transmission Control
Indicator Light will illuminate (O/D OFF) on the
instrument panel. When this O/D OFF is
illuminated the transmission will upshift and
downshift from 1st through 3rd gears.
[GF09800( ALL)12/95]
If the O/D OFF light does not come ªonº when
the TCS is depressed or if the light ªFLASHESº
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transmission.
*
[GF09900( BCGV)05/96]
To return the transmission to normal operation
(1st through 4th gear) depress the TCS again.
This switch may be used to cancel overdrive any
time the vehicle is being driven. Each time your
vehicle is started, the overdrive system will
automatically be in the normal overdrive mode
and the light will not be illuminated.
%*
[GF10200(MBC )01/96]
When to use D (Overdrive)
*
[GF10300( ALL)12/95]
Overdrive is the usual driving position for an
automatic overdrive transmission. It works the
same way Drive works, automatically upshifting
or downshifting as the vehicle speeds or slows.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

155
*
[GF10400( ALL)12/95]
However, Overdrive also shifts into a fourth
gear Ðan overdrive gear Ð when your vehicle
cruises at an appropriate consistent speed for
any length of time. This fourth gear will increase
your fuel economy when you travel at cruising
speeds.
% [GF10500(MBC )12/95]
When to use D (Overdrive) Ð with
transmission control switch activated (O/D
OFF light illuminated)
*
[GF10700(MBC )12/95]
Overdrive may not be appropriate for certain
terrain. If the transmission shifts back and forth
between Third and Fourth gears while you are
driving on hilly roads or if your vehicle does
not have adequate power for climbing hills,
depress the TCS.
*
[GF10900( BCGV)12/95]
You can depress the TCS at any speed.
*
[GF11100( ALL)05/96]
When to use 2 (Second)
*
[GF11200( ALL)12/95]
Use 2 (Second) for start-up on slippery roads or
to give you more engine braking to slow your
vehicle on downgrades.
*
[GF11300( ALL)05/96]
When to use 1 (Low)
*
[GF11400( ALL)12/95]
Use 1 (Low) when driving down steep grades. It
gives more engine braking to slow your vehicle
than 2 (Second) on the downgrades. You can
upshift from 1 (Low) to 2 (Second) or from 1
(Low) to Overdrive at any speed.
*
[GF11500( ALL)05/96]
P (Park)
*
[GF11600( ALL)12/95]
Always come to a complete stop before you shift
into P (Park). Make sure that the gearshift is
securely latched in P (Park). This locks the
transmission and prevents the rear wheels from
rotating.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

156
*
[GF11700( ALL)05/96]
RWARNING
Always set the parking brake fully and
make sure the gearshift is latched in P
(Park). Turn off the ignition whenever you
leave your vehicle.
*
[GF11800( ALL)05/96]
RWARNING
Never leave your vehicle unattended
while it is running.
*
[GF12000(MBC )12/95]
You can tell a console-mounted gearshift is
securely latched in P (Park) if the lever is
adjacent to the P (Park) and you cannot move it
without pushing in the thumb button.
%
*
[GF15500( ALL)01/96]
Driving With a Heavy Load
*
[GF15600( ALL)01/96]
There are limits to the amount of weight your
vehicle can carry or tow. The total weight of
your vehicle, plus the weight of the passengers
and cargo, should never be more than the Gross
Vehicle Weight Rating (GVWR). Also, the weight
that your vehicle carries over the front axle and
rear axle should never be more than the Gross
Axle Weight Rating (GAWR) for the respective
axle.
% [GF15700( ALL)12/95]
You can find your vehicle's GVWR and GAWR
on the Safety Compliance Certification Label on
the left front door lock facing or the door latch
post pillar.
*
[GF15800( ALL)01/96]
The weight limits of your vehicle's tires affect
the GVWR or GAWR limitations. Usage of
replacement tires with higher weight limits than
originals does not increase GVWR or GAWR.
Usage of lower capacity replacement tires may
lower GVWR and GAWR limitations.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

157
*
[GF15900( ALL)01/96]
RWARNING
Do not exceed the GVWR or the GAWR
specified on the Safety Compliance
Certification Label.
%*
[GF16000( ALL)01/96]
Limiting Your Vehicle's Load
*
[GF16100( ALL)12/95]
The load that you add to your vehicle must not
exceed the maximum load stated on the Safety
Compliance Certification Decal attached to the
left front door pillar.
*
[GF16200( ALL)01/96]
To figure the weight of your vehicle's load, add
the weights of:
*
[GF16300( ALL)01/96]
q
the driver and passengers
*
[GF16400( ALL)01/96]
q
luggage and any other items that you put in
your vehicle
*
[GF16500( ALL)12/95]
q
the tongue load of the loaded trailer
*
[GF16600( ALL)01/96]
q
the weight of any equipment that has been
added to your vehicle since it was delivered
to your dealer
*
[GF16700( ALL)01/96]
If you do not know the actual weights of these
items, use the following procedure to figure the
weight of a load:
*
[GF16800( ALL)01/96]
1. Weigh your vehicle without the driver,
passengers and luggage. You might take
your vehicle to a shipping company or an
inspection station for trucks.
*
[GF16900( ALL)01/96]
2. Then weigh your vehicle with the driver,
passengers and luggage.
*
[GF17000( ALL)01/96]
3. Subtract the first reading from the second to
figure the total weight of the load.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

158
*
[GF17100( ALL)11/92]
After determining this load, you must also make
sure that the total weight of your vehicle, plus
the load it carries, is less than its GVWR. Also,
make sure that the weight your vehicle carries
over each axle is less than the GAWR for the
respective axle.
*
[GF17200( ALL)01/96]
If your vehicle exceeds the GVWR, remove cargo
from your vehicle accordingly. If your vehicle
exceeds the GAWR for either axle, shift the load
or remove cargo accordingly.
*
[GF17300( ALL)01/96]
RWARNING
Improper distribution of your vehicle's
load or carrying weight in excess of the
amount shown on the tire decal can cause
rapid tire wear or loss of vehicle control.
%
*
[GF17400(MBC )01/96]
Trailer Towing
*
[GF17600( ALL)12/95]
Your vehicle does not come from the factory
fully equipped to tow. No towing packages are
available through Ford or Lincoln/Mercury
dealers.
*
[GF17700( ALL)05/96]
Because towing a trailer puts extra strain on
your vehicle, you must follow certain
precautions for your safety and the good of your
vehicle:
*
[GF17800( ALL)05/96]
q
Stay within the load limits for towing your
vehicle. (SeeTrailer towing specificationsin this
chapter.)
*
[GF17900( ALL)05/96]
q
Carefully and thoroughly prepare your
vehicle for towing, making sure to use the
right equipment and to attach it properly.
(SeePreparing to Towin this chapter.)
*
[GF18000( ALL)05/96]
q
Use extra caution when driving your vehicle
while you tow. (SeeDriving while you towin
this chapter.)
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996

159
*
[GF18100( ALL)05/96]
q
Service your vehicle more frequently if you
tow a trailer. (SeeServicing your vehicle if you
towin this chapter.)
*
[GF18200( ALL)05/96]
Ten to 15% of the loaded trailer's weight should
be on the tongue. However, the tongue load
should never exceed 10% of the maximum
weight that your vehicle can safely tow.
*
[GF18300( ALL)05/96]
RWARNING
Do not tow a trailer when using a
temporary spare tire.
[GF18400( ALL)12/95]
Your vehicle is classified as a light duty towing
vehicle. The amount of weight that you can
safely tow depends on the optional equipment
on your vehicle. See the following chart.
% [GF18500( ALL)12/95]
Trailer towing specifications
[GF18700( BC )12/95]
six pica chart:0010654-D*
[GF19000( ALL)05/96]
Preparing to Tow
*
[GF19100( ALL)05/96]
For your safety and for the good of your
vehicle, use the right equipment for the type of
trailer you tow. Also, make sure that all towing
equipment is properly attached to your vehicle.
If you are not certain that you are using the
right equipment in the proper manner, see your
Ford or Lincoln-Mercury dealer.
*
[GF19200( ALL)05/96]
Do not use hitches that clamp onto your
vehicle's bumper. The bumper is not designed to
bear the load.
File:09rcgfb.ex
Update:Thu May 30 10:59:34 1996
