High Current Fuses
*
[ER02400( ALL)12/95]
High current fuses are circuit protectors that are
part of the wiring harness for some electrical
equipment. These, like fuses, open when the
circuit load exceeds their amperage rating. High
current fuses may be purchased from your Ford
or Lincoln-Mercury dealer.
*
[ER02500(MBC )12/95]
The high current fuse panel is located in the
engine compartment on the left-hand fender
apron.
*
[ER02700( ALL)01/96]
RWARNING
Always disconnect the battery before
servicing high current fuses.
*
[ER02800( ALL)01/96]
Ford recommends that high current fuses be
replaced by a qualified technician.
[ER03000( BC )12/95]
half page art:0011157-A
The high current fuse panel location
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

169 % [ER03100( ALL)12/95]
The high current fuse panel
[ER03300( BC )05/96]
full page art:0010428-FFile:10rcerb.ex
Update:Thu May 30 11:01:08 1996

170 [ER03600( ALL)12/95]The high current fuses and relays
[ER03900( BC )05/96]
twenty-eight pica chart:0010429-MFile:10rcerb.ex
Update:Thu May 30 11:01:08 1996

171 [ER03905( BC )05/96]
twenty-four pica chart:0011394-A
%*
[ER04400( ALL)01/96]
Checking and Replacing Fuses
*
[ER04500( ALL)01/96]
If you need to check a fuse, follow these steps:
[ER04700( BC )12/95]
1. Find the fuse panel underneath the
instrument panel, to the left of the steering
column.
[ER05000( BCGV)12/95]
2. Check the fuse to see if it is blown. Look
through the clear side of the fuse to see if
the metal wire inside is separated. If it is,
the fuse should be replaced.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

172 [ER05200( ALL)12/95]
quarter page art:0010416-AThe side view of a fuse
[ER05400( BC )12/95]
3. Replace the fuse with one that has the right
amperage rating. (See the following chart.)
To remove the fuse use the pulling tool
attached to the inside cover of the fuse
panel. There are also four spare fuses
attached to the cover.
[ER05600( ALL)12/95]
eight pica chart:0001092-B[ER05800( BC )12/95]
eight pica chart:0011219-AFile:10rcerb.ex
Update:Thu May 30 11:01:08 1996

173
*
[ER05900( ALL)01/96]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[ER06000( BC )12/95]
4. Close the cover.
*
[ER06300( BCGV)04/96]
Even after you replace a fuse, it may continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
%*
[ER06400( ALL)01/96]
Circuit Breakers
*
[ER06500( ALL)12/95]
If you need to check a circuit breaker that is on
the fuse panel, seeChecking and replacing fusesin
this chapter to find out how to locate the fuse
panel.
[ER06600( ALL)12/95]
Circuit breakers will reset themselves and allow
the electrical parts to work again once the
overload on the circuit is removed. If the circuit
breakers continue to cut off electricity, have your
vehicle's electrical system checked.
*
[ER06700( ALL)01/96]
Diagnostic equipment is needed to check circuit
breakers. Refer to the manufacturer's
instructions.
*
[ER06800( ALL)01/96]
If you replace a circuit breaker, use one with the
same amperage rating. To remove a circuit
breaker mounted in the fuse panel, grip it with
your finger and thumb and pull it straight out
of its socket.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

174
%*
[ER07300( ALL)01/96]
If the Engine Cranks but Does
Not Start or Does Not Start After
a Collision
% [ER07400( ALL)12/95]
Fuel System Shut-off Switch
[ER07500( ALL)05/96]
If the engine cranks but does not start or does
not start after a collision, the fuel system shut-off
switch may have been activated. The shut-off
switch is a device intended to stop the fuel
system when your vehicle has been involved in
a substantial jolt.
*
[ER07600( BCGV)04/96]
Once the shut-off switch is activated, you must
reset the switch by hand before you can start
your vehicle. The switch is on the left side of the
trunk.
[ER07900( BC )12/95]
one third page art:0010013-E
The fuel pump shut-off switch
*
[ER08100( ALL)03/96]
RWARNING
If you see or smell fuel, do not reset the
switch or try to start your vehicle. Have
all the passengers get out of the vehicle
and call the local fire department or a
towing service.
File:10rcerb.ex
Update:Thu May 30 11:01:08 1996

175
*
[ER08200( ALL)03/96]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ER08300( ALL)01/96]
1. Turn the ignition key to the OFF position.
*
[ER08400( ALL)03/96]
2. Check under the vehicle for leaking fuel.
*
[ER08500( ALL)01/96]
3. If you do not see or smell fuel, push the red
reset button down. If the button is already
set, you may have a different mechanical
problem.
*
[ER08600( ALL)01/96]
4. Turn the ignition key to the ON position for
a few seconds, then turn it to the OFF
position.
*
[ER08700( ALL)03/96]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
*
[ER08800( ALL)01/96]
6. Check all vehicle warning lights before
driving the vehicle.
%
*
[ER09300( ALL)02/96]
Changing a Tire
*
[ER09400( ALL)02/96]
If you get a flat tire while you are driving, do
not apply the brake heavily. Instead, gradually
decrease the speed. Hold the steering wheel
firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off
the ignition, set the parking brake, and turn on
the hazard flashers.
%*
[ER09500( ALL)02/96]
The Temporary Spare Tire
[ER09700(MBC )02/96]
You have a high pressure temporary spare tire.
This spare tire is smaller than a regular tire and
is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon
as you can. This spare tire is marked with the
words ªTEMPORARY USE ONLYº so that you
can easily identify it.
