1997 FORD PROBE engine

185
*
[MC02000(ALL)01/96]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[MC02100(ALL)01/96]
q
Never get under a vehicle while it is
supported only by a jack. If you must work
under a vehicle, use safety stands.
*
[MC02200(ALL)01/96]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[MC02500(ALL)01/96]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
*
[MC02700(ALL)01/96]
Working with the engine off:
*
[MC02750(ALL)01/96]
1. Set the parking brake fully and make sure
the gearshift is securely latched in P (Park)
(automatic transaxle) or Neutral (manual
transaxle).
*
[MC02800(ALL)01/96]
2. Remove the key from the ignition after you
turn the engine off.
*
[MC02850(ALL)01/96]
3. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC02900(ALL)01/96]
Working with the engine on:
*
[MC03000(ALL)01/96]
1. Set the parking brake fully and make sure
the gearshift is securely latched in P (Park)
(automatic transaxle) or Neutral (manual
transaxle).
*
[MC03100(ALL)01/96]
2. Block the wheels. This will prevent your
vehicle from moving unexpectedly.
*
[MC03200(ALL)01/96]
RWARNING
Do not start your engine with the air
cleaner removed and do not remove it
while the engine is running.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

187
*
[MC04100(ALL)12/95]
NOTE: Apply lubricant to the hood latch at
six-month intervals to maintain smooth
and trouble-free operation.
*
[MC04200(ALL)01/96]
NOTE: Read and understandPrecautions When
Servicing Your Vehicleat the beginning
of this chapter before opening the
hood.
[MC04450(ALL)01/96]Engine Types
*
[MC04600(ALL)01/96]
Your vehicle has one of these types of engines:
[MC04700(ALL)01/96]
q
a 2.0L (121 CID) fuel injected 16-valve
four-cylinder engine.
[MC04800(ALL)01/96]
q
a 2.5L (152 CID) fuel injected 24-valve
six-cylinder engine.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

188 [MC05400(ALL)01/96]
three fourths page art:0032074-BThe 2.0L engine
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

189 [MC05500(ALL)01/96]
three fourths page art:0032081-E
The 2.5L engine
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

190
%*
[MC05600(ALL)01/96]
Engine Oil Recommendations
*
[MC05700(ALL)01/96]
We recommend using Motorcraft oil or an
equivalent oil meeting Ford Specification
WSS-M2C153-F and displaying the American
Petroleum Institute CERTIFICATION MARK on
the front of the container.
*
[MC05800(ALL)01/96]
one third page art:0060021-E
The API Certification Mark
*
[MC05900(ALL)01/96]
Neveruse:
*
[MC06000(ALL)01/96]
q
ªNon-Detergentº oils
*
[MC06100(ALL)02/96]
q
Oils labeled API SA, SB, SC, SD, SE, SF or SG
%*
[MC06200(ALL)01/96]
q
Additional engine oil additives, oil treatments
or engine treatments
%*
[MC06300(ALL)03/96]
Engine oils with anSAE 5W-30viscosity are
PREFERREDfor your vehicle. They provide the
best engine performance, fuel economy and
engine protection for all climates down to-15ÊF
(-25ÊC).
%*
[MC06400(ALL)03/96]
Synthetic engine oils which are CERTIFIED and
of the preferred viscosity may be used in your
engine. The engine oil and oil filter must still be
changed according to the maintenance schedule.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

191 %
*
[MC06500(ALL)01/96]
Checking and Adding Engine Oil
*
[MC06600(ALL)01/96]
Since the proper amount of engine oil is
important for safe engine operation, check the oil
using the dipstick each time you put fuel in
your vehicle. Remember the engine must be off,
the oil must be warm and the vehicle must be
parked on level ground.
%*
[MC06700(ALL)01/96]
Checking the engine oil level:
*
[MC06800(ALL)01/96]
1. Turn the engine off after it has warmed up
and allow a few minutes for the engine oil
to drain back into the oil pan.
*
[MC06900(ALL)01/96]
2. Set the parking brake fully and make sure
that the gearshift is securely latched in P
(Park) (automatic transaxle) or 1 (First)
(manual transaxle).
*
[MC07000(ALL)01/96]
3. Open the hood. Protect yourself from engine
heat.
*
[MC07100(ALL)01/96]
4. Locate the engine oil dipstick (highlighted in
yellow) and carefully pull it out of the
engine.
*
[MC07200(ALL)01/96]
5. Wipe the dipstick clean and put it back into
position, making sure it is fully seated.
[MC07300(ALL)01/96]
one inch art:0032075-A
Engine oil dipstick
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

192 [MC07400(ALL)01/96]6. Carefully, pull the dipstick out again. If the
oil level is below the L line, add engine oil
as necessary. If the oil level is beyond the
letter F, engine damage or high oil
consumption may occur and some oil must
be removed from the engine.
*
[MC07500(ALL)01/96]
7. Put the dipstick back in and make sure it is
fully seated.
%*
[MC07600(ALL)01/96]
Adding engine oil
*
[MC07700(ALL)01/96]
It may be necessary to add some oil between oil
changes. Make sure you use a CERTIFIED
engine oil of the preferred viscosity. Your
vehicle's warranty coverage may not apply if
engine damage is caused by the use of improper
engine oil.
*
[MC07800(ALL)01/96]
Add engine oil through the oil filler cap
highlighted in yellow. To add oil, remove the
filler cap and use a funnel to pour oil into the
opening. Be careful not to overfill the engine.
Recheck the oil level after you finish adding oil.
%*
[MC07900(ALL)01/96]
Changing the Engine Oil and the Oil Filter
*
[MC08000(ALL)01/96]
Change the engine oil and oil filterper the
following, whichever occurs first.
*
[MC08100(ALL)01/96]
one third page art:0060618-C
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

193
*
[MC08200(ALL)02/96]
Refer to theMaintenance Schedulebooklet for
additional information.
%*
[MC08250(ALL)05/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[MC08275(ALL)05/96]
NOTE: Ford production and aftermarket
(Motorcraft) oil filters are designed for
added engine protection and long life.
If a replacement oil filter is used that
does not meet Ford material and design
specifications, startup engine noises or
knock may be experienced. It is
recommended you use the appropriate
Motorcraft oil filter (or another brand
meeting Ford specifications) for your
engine application.
*
[MC08300(ALL)01/96]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[MC08400(ALL)01/96]
Protect your skin by washing with soap and
water.
%
*
[MC08450(ALL)05/96]
Brake Fluid
*
[MC08500(ALL)01/96]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake pads wear.
[MC08600(ALL)01/96]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic reservoir on the master cylinder. (SeeThe
Engine Typesearlier in this chapter to locate the
master cylinder.) The fluid level should be at or
near the MAX mark.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
