Air Conditioning System (If equipped)
[CF06800(ALL)01/96]
Operate the air conditioning by using the climate
controls on the center of the instrument panel.
[CF06900(ALL)01/96]
one third page art:0032041-A
Air conditioning controls
*
[CF06950(ALL)01/96]
Sometimes you may notice slight engine surging
if you have the air conditioner on. This is
normal, as the system is designed to cycle the
compressor on and off to maintain desired
cooling. The reduced compressor operation
should benefit fuel economy.
*
[CF07000(ALL)01/96]
On some vehicles with air conditioning,
wide-open throttle acceleration will temporarily
cut off the air conditioning.
*
[CF07050(ALL)01/96]
Since the air conditioner removes a lot of
moisture from the air during operation, it is
normal for water to drip on the pavement under
the air conditioner drain after you have stopped
the vehicle.
[CF07150(ALL)01/96]
Action for heating and windshield defrosting are
identical for cars equipped with either the
Heating Only Systemor theHeating and Air
Conditioning System. For instructions about these
functions, see the previous section,Heating Only
System. For instructions about using the air
conditioning, see the following sections.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

55
*
[CF08500(ALL)01/96]
To cool your vehicle using outside air:
[CF08600(ALL)01/96]
1. Turn the function selector control to NORM
A/C.
[CF08700(ALL)01/96]
2. Turn the temperature control all the way to
left to the blue (cool) area.
[CF08800(ALL)04/96]
3. Set the fan at the desired speed.
[CF08900(ALL)01/96]
In mild weather, setting the function selector
control in the VENT position will add cool air to
your vehicle without using the air conditioning.
You will get better fuel economy without using
the air conditioning.
*
[CF09000(ALL)01/96]
Engine Idle Speed Control System
*
[CF09100(ALL)01/96]
Genuine Ford air conditioning (either
factory-installed or dealer-installed) has an
engine idle speed control system that
compensates for engine speed loss that may
occur when the air conditioning compressor is
running. This idle speed control holds the engine
idle essentially constant, regardless of whether
the air conditioning system is on or off.
[CF09200(ALL)01/96]
NOTE: Whenever service to the air
conditioning system is required, make
sure the service facility uses a
refrigerant recycling system. These
systems will capture the refrigerant for
reuse. Releasing certain refrigerants
into the atmosphere is hazardous to the
environment.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

56
*
[CF09300(ALL)01/96]
Rear Window Defroster (If equipped)
[CF09400(ALL)01/96]
quarter page art:0032068-D
Rear window defroster button
[CF09500(ALL)01/96]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window. The rear window defroster
button is located on the lower right of the
instrument panel below the climate control
panel. This button is also used to activate your
heated power mirrors (if equipped).
*
[CF09600(ALL)03/96]
To defrost the rear window:
[CF09700(ALL)03/96]
1. Clear any snow and/or ice from the rear
window.
*
[CF09800(ALL)03/96]
2. Get in your vehicle and start the engine.
[CF09900(ALL)01/96]
3. Press the rear defrost button. The indicator
light turns on.
[CF10000(ALL)01/96]
The defroster turns off automatically after 15 to
25 minutes. If the window is not clear, turn on
the defroster again. It will also automatically
shut off any time the engine is shut off.
%*
[CF10100(ALL)03/96]
NOTE: Never use sharp instruments or
window cleaners with abrasives to
clean the inside of your rear window.
If you do, you may damage the heating
elements that are bonded to the inside
of the rear window and cause damage
to the rear window defroster.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

61
*
[CF15100(ALL)01/96]
Ignition
%*
[CF15200(ALL)01/96]
Understanding the Positions of the Ignition
[CF15300(ALL)01/96]
one third page art:0032054-A
Ignition lock cylinder
*
[CF15400(ALL)01/96]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[CF15500(ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
[CF15600(ALL)01/96]
To remove the key if you have a manual
transaxle, push the key in while turning it to the
LOCK position.
*
[CF15700(ALL)01/96]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[CF15800(ALL)01/96]
ACC (Accessory) allows some of your vehicle's
electrical accessories to operate while the engine
is not running.
*
[CF15900(ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

62
*
[CF16000(ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
%
*
[CF16010(ALL)02/96]
The Turn Signal Lever
*
[CF16020(ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF16030(ALL)02/96]
q
operate the headlamps and parking lamps
*
[CF16040(ALL)02/96]
q
operate the turn signals and cornering lamps
*
[CF16050(ALL)03/96]
q
turn the high beams on/off
*
[CF16060(ALL)03/96]
q
flash the lamps
*
[CF16070(ALL)02/96]
Headlamps and Parking Lamps
*
[CF16080(ALL)02/96]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[CF16100(ALL)01/96]
FIRST STOP Ð Turning the knob to the first
stop (g) will turn on the the license plate
lamps, parking lamps, side marker lamps, tail
lamps and instrument panel lamps.
[CF16200(ALL)03/96]
SECOND STOP Ð Turning the knob to the
second stop (B) will turn on the headlamps,
license plate lamps, parking lamps, side marker
lamps, tail lamps, and instrument panel lamps.
[CF16300(ALL)01/96]
quarter page art:0032032-A
Headlamp control
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

96 [SS02400(ALL)01/96]Your seat cushion power adjust lever is operated
by a motor. To avoid damage to the motor, you
should avoid operating this feature for an
extended period of time. You should also avoid
using the six-way power adjust lever
continuously with the engine stopped. This
could run down the battery.
[SS02500(ALL)01/96]
Use the lever to make only one adjustment at a
time.
%*
[SS02600(ALL)01/96]
Using the Split-Folding Rear Seat
*
[SS02700(ALL)01/96]
Your vehicle is equipped with split-folding rear
seats. One or both rear seatbacks can be folded
down to provide additional cargo space.
[SS02800(ALL)02/96]
NOTE: When folding down the rear seatback,
the seat belt tongue should be hanging
on the hook of the lower, side trim
panel, near the edge of the side of the
seat cushion.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

125
Starting
%*
[TO04100(ALL)01/96]
Fuel-Injected Engines
*
[TO04200(ALL)01/96]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[TO04500(ALL)01/96]
Starting Your Vehicle
%*
[TO05000(ALL)01/96]
Preparing to Start Your Vehicle
*
[TO05100(ALL)02/96]
RWARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO05200(ALL)01/96]
Before you start your vehicle, do the following:
*
[TO05300(ALL)01/96]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[TO05400(ALL)01/96]
2. Make sure the headlamps and other
accessories are turned off when starting.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996

126
*
[TO05500(ALL)01/96]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
*
[TO05600(ALL)01/96]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
%*
[TO05700(ALL)01/96]
Testing the Warning Lights
*
[TO05800(ALL)02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
%*
[TO06000(ALL)01/96]
Starting Your Engine
*
[TO06100(ALL)01/96]
To start your engine:
*
[TO06300(ALL)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO06320(ALL)01/96]
2. Keep your foot on the brake pedal and turn
the ignition key to the ON position.
*
[TO06330(ALL)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO06340(ALL)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO06400(ALL)05/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
