1997 FORD PROBE engine

158
*
[ER00940(ALL)03/96]
If your engine cranks but does not start after a
collision or substantial jolt:
*
[ER00950(ALL)03/96]
1. Turn the key in the ignition to the LOCK
position.
*
[ER00960(ALL)03/96]
2. Check under the vehicle for leaking fuel.
*
[ER00970(ALL)03/96]
3. If you do not see or smell fuel, push the red
reset button on the fuel pump shut-off
switch down.
[ER00980(ALL)03/96]
The reset switch on your vehicle is located on
the left side of the luggage compartment
under the carpet. The red reset button is
under the raised area of the rubber cover.
*
[ER00990(ALL)03/96]
4. Attempt to start your vehicle. If the vehicle
starts, let it run a few seconds, then turn the
key to the LOCK position.
*
[ER00995(ALL)03/96]
5. Check under the vehicle again for leaking
fuel.If you see or smell fuel, do not start
your vehicle again.If you do not see or
smell fuel, you can try to start your vehicle
again.
*
[ER02000(ALL)05/96]
Fuses
[ER02100(ALL)04/96]
If electrical parts in your vehicle are not
working, the system may have been overloaded
and blown a fuse. If a fuse blows, all the parts
of your vehicle that use the fuse will not work.
[ER02200(ALL)04/96]
Your vehicle has two fuse panels. The interior
fuse panel is below the instrument panel in front
of the driver's door. The main panel is under
the hood behind the battery.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

171
*
[ER08200(ALL)01/96]
2. Get out the spare tire and jack.
% [ER08300(ALL)01/96]
3. Remove any wheelcovers or hubcaps with
the tapered end of a wheel nut wrench.
Insert the handle of the wrench and twist it
against the inner wheelcover flange. Remove
any chrome nuts or plastic caps covering the
wheel lug nuts.
[ER08500(ALL)03/96]
4. Loosen the wheel lug nuts by pulling up on
the handle of the wrench one half-turn
counterclockwise. Do not remove the wheel
lug nuts until you raise the tire off the
ground.
%*
[ER08600(ALL)01/96]
Removing and Replacing the Tire
%*
[ER08700(ALL)01/96]
1. Find the jack notch next to the door of the
tire that you are changing. Put the jack in
the jack notch and turn the handle of the
jack clockwise until the wheel is completely
off the ground.
*
[ER08800(ALL)01/96]
RWARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

174 [ER09990(ALL)04/96]Your vehicle has metric (12 mm) wheel studs
and lug nuts. During wheel removal and
replacement, make certain that you use the same
lug nuts to reinstall the wheel or replace them
with nuts of the same metric size and threading.
*
[ER10000(ALL)01/96]
RWARNING
Installation of an English thread nut on a
metric stud (or vice-versa) will not
properly secure the wheel to the hub.
Damaged studs may result in wheel
separation and possible injury.
*
[ER10200(ALL)03/96]
5. Lower the vehicle by turning the jack handle
counterclockwise.
[ER10300(ALL)01/96]
6. Remove the jack and fully tighten the lug
nuts in the order shown in the illustration
under step 2.
[ER10700(ALL)01/96]
7. Put the tire, jack, and wrench away.
[ER10750(ALL)01/96]
8. Unblock the wheels.
%
*
[ER11000(ALL)02/96]
Jump-Starting Your Vehicle
[ER11100(ALL)01/96]
Your vehicle has a Motorcraft maintenance-free
battery. Your vehicle's battery may die if you
leave the lights on or any electrical equipment
on after you turn the engine off. If this happens,
you may be able to jump-start from a booster
battery to start your vehicle.
*
[ER11150(ALL)02/96]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

176 %
*
[ER11800(ALL)02/96]
Preparing Your Vehicle
*
[ER11900(ALL)02/96]
1. Your vehicle has a 12-volt starting system, so
you need to use a 12-volt jumper system.
You will damage your starting motor,
ignition system, and other electrical parts if
you connect them to a 24-volt power supply
(either two 12-volt batteries in series or a
24-volt generator set).
*
[ER12000(ALL)02/96]
2. Do not disconnect the battery of the disabled
vehicle. You could damage the vehicle's
electrical system.
*
[ER12100(ALL)02/96]
3. Park the booster vehicle close to the hood of
the disabled vehicle.Make sure the vehicles
do not touch each other.Set the parking
brake on both vehicles and stay clear of the
engine cooling fan and other moving parts.
*
[ER12200(ALL)02/96]
4. Check all battery terminals and remove any
excessive corrosion before you attach the
jumper cables.
%*
[ER12400(ALL)02/96]
Connecting the jumper cables
*
[ER12500(ALL)02/96]
1. Connect one end of the first jumper cable to
the positive (+) terminal of the discharged
battery. (You can connect either jumper cable
to the positive (+) terminal, as long as you
use the same cable for both positive
terminals.) Most jumper cables have a red
cable and a black cable. The red cable is
generally used for the positive terminals and
the black for the negative ones.
*
[ER12600(ALL)02/96]
2. Connect the other end of the first cable to
the positive (+) terminal of the booster
battery.
*
[ER12700(ALL)02/96]
3. Connect one end of the second cable to the
negative (S) terminal of the booster battery
Ð NOT to the discharged battery.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

177
*
[ER12800(ALL)01/96]
4. Connect the other end of the second cable to
a good metallic surface on the engine or
frame of the disabled vehicle.
*
[ER12900(ALL)02/96]
RWARNING
Do not connect the end of the second
cable to the negative (S) terminal of the
battery to be jumped. A spark may cause
an explosion of the gases that surround
the battery.
[ER13000(ALL)01/96]
two third page art:0030135-C
The sequence for connecting the jumper cables
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

178
*
[ER13100(ALL)02/96]
Jump-Starting
*
[ER13200(ALL)02/96]
1. Make sure that the jumper cables are not in
the way of moving engine parts, then start
the booster vehicle. Run the engine at a
moderate speed.
*
[ER13300(ALL)02/96]
2. Let the discharged battery charge for a few
minutes and then start the disabled vehicle.
It may take a couple of tries before the
vehicle starts. If the vehicle does not start
after several attempts, there may be a
different problem.
*
[ER13400(ALL)02/96]
3. When both vehicles are running, let them
idle for a few minutes to charge the
discharged battery.
%*
[ER13500(ALL)02/96]
Removing jumper cables
[ER13600(ALL)01/96]
1.Always remove the jumper cables in
reverse order.Remove the negative (-) end
of the jumper cable from the metallic surface
on the engine or frame of the disabled
vehicle.
*
[ER13700(ALL)03/96]
2. Remove the negative (S) cable from the
booster battery.
*
[ER13800(ALL)02/96]
3. Remove the positive (+) cable from the
booster battery.
*
[ER13900(ALL)02/96]
4. Remove the other end of the positive (+)
cable from the discharged battery.
*
[ER14000(ALL)02/96]
After the vehicle is started, let it idle for a while
to let the engine ªrelearnº its idle conditions.
Drive it around for a while with all electrical
accessories turned off to let the battery recharge.
Driveability may be deteriorated slightly until all
drive modes are ªrelearned.ºYou may need to
use a battery charger to fully recharge the
battery.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

183
Maintenance and Care
%*
[MC00300(ALL)01/96]
Service Made Easy
*
[MC00400(ALL)01/96]
Ford has two goals for servicing your vehicle.
*
[MC00500(ALL)01/96]
1. When we can, we design parts that do not
need to be serviced.
*
[MC00600(ALL)01/96]
2. We want to make servicing your vehicle as
easy as possible. To help you:
*
[MC00700(ALL)01/96]
q
We highlight do-it-yourself items in yellow in
the engine compartment so that you can find
them easily.
*
[MC00800(ALL)03/96]
q
When possible, we design parts that can be
replaced without tools.
*
[MC00900(ALL)02/96]
q
We give you a Maintenance Schedule that
makes tracking routine service for your
vehicle easy. The maintenance schedule is
located in theMaintenance Schedulebooklet.
*
[MC00925(ALL)01/96]
This chapter tells you about the basic parts that
you need to check and service regularly.
*
[MC00930(ALL)01/96]
If your vehicle needs professional servicing, your
dealership can provide the parts and service
required. Check yourWarranty Information Booklet
to find out which parts and services are covered.
Also see theCustomer Assistancechapter of this
Owner Guide.
*
[MC01000(ALL)03/96]
Ford Motor Company recommends that you
perform the Owner Maintenance Checks listed in
theMaintenance Schedulebooklet. These services
are important for the proper operation of your
vehicle. In addition to the conditions listed in
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

184the Owner Maintenance Checklist, be alert for
any unusual noise, vibration, or other indication
that your vehicle may need service. If you do
notice something unusual, see that your vehicle
is serviced promptly.
*
[MC01100(ALL)01/96]
Use only recommended fuels, lubricants, fluids,
and service parts that meet Ford Motor
Company specifications. Motorcraft parts are
designed and built to provide the best
performance in your vehicle. Using these parts
for replacement is your assurance that Ford-built
quality stays in your vehicle.
%*
[MC01150(ALL)05/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%
*
[MC01600(ALL)01/96]
Precautions When Servicing Your
Vehicle
*
[MC01700(ALL)01/96]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
%*
[MC01800(ALL)01/96]
q
Do not work on a hot engine. The engine
cooling fan may come on unexpectedly.
Always turn the engine off and let it cool.
*
[MC01850(ALL)05/96]
RWARNING
The cooling fan is automatic and may
come on at any time. Always disconnect
the negative terminal of the battery before
working near the fan.
*
[MC01900(ALL)01/96]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
