1997 FORD PROBE engine

139 [GF04800(ALL)05/96]
two third page art:0032064-E
Automatic shift lever
*
[GF04900(ALL)01/96]
Your automatic transaxle vehicle has a
console-mounted shift selector lever. You must
step on the brake pedal, start the engine, and
then push in the thumb button to move the shift
selector lever to the position you choose.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

140
*
[GF05000(ALL)05/96]
RWARNING
Hold the brake pedal down while you
move the gearshift lever from position to
position. If you do not hold the brake
pedal down, your vehicle may move
unexpectedly and injure someone.
*
[GF05010(ALL)04/96]
Shift-lock System (If equipped)
*
[GF05020(ALL)04/96]
For your safety, the automatic transaxle has a
shift-lock system, which prevents shifting the
transaxle out of the P (Park) position without
depressing the brake pedal when the ignition
key is in the ON position.
*
[GF05030(ALL)03/96]
To shift the transaxle out of the P (Park)
position:
*
[GF05040(ALL)03/96]
1. Depress and hold the brake pedal.
*
[GF05050(ALL)03/96]
2. Start the engine.
[GF05060(ALL)03/96]
3. Push in the thumb button and move the
shift selector lever.
[GF05070(ALL)03/96]
4. SeeShift Lock Emergency Overridein this
section for more information.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

144 [GF06300(ALL)01/96]
one inch art:0032053-AOverdrive OFF indicator light
[GF06400(ALL)01/96]
To return the transaxle to normal operation (1st
through 4th gears) press the O/D OFF button
again. The O/D OFF button may be used to
cancel Overdrive any time the vehicle is being
driven. Each time your vehicle is started, the
Overdrive system will automatically be in the
normal ªoverdrive onº mode and the light will
not be illuminated.
[GF06500(ALL)03/96]
If the light does not illuminate when the O/D
OFF button is pressed, or if the light flashes
when you are driving, have your vehicle
serviced at the first opportunity. If this
condition persists, damage could occur to the
transaxle.
[GF06600(ALL)01/96]
When to use Drive (D with Overdrive OFF)
[GF06700(ALL)01/96]
In Drive (Overdrive OFF), your vehicle
automatically upshifts or downshifts from 1st
through 4th gears as the vehicle speeds up or
slows down. It also downshifts when you need
extra acceleration to pass or when driving up a
hill.
[GF06800(ALL)01/96]
Selecting Drive (Overdrive OFF) will eliminate
the transaxle's tendency to ªhuntº between third
and fourth gears while driving over hilly terrain.
It also gives your vehicle more engine braking to
slow your vehicle than Overdrive does.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

145
*
[GF06900(ALL)05/96]
When to use 2 (Second)
[GF07000(ALL)01/96]
Use Second (2) to help drive up moderately
steep hills or when starting on slick surfaces. It
prevents the transaxle from frequently shifting
up and down. It also gives more engine braking
than Overdrive or Drive when going down hills.
[GF07100(ALL)01/96]
Do not go faster than 64 mph (102 km/h) with
the gearshift in the Second (2) position. If you
shift from Overdrive or Drive to Second because
of hilly terrain, your transaxle will automatically
downshift in the proper sequence.
*
[GF07200(ALL)01/96]
When to use 1 (First)
[GF07300(ALL)01/96]
When your vehicle is in First (1), it gives more
engine braking to slow your car than Drive (D
with Overdrive OFF) on downgrades.
[GF07400(ALL)01/96]
Do not go faster than 32 mph (50 km/h) in this
gear. You can upshift from First (1) into D
Position at any speed. If you shift from
Overdrive or Drive to First (1) because of hilly
terrain, your transaxle will automatically
downshift in the proper sequence.
[GF07500(ALL)04/96]
Reverse
[GF07600(ALL)01/96]
In the Reverse (R) position, the vehicle moves
only backward. Your vehicle must be stopped
before shifting into Reverse (R).
[GF07700(ALL)04/96]
Neutral
[GF07800(ALL)01/96]
In Neutral (N), the wheels of the transaxle are
not locked. Your vehicle will roll freely, even on
the slightest incline, unless the parking brake or
brakes are on.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

147
%*
[GF08500(ALL)01/96]
Driving with a Manual Transaxle
%*
[GF08600(ALL)01/96]
Using the Clutch
*
[GF08700(ALL)01/96]
After the engine starts, allow it to idle for a few
seconds. Then, hold your right foot on the brake
pedal, push the clutch pedal to the floor with
your left foot, and move the shift selector lever
into 1 (First) or R (Reverse).
*
[GF08800(ALL)01/96]
To move the vehicle, lift your right foot off the
brake pedal and slowly release the clutch pedal.
(You need to press down slowly on the
accelerator at the same time you release the
clutch pedal.)
*
[GF08900(ALL)01/96]
Do not drive with your foot resting on the
clutch pedal and do not use the clutch to hold
your vehicle at a standstill while waiting on a
hill. These actions will seriously reduce clutch
life.
*
[GF09000(ALL)01/96]
Driving with your foot resting on the clutch may
cause the vehicle to jerk sharply when pressing
or removing your other foot from the
accelerator.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

150
*
[GF10400(ALL)08/95]
Upshifting
[GF10500(ALL)04/96]
For normal acceleration, you should upshift at
the following speeds:
[GF10600(ALL)01/96]
eight pica chart:0032089-A[GF10700(ALL)01/96]
For cruising, you should upshift at the following
speeds.
[GF10800(ALL)01/96]
eight pica chart:0032090-A%*
[GF10900(ALL)01/96]
Downshifting
*
[GF11000(ALL)03/96]
When you slow down or climb a steep hill,
always downshift before the engine starts to lose
power. Downshifting reduces the chance of
stalling and gives your vehicle better acceleration
to increase speed again.
*
[GF11100(ALL)01/96]
When you drive down steep hills, downshifting
helps you keep a safe speed and helps prevent
unnecessary wear on the brakes.
*
[GF11200(ALL)01/96]
When you come to a stop, do not downshift
through each gear. Disengage the clutch and use
the brake as necessary. Downshifting through
the gears decreases your vehicle's fuel economy.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997

155
Roadside Emergencies
%*
[ER00300(ALL)03/96]
Hazard Flasher
*
[ER00400(ALL)01/96]
To alert other drivers to hazardous situations,
press the hazard flasher switch on the top of the
steering column. All the turn signals will flash
on and off at the same time. The flashers will
also operate while the brake pedal is applied. To
turn the flashers off, press the switch again.
*
[ER00500(ALL)01/96]
The flashers work whether your vehicle is
running or not. The flashers will work for up to
two hours when the battery is fully charged and
in good condition. They will not drain the
battery excessively unless they are left on for an
extended period of time.
[ER00600(ALL)01/96]
If the flashers run for longer than 2 hours while
your engine is not running, or if your battery is
not fully charged, your battery could be drained.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996

156 [ER00700(ALL)01/96]
half page art:0032030-AHazard warning flasher switch
*
[ER00800(ALL)01/96]
If the Engine Cranks but Does
Not Start or Starting After a
Collision
*
[ER00850(ALL)01/96]
The Fuel Pump Shut-off Switch
*
[ER00900(ALL)05/96]
If the engine cranks but does not start or if you
have had a collision, the fuel pump shut-off
switch may have been triggered. The shut-off
switch is a device that stops the fuel pump
when your vehicle has been involved in a
substantial jolt.
*
[ER00910(ALL)03/96]
Once the shut-off switch is activated, you must
reset the switch by hand before you can start
your vehicle.
File:10prerp.ex
Update:Thu Jun 13 09:57:39 1996
