1997 FORD PROBE engine

195
*
[MC09400(ALL)01/96]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
%
*
[MC09700(ALL)02/96]
Windshield Washer Fluid
%*
[MC09750(ALL)03/96]
Washer Fluid
[MC09800(ALL)01/96]
Check the level of the windshield washer fluid
every time you stop for fuel. The reservoir for
the windshield washer fluid is located in the
engine compartment. Visual inspection can
determine if the washer fluid is adequate. Do
not operate the washer when the reservoir is
empty.
[MC09900(ALL)01/96]
half page art:0032082-A
Windshield washer fluid reservoir
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

196
*
[MC10000(ALL)01/96]
RWARNING
Do not put windshield washer fluid in the
container for the engine coolant.
%*
[MC10100(ALL)02/96]
Use specially formulated windshield washer
fluid rather than plain water, because specially
formulated washer fluids contain additives that
dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such
as methanol should be used in freezing weather
(temperatures below32ÊF [0ÊC]).State or local
regulations on Volatile Organic Compounds
(VOCs) may restrict use of the most common
antifreeze, methanol. Washer fluids containing
non-methanol antifreeze agents should be used
only if they provide cold weather protection
without damaging the vehicle's paint finish,
wiper blades, and windshield washer system.
%
*
[MC10500(ALL)01/96]
Engine Coolant
*
[MC10600(ALL)05/96]
Adding Engine Coolant
[MC10620(ALL)05/96]
RWARNING
Be careful not to add engine coolant to
the windshield washer fluid reservoir. If
sprayed on the windshield, engine coolant
could make it difficult to see through the
windshield.
*
[MC10640(ALL)05/96]
When the engine is cool, add a 50/50 mixture of
engine coolant and water to the engine coolant
recovery reservoir Ð DO NOT ADD DIRECTLY
TO THE RADIATOR. Add straight water only in
an emergency, but you should replace it with a
50/50 mixture of coolant and distilled water as
soon as possible.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

197 [MC10660(ALL)05/96]
one inch art:0032038-B
*
[MC10680(ALL)05/96]
Check the coolant level in the coolant recovery
reservoir the next few times you drive the
vehicle. If necessary, add enough of a 50/50
mixture of coolant and water to bring the liquid
level to the fill line on the reservoir.
[MC10700(ALL)05/96]
RWARNING
Never remove the coolant recovery cap
while the engine is running or hot.
*
[MC10720(ALL)05/96]
If you must remove the coolant recovery cap,
follow these steps to avoid personal injury
caused by escaping steam or engine coolant:
*
[MC10740(ALL)05/96]
1. Before you remove the cap, turn the engine
off and let it cool.
*
[MC10760(ALL)05/96]
2. When the engine is cool, wrap a thick cloth
around the cap and turn it slowly,
counterclockwise to the first stop.
*
[MC10780(ALL)05/96]
3. Step back while the pressure releases.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

198
*
[MC10800(ALL)05/96]
4. When you are sure that all the pressure has
been released, use the cloth to press the cap
down, turn it counterclockwise, and remove
it.
[MC10820(ALL)05/96]
Use Ford Premium Engine Coolant
E2FZ-19549-AA (in Canada, Motorcraft CXC-8-B)
or an equivalent premium engine coolant that
meets Ford specification ESE-M97B44-A. Ford
Premium Engine Coolant is an optimized
formula that will protect all metals and rubber
elastomers used in Ford cooling systems for 4
years or 50,000 miles (80,000 km).
[MC10840(ALL)05/96]
Do not use alcohol or methanol antifreeze or any
engine coolants mixed with alcohol or methanol
antifreeze. Do not use supplemental coolant
additives in your vehicle. These additives may
harm your engine cooling system.The use of an
improper coolant may void the warranty of
your vehicle's engine cooling system.
[MC10860(ALL)05/96]
Recycled engine coolant
*
[MC10880(ALL)05/96]
Ford Motor Company recommends that Ford
and Lincoln-Mercury dealers use recycled engine
coolant produced by Ford-approved processes.
Not all coolant recycling processes produce
coolant which meets Ford specification
ESE-M97B44-A, and use of such coolant may
harm engine and cooling system components.
*
[MC10900(ALL)05/96]
Always dispose of used automotive fluids in a
responsible manner. Follow your community's
regulations and standards for recycling and
disposing of automotive fluids.
[MC10920(ALL)05/96]
Coolant refill capacity
[MC10940(ALL)05/96]
To find out how much fluid your vehicle's
cooling system can hold, seeRefill capacitiesin
theCapacities and Specificationschapter.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

199 [MC10960(ALL)05/96]
Have your dealer check the engine cooling
system for leaks if you have to add more than a
quart (liter) of engine coolant each month.
[MC10980(ALL)05/96]
Severe winter climate
*
[MC11000(ALL)05/96]
If you drive in extremely cold climates (less than
S34ÊF [S36ÊC]), it may be necessary to increase
the coolant concentration above 50%. Refer to
the chart on the coolant container to ensure the
coolant concentration in your vehicle is such that
the coolant will not freeze at the temperature
level in which you drive during winter months.
Never increase the engine coolant concentration
above 60%. Leave a 50/50 mixture of engine
coolant and water in your vehicle year-round in
non-extreme climates.
%*
[MC16100(ALL)01/96]
Checking Hoses
*
[MC16200(ALL)04/96]
Check all engine and heater system hoses and
hose connections for deterioration, leaks, and
loose hose clamps as specified in themaintenance
schedule. Repair or replace with Motorcraft hoses
or equivalent as necessary.
%
*
[MC17000(ALL)01/96]
Power Steering Fluid
*
[MC17100(ALL)01/96]
Check the level of the power steering fluid at
least twice a year (i.e., every Spring and Fall).
%*
[MC17200(ALL)01/96]
Checking and Adding Power Steering
Fluid
*
[MC17300(ALL)04/96]
1. Start the engine and let it run until the
power steering fluid reaches normal
operating temperature. The power steering
fluid will be at the right temperature when
the engine coolant temperature gauge in the
instrument cluster is near the center of the
NORMAL operating temperature range.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

200
*
[MC17400(ALL)01/96]
2. While the engine idles, turn the steering
wheel back and forth several times. Make
sure that the cap assembly is installed at this
time.
*
[MC17500(ALL)01/96]
3. Turn the engine off and check the level on
the power steering reservoir.
[MC17600(ALL)01/96]
one third page art:0032043-A
Where to check for power steering fluid
[MC17700(ALL)01/96]
4. Remove the dipstick to read the power
steering fluid level. If the power steering
fluid is low, add fluid in small amounts,
continuously checking the level, until you
reach the HIGH line. Do not overfill. To find
out how much fluid your vehicle's power
steering fluid reservoir will hold, seeRefill
capacities for fluidsin the Index.
[MC17800(ALL)01/96]
5. When you are finished, put the dipstick back
in and make sure that it fits snugly.
*
[MC17900(ALL)01/96]
If the power steering fluid is low, do not drive
your vehicle for a long period of time before
adding fluid. This can damage the power
steering pump.
*
[MC18000(ALL)04/96]
If you must check the power steering fluid
before it reaches normal operating temperature,
make sure that the fluid reaches the ªLº (LOW)
line range in the reservoir. The reading will only
be accurate if the fluid temperature is
approximately 70Ê to100ÊF (21Ê to 38ÊC).
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

201
%*
[MC18100(ALL)01/96]
Automatic Transaxle Fluid
*
[MC18200(ALL)02/96]
Under normal circumstances, you do not need to
check the fluid level of the transaxle, since your
vehicle does not use up transaxle fluid. Refer to
theMaintenance Schedulebooklet for replacement
intervals. However, if the transaxle is not
working properly Ð for instance, the transaxle
may slip or shift slowly, or you may notice
some sign of fluid leakage Ð the fluid level
should be checked.
[MC18300(ALL)01/96]
If you must check the transaxle fluid in an
emergency, make sure that your vehicle is on
level ground, start the engine, and move the
gearshift through all of the gears allowing
sufficient time for each position to engage.
Securely latch the gearshift in P (Park). Set the
parking brake and leave the engine running.
[MC18400(ALL)01/96]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube. Make sure the
dipstick is fully seated in the filler tube;
otherwise, you will not get an accurate reading.
Pull the dipstick out and read the fluid level.
[MC18500(ALL)01/96]
The fluid level must be above the lower mark. If
it is not, you should not drive your vehicle until
more fluid is added. Ideally, the fluid level
should be within the specified area of the
dipstick.
[MC18600(ALL)01/96]
NOTE: The fluid level indication on the
dipstick will be different at operating
temperature and room temperature. For
the correct fluid level reading on the
dipstick, follow the appropriate
instructions.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

202 [MC18700(ALL)01/96]At normal operating temperature (approximately
20 miles [32 km] of vehicle operation), the level
on the dipstick should be within the specified
area on the ªSafe level when hotº temperature
scale. At room temperature, the level should be
within the specified area on the ªSafe level when
coldº temperature scale. If your vehicle has not
been operated for some time and outside
temperature is below50ÊF (10ÊC) thefluid must
be warmed by running the engine.
[MC18800(ALL)01/96]
one third page art:0032096-A
Automatic transaxle fluid dipstick on 2.5L engine vehicles
[MC18850(ALL)01/96]
one third page art:0032151-B
Automatic transaxle fluid dipstick on 2.0L engine vehicles
