1997 FORD PROBE engine

232 %
*
[MC62000(ALL)01/96]
Cleaning the Exterior Lamps
*
[MC62100(ALL)01/96]
Do not use dry paper towel, chemical solvents
or abrasive cleaners to clean the lamps, as these
may cause scratches or crack the lamps.
*
[MC63000(ALL)01/96]
Cleaning the Engine
*
[MC63100(ALL)01/96]
A clean engine is more efficient because the
engine is able to cool properly. A build up of
grease and dirt acts as an insulator, keeping the
engine warmer than normal.
*
[MC63200(ALL)01/96]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[MC63300(ALL)04/96]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[MC63400(ALL)04/96]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[MC63500(ALL)01/96]
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%*
[MC63600(ALL)03/96]
Cleaning the Wheels
*
[MC63700(ALL)03/96]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[MC63800(ALL)03/96]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

235
*
[MC71200(ALL)01/96]
q
Lubricate all hood, door and trunk lid hinges
and latches with a light grade oil.
*
[MC71300(ALL)01/96]
q
Cover interior soft trim to prevent fading.
*
[MC71400(ALL)01/96]
q
Keep all rubber parts free from oil and
solvents.
%*
[MC71500(ALL)01/96]
Engine
*
[MC71600(ALL)01/96]
q
Start engine every 15 days. Run at fast idle
until it reaches normal operating temperature.
*
[MC71700(ALL)01/96]
q
With your foot on the brake, shift through all
the gears while the engine is running.
%*
[MC71800(ALL)01/96]
Fuel system
%*
[MC71900(ALL)01/96]
q
Fill fuel tank with high-quality unleaded fuel
until the first automatic shutoff of the fuel
pump nozzle.
*
[MC72000(ALL)01/96]
NOTE: During extended periods of vehicle
storage (60 days or more), fuel may
deteriorate due to oxidation. This can
damage rubber and other polymers in
the fuel system and may also clog
small orifices.
*
[MC72100(ALL)01/96]
Ford Gas Stabilizer should be added whenever
actual or expected storage periods exceed 60
days. Follow the instructions on the label. The
vehicle should then be operated at idle speed to
circulate the additive throughout the fuel system.
*
[MC72200(ALL)01/96]
A volatile corrosion inhibitor added to the fuel
system will protect the fuel system's inner
surfaces from corrosion. Follow the instructions
packaged with the product.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

254
%*
[HS06400(ALL)05/96]
Getting Help Outside the U.S.
and Canada
*
[HS06500(ALL)05/96]
Before you export your vehicle to a foreign
country, contact the appropriate foreign embassy
or consulate to make sure local regulations do
not prevent you from registering your vehicle.
Officials at the embassy can also help you decide
whether you should import your vehicle to that
country.
*
[HS06600(ALL)06/95]
Officials at the embassy or consulate can tell you
where to get unleaded fuel. If you cannot get
unleaded fuel or can get only fuel with an
anti-knock index that is lower than your vehicle
needs, contact a district or owner relations office
before you leave the U.S. or Canada.
*
[HS06700(ALL)05/96]
Use of leaded fuel in your vehicle without a
proper conversion may damage the effectiveness
of your emissions control system and may cause
engine knocking or serious engine damage. Ford
Motor Company is not responsible for any
damage that is caused by use of improper fuel.
*
[HS06800(ALL)06/95]
You may also have difficulty importing your
vehicle back into the U.S. if you use leaded fuel.
File:14prhsp.ex
Update:Wed May 15 15:04:50 1996

259
*
[AC01400(ALL)05/96]
NOTE: The Federal Communications
Commission (FCC) or the Canadian
Radio Telecommunications Commission
(CRTC) regulates the use of mobile
communications systems Ð such as
two-way radios, telephones, and theft
alarms Ð that are equipped with radio
transmitters. Any such equipment
installed in your vehicle should comply
with FCC or CRTC regulations and
should be installed only by a qualified
technician.
*
[AC01500(ALL)05/96]
NOTE: Mobile communications systems may
harm the operation of your vehicle,
particularly if they are not properly
designed for automotive use or are not
properly installed. For example, when
operated, such systems may cause the
engine to stumble or stall. In addition,
such systems may themselves be
damaged or their operation affected by
operating your vehicle. (Citizens band
[CB] transceivers, garage door openers,
and other transmitters whose power
output is 5 watts or less will not
ordinarily affect your vehicle's
operation.)
*
[AC01600(ALL)05/96]
NOTE: Because we have no control over the
installation, design, or manufacture of
such systems, Ford cannot assume
responsibility for any adverse effects or
damage that may result if you use this
equipment.
File:15pracp.ex
Update:Mon Jun 3 10:09:16 1996

273 [QI02700(ALL)05/96]
full page art:0032136-I
2.0L Engine Compartment
File:16prqip.ex
Update:Wed Jun 12 10:25:51 1996

274 [QI02800(ALL)07/95]
full page art:0032137-H2.5L Engine Compartment
File:16prqip.ex
Update:Wed Jun 12 10:25:51 1996

Index 275
Index
A
ABS warning light
(see Anti-lock brake system)....... 13
Accessory position on the ignition..... 61
Additives, engine oil.......... 190
Air bag supplemental restraint system
and child safety seats......... 113
description............104, 106
driver air bag..........104, 106
indicator light............. 11
operation.............. 106
passenger air bag........... 106
service and information labels..... 106
tone generator............ 110
Air cleaner filter, specifications...... 237
Air conditioning, electronic automatic
temperature control system....... 49
Aluminum wheels............ 214
Antenna, radio (see Electronic
sound system)........... 21,43
Antifreeze (see Engine coolant)...... 196
Anti-lock brake system (ABS)
description.............. 133
see also Brake............ 133
warning light.............. 13
warninig light............. 12
Assistance (see Customer assistance) . . . 245
Audio system (see Electronic
sound system)............. 21
Autolamp system (see Headlamps)..... 63
Automatic transaxle
driving with............. 138
fluid, adding............. 201
fluid, checking............ 201
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996

Index 277
Bulbs, replacing
halogen............... 226
headlamps.............. 226
C
Canada, customer assistance....... 252
Canada, warranty information....... 4
Canadian Motor Vehicle Arbitration Plan
(CAMVAP).............. 253
Carbon monoxide in exhaust....... 130
Car seats for children
(see Child safety seats)........ 113
Cassette tape player (see Electronic
sound system)............. 34
Catalytic converter........... 222
CD player (see Electronic sound system) . . 28
Chains, tires.............. 214
Changing a tire............. 167
Child safety restraints.......... 111
child safety seats........... 113
Child safety seats
and air bags............. 113
attaching with tether straps...... 122
automatic locking mode
(retractor)...........102, 113
in front seat............. 113
in rear outboard seat......... 113
in rear seat.............. 113
tether anchorage hardware...... 122
Chime, safety belt............. 11
Cleaning your vehicle
CD player and discs.......... 31
chrome and aluminum parts...... 231
engine compartment......... 232
exterior............... 230
exterior lamps............ 232
fabric................ 233
headlamps.............. 232
instrument panel.......... 49,231
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996
