1997 FORD PROBE engine

204
*
[MC19700(ALL)01/96]
If you see any corrosion on the battery cables or
terminals, remove the cables from the terminal
and clean them both with a wire brush. You can
neutralize the acid with a solution of baking
soda and water. Reinstall the cables when you
are done cleaning them, and apply a small
quantity of grease to the top of each battery
terminal to help prevent corrosion.
*
[MC19800(ALL)01/96]
Battery replacement
[MC19900(ALL)01/96]
When the original equipment maintenance-free
battery is replaced under warranty, it may be
replaced by a low-maintenance battery.
[MC19950(ALL)01/96]
The low-maintenance battery has removable vent
caps for checking the electrolyte level and
adding water, if necessary.
[MC20000(ALL)01/96]
The electrolyte level should be checked at least
every 24 months or 24,000 miles (40,000 km) in
temperatures up to90ÊF (32ÊC) andmore in
temperatures above90ÊF (32ÊC).Keep the
electrolyte level in each cell up to the level
indicator. Do not overfill.
[MC20100(ALL)01/96]
If the level gets low, you can add plain tap
water to the battery, provided the water isn't
hard or doesn't have a high mineral or alkali
content. However, if possible, refill with distilled
water. If the battery needs water quite often,
have the charging system checked for a possible
problem.
[MC20200(ALL)01/96]
If you ever disconnect the battery or install a
new battery, you must allow the computer to
ªrelearnº its idle condition before your vehicle
will drive properly. To begin this process, put
the gearshift in P (Park) (automatic transaxle) or
N (Neutral) (manual transaxle), set the
emergency brake, turn off all the accessories, and
start the vehicle. Bring the engine to normal
operating temperature.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

205
*
[MC20300(ALL)01/96]
If you do not let the engine relearn its idle, the
idle quality of your vehicle may be adversely
affected until the idle is relearned. Your vehicle
will eventually relearn its idle while you drive
it, but it takes much longer than if you use the
previous procedure.
%*
[MC20400(ALL)01/96]
Help Us Protect Our Environment
*
[MC20500(ALL)01/96]
Ford Motor Company strongly recommends that
used lead-acid batteries be returned to an
authorized recycling facility for disposal.
*
[MC20600(ALL)01/96]
one inch art:0000983-A
Battery recycling symbol
*
[MC20700(ALL)02/96]
RWARNING
The gases around the battery can explode
if exposed to flames, sparks, or lit
cigarettes. An explosion could result in
injury or vehicle damage.
*
[MC20800(ALL)02/96]
RWARNING
To protect yourself when charging a
battery, always shield your face and eyes.
Make sure that you can breathe fresh air.
%*
[MC20900(ALL)05/96]
RWARNING
Batteries contain sulfuric acid which burns
skin, eyes, and clothing.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

218refuel, your vehicle can be operated on
non-California fuels. However, even though your
engine will perform adequately on other
gasolines, the performance of the emission
control devices and systems may be adversely
affected. Repair of damage caused by using a
fuel that your vehicle was not designed for may
not be covered by your warranty.
[MC31800(ALL)03/96]
Octane Recommendations
[MC31900(ALL)03/96]
Your 2.0L engine is designed to use regular
gasoline with an (R+M)/2 octane rating of 87.
We do not recommend gasolines labeled as
ªregularº in high altitude areas that are sold
with octane ratings of 86 or even less.
[MC32000(ALL)03/96]
Your 2.5L engine is designed to use premium
gasoline for optimum performance with an
(R+M)/2 octane rating of 91 or higher. Gasolines
with lower octane ratings can be used, but
performance may decrease. We do not
recommend gasolines labeled as ªpremiumº in
high altitude areas that are sold with octane
ratings less than 91.
*
[MC32100(ALL)05/96]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane fuel, see your dealer or a
qualified service technician to prevent any
engine damage.
*
[MC32200(ALL)05/96]
Fuel Quality
*
[MC32300(ALL)05/96]
If you are experiencing starting, rough idle or
hesitation problems try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[MC32400(ALL)05/96]
The American Automobile Manufacturers
Association (AAMA) issued a gasoline
specification to provide information on high
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

220
*
[MC34350(ALL)08/95]
q
Avoid breathing vapors while refueling.
*
[MC34400(ALL)08/95]
q
If fuel is splashed on the skin, wash with
soap and water.
*
[MC34500(ALL)08/95]
q
If fuel is splashed in the eyes, remove contact
lenses (if worn), flush with water for 15
minutes, and seek medical attention.
*
[MC34600(ALL)01/96]
Gasoline and gasoline blends may contain small
amounts of carcinogens, such as benzene.
Long-term exposure to unleaded gasoline vapors
has caused cancer in laboratory animals.
*
[MC34700(ALL)01/96]
If you are taking the medication ªAntabuseº or
other forms of disulfiram for the treatment of
alcoholism, vapor or skin contact with a
gasoline-methanol blend may cause the same
kind of adverse reaction as drinking an alcoholic
beverage. In sensitive individuals, serious
personal injury or sickness could result. Consult
a physician promptly if you experience an
adverse reaction.
%*
[MC34800(ALL)01/96]
Running Out of Fuel
*
[MC34900(ALL)08/95]
NOTE: Avoid running out of fuel because this
situation may have an adverse effect on
modern powertrain components.
*
[MC35000(ALL)01/96]
You may need to crank the engine several times
before the fuel system starts to pump fuel from
the tank to the engine.
%*
[MC35100(ALL)03/96]
Fuel Economy
*
[MC35150(ALL)01/96]
Fuel economy is an estimate of the efficiency of
your vehicle and can be calculated as Miles Per
Gallon (MPG) or Liters Per 100 Kilometers
(L/100K).
*
[MC35200(ALL)01/96]
Do not calculate fuel economy during your
vehicle's break-in period. This would not be an
accurate estimate of how much fuel your vehicle
will normally use.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

221
*
[MC35300(ALL)01/96]
To calculate fuel economy:
*
[MC35400(ALL)01/96]
1. Fill the tank completely and record the
initial odometer reading.
*
[MC35500(ALL)01/96]
2. Every time you buy fuel record the
amount (in gallons or liters) purchased.
*
[MC35600(ALL)01/96]
3. After at least three to five tankfuls, fill the
fuel tank and record the final odometer
reading.
*
[MC35700(ALL)01/96]
4. Use these equations to calculate your fuel
economy:
*
[MC35800(ALL)01/96]
q
English: MPG = (total miles driven)v
(gallons used)
*
[MC35900(ALL)01/96]
q
Metric: L/100k = (liters used)v
(100 kilometers)
*
[MC36000(ALL)01/96]
Comparisons With EPA Estimates
*
[MC36100(ALL)05/96]
EPA fuel economy figures are obtained from
laboratory tests under simulated road conditions
and may not reflect the actual conditions you
experience or your style of driving. The EPA
fuel economy estimate is not a guarantee that
you will achieve the fuel economy shown.
*
[MC36200(ALL)01/96]
The following decrease fuel economy:
*
[MC36300(ALL)01/96]
q
Lack of regular, scheduled maintenance
*
[MC36400(ALL)01/96]
q
Rapid acceleration and excessive speed
*
[MC36500(ALL)01/96]
q
Driving with your foot on the brake
*
[MC36550(ALL)01/96]
q
Sudden stops
*
[MC36600(ALL)01/96]
q
Extended engine idling
*
[MC36660(ALL)01/96]
q
Using speed control in hilly terrain
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

223
*
[MC38500(ALL)01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC38600(ALL)01/96]
q
Use only unleaded fuel.
*
[MC38700(ALL)01/96]
q
Avoid running out of fuel.
*
[MC38800(ALL)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC38900(ALL)01/96]
q
Do not push start your vehicle.
*
[MC38950(ALL)03/96]
q
Have the services listed in yourMaintenance
Schedulebooklet performed according to the
specified schedule.
*
[MC39000(ALL)01/96]
RWARNING
Do not park, idle, or drive your vehicle in
dry grass or other dry ground cover. The
emission system heats up the engine
compartment and exhaust system, which
can start a fire.
*
[MC39100(ALL)01/96]
Watch for fluid leaks, strange odors, smoke, loss
of oil pressure, the charge warning light, the
check engine light, or the temperature warning
light. These sometimes indicate that the emission
system is not working properly.
*
[MC39200(ALL)01/96]
Do not make any unauthorized changes to your
vehicle or engine. Changes that cause more
unburned fuel to reach the exhaust system can
increase the temperature of the engine or
exhaust system.
%*
[MC39300(ALL)01/96]
In general, maintenance, replacement, or service
of the emission control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those with which your vehicle or engine was
originally equipped.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

224
*
[MC39400(ALL)01/96]
By law, anyone who manufactures, repairs,
services, sells, leases, trades vehicles, or
supervises a fleet of vehicles is not permitted to
intentionally remove an emission control device
or prevent it from working. In some of the
United States and in Canada, vehicle owners
may be liable if their emission control device is
removed or is prevented from working.
*
[MC39500(ALL)08/95]
Never use a metal exhaust collector when you
service your vehicle. If the metal collector
contacts any of your vehicle's plastic trim or
bumper parts they could melt or deform.
*
[MC39600(ALL)01/96]
Do not drive your vehicle if it does not operate
properly. See your dealer if the engine runs on
for more than five seconds after you shut it off
or if it misfires, surges, stalls, or backfires.
%*
[MC39700(ALL)01/96]
Information about your vehicle's emission
control system is on the Vehicle Emission
Control Information decal located on or near the
engine. This decal identifies engine displacement
and gives some tune-up specifications.
%*
[MC39800(ALL)03/96]
How to Prepare Your Vehicle for
Inspection/Maintenance (I/M) Testing
*
[MC39900(ALL)05/96]
In some localities it may become a legal
requirement to pass an
Inspection/Maintenance (I/M) test of the
On-Board Diagnostic (OBD) II system. If the
vehicle's powertrain system or its battery has
just been serviced, the OBD II system is reset to
a not ready for I/M testing condition. To
prepare for I/M testing, the law specifies that
additional mixed city and highway driving is
required to complete the check of the OBD II
system.
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996

225
*
[MC39910(ALL)03/96]
The driving modes required to reach the ready
condition consist of a minimum of 30 minutes of
city and highway driving as described below.
*
[MC39920(ALL)03/96]
q
20 minutes of driving in stop and go
city-type traffic with at least four idle periods.
*
[MC39930(ALL)03/96]
q
10 minutes of driving on an expressway or
highway
*
[MC39940(ALL)05/96]
Before completing the above driving modes, the
engine must be warmed up and at operating
temperature. Once started, the vehicle must not
be turned off during the above driving modes. If
the vehicle owner is unable to meet the I/M
requirements by using these driving patterns, an
authorized service center can perform a detailed
OBD II drive cycle as it would any other type of
repair work.
%
*
[MC42000(ALL)03/96]
Lights and Bulb Replacement
*
[MC42100(ALL)01/96]
It is a good idea to check the operation of the
following lights frequently:
*
[MC42200(ALL)01/96]
q
headlamps
*
[MC42400(ALL)01/96]
q
tail lamps
*
[MC42500(ALL)01/96]
q
brakelamps
*
[MC42600(ALL)01/96]
q
hazard flasher
*
[MC42700(ALL)01/96]
q
turn signals
*
[MC42800(ALL)01/96]
q
side markers
*
[MC42900(ALL)05/96]
q
license plate lamps
[MC43000(ALL)01/96]
q
fog lamps (GT model)
File:11prmcp.ex
Update:Thu May 16 12:08:53 1996
