Rear window defroster
Press the defroster control to clear
the rear window of thin ice and
fog.
²The small LED will illuminate
when the defroster is activated.
The ignition must be in the ON
position to operate the rear
window defroster.
The defroster turns off
automatically after 10 minutes or
when the ignition is turned to the
OFF position. To manually turn off
the defroster before ten minutes
have passed, push the control
again.
P
exd_parking_brake_location
Controls and features
26
Page 26 of 224
Parking brake
For information on the parking
brake, refer toPreparing to start
the vehiclein theDriving
chapter.
CLIMATE CONTROL
Operating the instrument panel
controls
BRAKE
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3
FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
FLR
& DEF *MAX
A/CFLOOR PANEL &
FLOOR
DEF OFF
PANEL
*A/CWARM COOL
LO
HI
exd_climate_overview_art
exd_title_climate_controls
exd_vents_climate_controls
Controls and features
27
Page 27 of 224
Instrument panel vents
There are four vents on the
instrument panel. These vents are
equipped with dials to adjust the
amount and direction of air passing
through them.
Temperature
Turn temperature control to the
desired temperature.
WARM COOL
exd_temperature_control
exd_fan_speed_climate
Controls and features
28
Page 28 of 224
Fan speed
Turn the fan speed control to the
desired speed.
Airflow and air conditioning
Turn the mode control to the
desired airflow position.
Controlling airflow
Select PANEL for air to flow
through these vents:
The PANEL position allows outside
air to flow through the instrument
panel vents.
LO
HI
FLR
& DEF MAX
A/CFLOOR PANEL &
FLOOR
DEF OFF
PANEL
A/C
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
exd_mode_control
exd_airflow
Controls and features
29
Page 29 of 224
Select PANEL & FLOOR for air to
flow through these vents:
The PANEL & FLOOR position
directs outside air to flow between
the panel and floor vents. The air
conditioning system will function
in this mode provided the outside
temperature is above 10ÉC (50ÉF).
Select FLOOR for air to flow
through these vents:
The FLOOR position directs
outside air to flow through the
floor vents.
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
Controls and features
30
Page 30 of 224
Select FLR & DEF for air to flow
through these vents:
The FLR & DEF position directs
outside air to flow through the
floor vents and the windshield
defroster vents. The air
conditioning system will function
in this mode provided the outside
temperature is above 10ÉC (50ÉF).
Select
for air to flow through
these vents:
The
position directs outside
air to flow through the windshield
defroster vents. The air
conditioning system will function
in this mode provided the outside
temperature is above 10ÉC (50ÉF).
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
exd_ac
Controls and features
31
Page 31 of 224
Air conditioning
Select A/C for air conditioned air
to flow through these vents:
The A/C mode directs outside air
conditioned air to flow through the
instrument panel vents. The A/C
mode can be used for heating,
ventilating and defogging the
windows or air conditioning. The
A/C system only functions if the
outside temperature is above 10ÉC
(50ÉF).
Select MAX A/C for air to flow
through these vents:
The MAX A/C mode recirculates
the cabin air and directs it to flow
through the instrument panel
vents. This mode is noisier but
more economical than the A/C
mode. The air conditioning system
only functions if the outside
temperature is above 10ÉC (50ÉF).
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
d
PHI LOOFF*A/C*MAX
A/CREW
1FF
2SIDE 1-2
3FM 1STVOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLKSEEKTUNE
DISCSSCAN4DOLBY SYSTEMEJTAPE CDCOMP5SHUFFLE
6
d
Controls and features
32
Page 32 of 224
OFF position
Select the OFF position for all
climate control functions to cease.
The outside inlet door will close
and the fan is shut off.
Maximum heating
Set mode control to FLOOR, turn
temperature control to maximum
heat (red) and set fan speed
control to HI.
Maximum cooling
Set mode control to MAX A/C, turn
the temperature control to
maximum cool (blue) and set fan
speed control to HI.
FLR
& DEF *MAX
A/CFLOOR PANEL &
FLOOR
DEF OFF
PANEL
*A/CWARM COOL
LO
HI
FLR
& DEF *MAX
A/CFLOOR PANEL &
FLOOR
DEF OFF
PANEL
*A/CWARM COOL
LO
HI
exd_max_heat exd_max_cooling
exd_ventilating
