1997 FORD EXPEDITION Owners Manual

ENGINE DATA
Component 4.6 L engine 5.4 L engine
Required fuel grade 87 octane
Induction system tuned runner & plenum
Firing order/ijection timing 1-3-7-2-6-5-4-8
Spark plug gap .054
Ignition system E.I. DIS coil on plug
VEHICLE DIMENSIONS
4
1
exd_engine_data
exd_dimensions_vehicle
Capacities and specifications
218

Dimensions mm(inches)
1 - Overall length 5197 mm (204.6 in)
2 - Overall width 2027 mm (79.8 in)
3 - Maximum height 1963 mm (77.3 in)
4 - Wheelbase 3023 mm (119.0 in)
5 - Front track 1661 mm (65.4 in)
IDENTIFYING YOUR VEHICLE
Vehicle identification tag
The vehicle identification tag is
located on the front panel of the
engine compartment. This tag
bears technical information on
your vehicle and identifies various
components.
55
2
3
exd_plate_identification
exd_vin_number
Capacities and specifications
219

Vehicle identification number
The vehicle identification number
(VIN) is attached to a metal tag
and is located on the front driver's
side of the instrument panel. The
VIN tag may be seen by looking
through the windshield from the
outside of the vehicle.
Engine number
The engine number is stamped on
the engine block.
UF0AXXGAGAJK07767
exd_engine_number
Capacities and specifications
220

REPORTING SAFETY DEFECTS
(U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash,
or could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in
addition to Ford Motor Company.
If NHTSA receives similar
complaints, it may open an
investigation, and if it finds that a
safety defect exists in a group of
vehicles, it may order a recall and
remedy campaign. However,
NHTSA cannot become involved in
individual problems between you,
your dealer or Ford Motor
Company.
To contact NHTSA, you may either
call the Auto Safety Hotline
toll-free at 1±800±424±9393
(202±366±0123 in the Washington
D.C. area) or write to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other
information about motor vehicle
safety from the Hotline.com_reporting_defects.01
Reporting safety defects
221

Air bag supplemental restraint
system ..........................................87
and child safety seats ..............88
description ................................87
disposal ......................................91
indicator light ...........................90
passenger air bag .....................89
Air cleaner filter .......................179
Air conditioning
auxiliary heater and air
conditioner ................................37
Air suspension ...........................111
Anti-theft system ........................67
Battery .......................................176
jumping a disabled battery ....151
Brakes ........................................107
adjustment ..............................107
anti-lock ...................................107
fluid, checking and adding ....162
Brake-shift interlock .................117
Break-in period .............................3
Bulbs, replacing .................198,205
headlamps ...............................199
rear lamps ...............................204
specifications ..........................205
Capacities for refilling fluids ...213,
215
Changing a tire .........................147
Cleaning your vehicle ...............206
engine compartment ..............208
fabric ........................................211
instrument panel ....................211
plastic parts ............................209
tail lamps .................................210
washing ....................................206
waxing .....................................207
wheels ......................................208
Climate control system .........27,28
air conditioning ...............32,33,34
defrosting ..................................65
heating .......................................33Compass, electronic
calibration .................................52
set zone adjustment .................52
Console, description ...................63
Controls .......................................64
Defrost
windshield .................................34
Emission control system ..........194
Engine .................................158,218
Engine block heater .................104
Engine coolant ..........................165
checking hoses .......................168
disposal ....................................167
refill capacities ........................167
Engine oil
changing oil and oil filter .......162
specifications ..........................159
Entry system
illumination ...............................54
Exhaust fumes ..........................106
Fail safe cooling ........................169
Floor mats ..............................65,66
Foglamps ..............................20,203
Four-Wheel Drive vehicles
control trac .............................119
special driving instructions ...120,
121
Fuel
calculating fuel economy .......193
improving fuel economy ........133
octane rating ...........................191
quality ......................................191
safety information relating to
automotive fuels .....................189
Fuel pump shut-off switch .......134
Gauges, Electronic ......................14
GVWR (Gross Vehicle Weight
Rating) .......................................123
Hazard flashers .........................134
Hitch ..........................................131
Identification Number, Vehicle
(VIN) ..........................................219
Index
222

Idle
relearning ................................178
Ignition .........................................68
Instrument panel ........................20
Jack ..............................................66
Jump-starting your vehicle 151,152
attaching cables ......................152
disconnecting cables ..............153
Lamps
interior lamps ...........................54
parking lamps .........................201
Lights, warning and indicator
anti-lock brakes (ABS) ............12
brake ..........................................10
charging system ..........................9
high beam .................................12
safety belt ............................10,86
Message center ...........................17
english/metric button ...............18
low fuel level ........................18,19
Motorcraft parts ........................213
Odometer .....................................17
Overdrive .....................................48
Overdrive lockout button ...........11
Overhead console
compass/temperature display ..50
Power features
door locks ..................................60
windows ...............................58,59
Power steering
fluid, checking and adding ....170
Rear console ................................63
Rear window
wiper ..........................................46
Relays ........................................135
Remote entry system
locking/unlocking doors ...........69
panic alarm ...............................69
replacement/additional
transmitters ...............................70
replacing the batteries .............70
Reporting safety defects ..........221Safety restraints
extension assembly ..................85
for children ...............................91
lap and shoulder belts ........82,83
proper use ............................80,81
Safety seats for children ............94
attaching with tether straps ....99
automatic locking mode
(retractor) ............................95,98
Seats ............................................72
bench (60-40 split) .............72,73
lumbar support .........................73
power seat recliner/lumbar ......74
rear flip fold seat ......................75
rear seat access ........................74
third row seat .................76,77,79
Servicing your vehicle ..............155
precautions when servicing ...155
Special notice
utility-type vehicles ....................2
Speed control ..............................41
accelerating ...............................42
resetting ....................................43
resuming a set speed ...............43
turning off .................................41
Speedometer ...............................14
Starting your vehicle ................100
preparing to start your
vehicle .....................................101
starting a warm engine ..........103
Steering, power .........................109
Steering wheel ............................40
Tachometer
mechanical cluster ...................15
Temperature control (see
Climate control) .....................28,29
Tires
changing ..................................144
inspection and maintenance ..182
tire grades ...............................182
treadwear ................................182
Traction-lok rear axle ...............111
Index
223

Trailer towing
calculating maximum trailer
weight ......................................127
Transfer case (see Differential
fluid) ...................................175,176
Transmission ......................114,172
Transmission control switch ......49
Trip odometer .............................17
Turn signal ..................................47
indicator lights ..........................12
Vehicle dimensions ...................218
Vehicle headlamp aiming
device (VHAD) .........................206
Ventilating your vehicle ...........105
Voltmeter (see Battery voltage
gauge) ..........................................16Warning chimes
headlamps on ............................14
key in ignition ...........................14
safety belt .................................13
Warning lights (see Lights) .8,144,
145
Windows
accessory delay .........................59
Windshield washer fluid and
wipers ........................................179
checking and adding fluid .....164
operation ..............................44,45
Wrecker towing .........................154
Index
224

FILLING STATION
INFORMATION
FuelUnleaded fuel only- Octane 87
Fuel tank capacity - 4x2
(standard suspension)98 L (26 gallon)
Fuel tank capacity - 4x2 (with
air suspension)114 L (30 gallon)
Fuel tank capacity - 4x4 114 L (30 gallon)
Engine oil WSS-M2C153-F*
Hood release Pull handle under the left side of the
instrument panel.
* Use only oil displaying the
American Petroleum Institute
certification mark Ð SAE 5W-30
preferred.
exd_filling_info
Filling station information
