1996 LINCOLN CONTINENTAL Customer Assistance Guide

Utility compartment armrest utility compartment beverage holderThe features on the full console
134Cupholder with full console
The cupholder provides a space for your cup.
Mini console cupholders
Six passenger vehicles are equipped with a mini
console that is located within the ashtray panel.
To open the panel, press on the front of it and
release. It will open automatically. To close,
push the panel back into place until it latches./!\WARNINGUse only soft cups in the cupholder.Hard objects can injure you in acollision.Storage Compartments
Your vehicle has two map pockets on the panels
of the front doors. The back of the front seats
also have map pockets.

Trunk
Opening the Trunk Manually
Locate the trunk lock in the rear reflector to the
right of the license plate to insert the key. Turn the
key to the right to open the trunk.The trunk lock cylinderUsing the Power Trunk Release
You can use your power trunk release feature in
three ways:
With your electric trunk release, you can open
the trunk from inside your vehicle by pressing
the TRUNK RELEASE button located on the
driver side door. The TRUNK RELEASE
button will only function when the vehicle is
traveling under three mph (five km/h).
To open your trunk with the keyless entry
system, press 5/6 on the keyless entry pad
within five seconds of entering the keyless code.
You can also open the trunk by pressing the
TRUNK button on the remote entry transmitter.
To prevent inadvertent activation, the trunk
button must be depressed twice within five (5)
seconds to open the trunk.
135

open trunk lidThe remote control for the trunk
The trunk lid cannot be opened if your vehicle is
moving faster than three mph (five km/h).
Cargo Storage System
(If equipped)
Your vehicle may be equipped with a cargo storage
system. It was designed to allow you to use all
available space in your trunk while permitting easy
loading and unloading.
136The cargo storage system
Release handle

To operate:
Grasp and squeeze the release handle to move the
cargo storage system rearward.
Place groceries, packages, etc. in the cargo storage
system.
Grasp and squeeze the release handle to move the
cargo storage system forward untfl it locks into
place.
NOTE:The cargo storage system has three
locking positions. Make sure the storage system is
securely locked in place.
Remote Control Fuel Filler Door Release
Button
Your vehicle has a remote control fuel filler door
which cannot be opened from outside of the vehicle.
To unlatch the fuel filler door, push the fuel door
button on the driver side door. Refer to Servicing
Your Vehicle in the Index for further information.Located on driver's door Manual override
located in trunk on RH side
Press button to open fuel filler
doorThe remote control fuel filler door release
button
137

Positive Retention Driver's Side Floor
Mat
Installing the floor mat
Position the floor mat in foot well. Place mat eyelet
over pointed end of retention post from the rear and
rotate forward to install. Adjust floor mat position
to allow proper operation of accelerator pedal and
brake pedal.
138Must be Positioned 1 inch (25.5 mm) Away From Brake Pedal And Accelerator Pedal All Around To Front of
Vehicle Seat track floor matThe positive retention floor mat

Removing the floor mat
Lift floor mat just forward of retention post and
rotate rearward to disengage from retention post.
The Electronic Compass
(If equipped)The electronic compassThe compass is mounted to the inside rear view
mirror. The display is in the upper right hand
comer of the mirror glass.
The display will show one of the following
directions: N, NE, E, SE, S, SW, W, and NW.
The brightness of the compass display is
controlled by the instrument panel dimming
switch.
Factors Affecting Compass Accuracy
Some things which can affect compass accuracy
are large buildings, bridges, power lines, and
powerful antennas. Keep radar detectors and
other magnetically mounted devices as far away
from the compass as possible. Sometimes after-
market and dealer-installed moon roofs can
affect the accuracy of the compass. Using
automatic car washes can cause minor
inaccuracies in the compass.
NOTE: Usually, when something affects the
compass readings, the compass will correct itself
after a few days of operating your vehicle in normal
conditions. If the compass is still giving inaccurate
139

readings after a few days, perform a compass
adjustment.
Compass-Calibration
I .For optimum calibration, switch off all non-
essential electrical accessories (rear window
defrost, heater/air conditioning, map lamps,
wipers, etc.) and ensure all doors are shut.
2.Drive to an open, level area away from large
metallic objects or structures.
3.Insert an appropriate diameter rod (paper clip)
into the left switch access hole underneath the
compass module and press gently for 1-2
seconds until "CAL" and a direction appear on
the display.
1404. Release the button and drive in a circle
until "CAL" disappears from the display
(approx. 2-3 circles).
Compass-Zone Adjustment
1.The zone setting is factory pre-set to Zone
8. Refer to the Zone Map in this manual to
verify the correct compass zone setting for
your geographical location.

2.Insert an appropriate diameter rod (paper
clip) into the right switch access hole
underneath the compass module and gently
press the right button for 1-2 seconds until
"ZONE" and the current zone setting
appear in the display.
3.Release the right button.
4.Pressing the right button repeatedly will
cycle through all possible zone settings.
Stop cycling when the correct zone setting
for your location appears.
5.Releasing the button for 2 seconds will exit
the zone entry mode.
Securitire (If equipped)
Securitires are designed to allow you to
continue driving your Continental a limited
number of miles when one of your vehicle's tires
is at low or even zero air pressure.
141
