1996 LINCOLN CONTINENTAL Customer Assistance Guide

Brake Fluid
Under normal circumstances, your vehicle should
not use up brake fluid rapidly. However, expect the
level of the brake fluid to slowly fall as you put
more mileage on your vehicle and the brake lining
wears.
You should check the brake fluid at every scheduled
engine oil change, but be sure to check it at least
once a year. You can do this by looking at the fluid
level in the plastic reservoir on the master cylinder.
(See The Engine Type in this chapter to locate the
master cylinder.) The fluid level should be at or near
the MAX mark./!\ WARNINGBrake fluid is toxic.If brake fluid contacts eyes, flush eyes with running
water for 15 minutes. Get medical attention ifirritation persists. If taken internally, drink water and
induce vomiting. Get medical attention immediately.
If the fluid is low, carefully clean and remove the cap
from the reservoir. Fill the reservoir to the MAX
line with Ford High Performance DOT 3 Brake Fluid
C6AZ-19542-AA, C6AZ-19542-BA, or equivalent
DOT 3 fluid meeting Ford specification ESA-
M6C25-A./!\ WARNINGIf you use a brake fluid that is not DOT 3, youwill cause permanent damage to your brakes.Do not fill the reservoir above the MAX line.
If you find that the fluid level is excessively low
below the seam or ridge on the outside of the plastic
reservoir - have the brake system inspected.
263

/!\ WARNINGDo not let the reservoir for the mastercylinder run dry. This may cause the brakesto fail.The brake fluid reservoir
264Power Steering Fluid
Check the level of the power steering fluid at least
twice a year (i.e., every Spring and Fall).
Checking and Adding Power Steering
Fluid
1. Start the engine and let it run until the power
steering fluid reaches normal operating
temperature. The power steering fluid will be at
the right temperature when the engine coolant
temperature gauge in the instrument cluster is
near the center of the NORMAL operating
temperature range.
2. While the engine idles, turn the steering wheel
back and forth several times. Make sure that the
cap assembly is installed at this time.

3.Turn the engine off and check the level on the
power steering reservoir.
4.The fluid level is viewed through the sight
window on the power steering reservoir. If the
power steering fluid is below the middle line,
add fluid in small amounts, continuously
checking the level. Do not overfill.The power steering fluid reservoir
265

Use only MERCONÒ ATF power steering fluid.
If the power steering fluid is low, do not drive your
vehicle for a long period of time before adding fluid.
This can damage the power steering pump.
Fuses
Fuses (conventional and high current) protect your
vehicle's electrical system from overloading. If
electrical parts in your vehicle are not working, the
system may have been overloaded and blown a fuse.
Before you replace or repair any electrical parts,
check the appropriate fuses (conventional and high
current).
266The following charts tell you which fuses protect
each electrical part of your vehicle. If a fuse blows,
all the parts of your vehicle that use that circuit will
not work.
Once you have determined which fuses to check,
follow the procedures under Checking and replacing
fuses in this chapter.

The instrument panel fuse panel location
Emergency
brake pedalSqueeze here to remove fuse panel
cover267

The instrument panel fuse panel
268

The Instrument Panel Fuses
Fuse
Location Fuse Amp
RatingDescription110An And-theft indicator light
n PWM dimming output for
microphone illumination,
ashtray illumination (R & L
rear door),heated seat
switches, heated backlight
switch, EATC control panel,
message center switches, cigar
lighter, console shift
illumination, navigation
display module, and
navigation switches210An Luxury radio
n Clock (non-navigational)
n Cellular phone310An Multi-function switch410An Run/Accessory sensor
(luxury radio)
n Cellular phone
n Run/Accessory sensor
(LCM)
n Window switches
backlight RF, LR, RR) *
n CompassFuse
LocationFuse Amp
RatingDescription4 (cont.)10A
· E/C mirror
· Stand alone clock
· Door lock switches backlight510A
· Virtual image cluster
· Light sensor (Autolamp)
· Traction Assist OFF switch
· Airbag diagnostic
· Luxury radio FCU
· Run/Start sensor (LCM)65A
· SCP network715A
· Right front turn lamp
· Right turn indicator
· HI beam switch
· Right and left front side
marker lamps
· Right and left front park
lamps
· Right and left front tail
lamps
· Right rear stop/turn lamps830A
· Fuel filler
· Trunk solenoid
· Navigation system power269

Fuse
Location Fuse Amp
RatingDescription910A
· Blower motor relay coil
· EATC control
· Airbag diagnostic1030A
· Windshield wiper motor
· Windshield wiper control
module (washer pump motor)1110A
· PCM power relay coil
· Ignition coil125A
· SCP network1315A
· Stand alone clock
illumination
· Right and left rear side
marker lamps
· License lamps
· Right and left tail lamps
(on decklid)
· Left rear stop/turn lamps
· Left turn indicator
· Left front turn lamp1415A
· Front cigar lighter270Fuse
LocationFuse Amp
RatingDescription1510A
· Navigation display
· Navigation module
· Heated seat control switches1630A
· power moonroof switch
· Moonroof motor17(Not used)185A
· SCP network1910A
· LH low beam2010A
· Multi-function switch (Flash
to pass and hazard signal to
LCM)
· LH & RH cornering lamps2110
· ABS control module22(Not used)23(Not used)245A
· SCP network25
· RH low beam2610A
· Instrument cluster power
· EATC power27(Not used)
