Page 169 of 320

If the player is in the tape mode but not in Play,
pressing the 'TAPE" button will activate play. If
the "TAPE" button is pressed with no tape
inserted, the display will flash "NO TAPE".
How to locate a desired track on the tape
There are six ways to quickly locate a desired
selection on the tape. You can use the fast
forward, rewind, Blank Skip, "SEEK", "SCAN"
or "SIDE 1-2" functions. Following are brief
descriptions of each: Fast forwarding the tape
To fast forward the tape, press the "FF'
button. The radio will play while the tape is in
fast forward. The light above the "FF" button
will blink while in the fast forward mode.
Press "FF" again or press the "TAPE" button
to stop fast forwarding. At the end of the
tape, the direction automatically reverses and
plays the other side of the tape.
166 Rewinding the tape
To rewind the tape, press the "REW' button.
The radio will automatically begin playing
while the tape is rewinding. The light above
the "REW" button will blink while in the
rewind mode. Press "REW" again or press
the 'TAPE" button to stop rewinding. Using the "SEEK" function with your cassette
tape player
While in the tape mode, push the right ()
side of the "SEEK' button to seek forward to
the next selection on the tape. Push the left
() side to restart a currently playing tape
selection. Using the 'Blank Skip" function with your
cassette tape player
Press the "Blank Skip" button to activate
the blank skip mode. After approximately
20 seconds of blank program, the tape will
seek forward to the next program.
Page 170 of 320

Using the "SCAN" function with your cassette
tape player
Pushing the "SCAN" button will begin the
forward scan mode on the tape currently
playing, stopping on each tape selection for
approximately eight seconds.
To stop the scan mode on the presently
sampled tape selection, press the "SCAN"
button or the "TAPE" button. How to change the side of the tape being
played
The alternate side of the tape can be selected
by pressing the "SIDE 1-2" button.
How to eject the tape
To stop the tape and eject the cassette, press the
"EJECT" button. The tape will eject only when
in the tape mode. The cassette cannot be ejected
when the radio is playing an “AM” or "FM"station. The system will revert to radio
mode when the cassette is ejected.
How to store the tape
Press the "AWFM" button to stop the
tape player and resume radio play.
Using the DolbyÒ B noise
reduction feature
NOTE: Noise reduction system
manufactured under license from Dolby
Labs Licensing Corporation. "Dolby" and
double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation.
Push the button to activate. When
activated, the light above the button
will be illuminated,
Tape error messages
Your cassette tape player is equipped to
diagnose certain problems you may
experience. Error codes are as follows:
167
Page 171 of 320

TD El - Radio tries to change sides of tape 3
times in a 10 second span. push ,EJECT" and try
another tape. if problem persists, refer problem to
qualified personnel for service.
TD E2 - Tape eject failure. Radio tries to eject
tape and it will not eject. push "EJECT" to elect
tape. if the tape Will not eject, refer problem to
qualified personnel for service.
TD E3 - Loading error. push 'EJECT" to elect
tape. Reload tape. If the same error code
appears in the display, try another tape.
Tips on Caring for the Cassette Player
and Tapes
In order to keep your cassette tape player
performing the Way it was meant to, read and
follow these simple precautions: Using a Ford Cassette Cleaning Cartridge to
clean the tape player head after 10-12 hours of
play will help maintain the best playback
sound and proper tape operation.
168 Only cassettes that are go minutes long or
less ger than go minutes should be used.
Tapes longer than 90 minutes are thinner
and subject to breakage or may jam the tape
player mechanism. Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions allow them to reach a moderate
temperature before playing. If a tape is. loose inside the cassette; tighten
it by putting, your finger or a pencil into
one of the holes and turning the hub until
the tape is tight. Loose labels on cassette tapes can become
lodged in the mechanism. Remove any
loose label material before inserting a
cassette. Do not leave a tape in the cassette tape
player when not in use. High heat in the
vehicle can cause the cassette to warp.
Page 172 of 320
Ford 6-CD Changer
Introduction
The Ford 6-CD Changer is mounted in your
console and holds 6 CDs, all controlled by using
buttons on your Luxury Audio System.
Be sure to read all of the information provided on
the following pages to get the most out of this
system.
Loading Instructions
1. Open Compact Disc Changer unit by suding
door to the right (Figure 1).Figure 1
2.Push the button to eject the disc"magazine" (holds 6 discs) (Figure 2).
169
Page 173 of 320
Disc magazine eject buttonFigure 2Figure 3
3. Load discs into the disc magazine slots
(numbered I through 6) one at a time with
labeled surfaces upward, starting with bottom
slot number I (Figure 3).
1704. Insert loaded disc magazine into
chamber unit with the arrow on top of the
disc magazine pointing toward the
changer (Figure 4). Make sure magazine
is fully inserted into changer.
Page 174 of 320

Figure 4
NOTE: To remove one or more compact disc(s)
from the disc magazine, push the corresponding
lever(s) to the back. Disc(s) will partially come
out for easy removal.
5.Close unit by sliding changer panel door to
the left.
The Compact Disc Changer unit is now ready to
play using the controls of your Luxury Audio
System.How to Operate the Ford 6-CD
Changer Using the Controls on the
Radio
If your vehicle is equipped with the Ford 6-CD
Changer System, you can operate it through the
controls of your Luxury Audio System.
Several of the controls on the radio operate in
the same manner in CD mode as they do in radio
or cassette mode: turning the power on, volume
control and adjusting the bass, treble, speaker
balance or fade.
How to begin CD Changer play
NOTE: Radio power must be on to operate the
Compact Disc Changer.
Push the "CD" button to begin CD play. The
CD Changer will automatically begin playing the
first track (selection) of the first disc loaded in
the unit. 0 The display will indicate "CD-#.#" for
disc number then display "TR-##" for track
number, then "DD-TT" for disc number and
track number.
171
Page 175 of 320

How to change the disc being played
When in the CD mode, you can change discs by
pressing the right (pop.) side of the "TUNE
DISCS" button (to select the next disc) or the
left () side of the "TUNE DISCS" button (to
select the next disc) or the left () side of the
“TUNE DISCS” button to select the previous
disc). Play will begin on the first track of the
selected disc.
When either side of the button is pressed and
held, the CD changer will continue fast-
forwarding or reversing through the discs in the
disc magazine. During these functions, the
display will indicate the disc number.
How to change the track being played
Press the right () side of the "SEEK" button to
seek forward to the next track of current disc.
After the last track has been completed, the CD
player automatically wraps back to the first track
of the current disc.
172Press the left () side of the SEEK
button to seek in reverse to the previous
track on the current disc. If a selection
has been playing for three seconds or
more and you press the left () side of
the SEEK button, the CD Changer will
replay that selection from the beginning.
Operating the CD Compression feature
The compression feature will bring soft
and loud passages closer together for a
more consistent listening level.
To turn the compression on, press the #5
"/COMP" button. (While in the CD
Changer mode, the Dolby button controls
the compression function.) When the
compression feature is activated, the
display will indicate "C". Press again to
deactivate.
Page 176 of 320

Operating the Shuffle feature
The shuffle feature on your CD player allows you
to listen to your disc selections in a different
order. When this feature is activated, your CD
player will randomly select and play tracks on the
disc.
Press the "SHUFFLE" button to turn on, press it
again to turn off. When on, the light above the
"SHUFFLE" button will illuminate.
Operating the "SC4N"function
Press the "SCAN" button to enter the scan mode.
The CD player will begin scanning the disc,
stopping on each listenable track for
approximately an eight second sampling. This
continues until you press the "SCAN" button a
second time.Operating the Shuffle and Scan features
simultaneously
Both the shuffle and scan features can be
activated simultaneously. In this mode, the
player will randomly pick a selection and play
the first eight seconds. This process is
continued until either the "SCAN" button or
"SHUFFLE" button is pressed a second time.
How to stop CD play
While in CD Changer mode, press the EJCT,
AM or FMI/FM2 button to stop CD play and
resume radio play. Also, loading a cassette into
the cassette deck will stop CD play and begin
cassette play.
Balance control allows you to adjust the sound
distribution between the right and left speakers.
Push the "AUDIO" button repeatedly until the
display reads "BAL." Push the right (+) side of
the "VOLUME" button to shift the sound to the
right speakers, and push the left (-) side to shift
the sound to the left speakers.
