1996 LINCOLN CONTINENTAL Customer Assistance Guide

Engine Oil Pressure Warning Light
This light indicates the engine's oil pressure, not
the oil level. However, if your engine's oil level
is low, it could affect the oil pressure. The
light will come on briefly when you turn your
key to the START and ON position. The light
should stay off when the engine is running with
normal oil pressure. If the light comes on while
the engine is running, you have lost oil pressure
and continued operation will cause severe
engine damage.
54If you lose engine oil pressure:
1. Pull off the road as soon as safely possible.
2. Shut off the engine immediately or severe engine
damage could result.
3. Check the engine's oil level, following the
instructions on checking and adding engine oil,
see the Engine Oil in the Index. If you do not
follow these instructions, you or others could be
injured. To assure an accurate reading, your car
should be on level ground.
4. If the level is low, add only as much oil as
necessary before you start the engine again. Do
not overfill. Do not operate the engine if the light
is on, regardless of the oil level. Contact your
nearest dealer for further service actions.
For more information about adding oil, see Adding
engine oil in the Servicing Your Vehicle chapter.

Traction ControlÒ Ò Active Light (If
equipped)
This light comes on when the Traction
ContronÒ system begins applying and releasing
the brakes and adjusting the engine
characteristics to limit a wheelspin condition.
It will be lit for a minimum of six seconds or
for the duration of the Traction ControlÒ
event.T/CACTIVECharging System Light
This light indicates that your battery is not being
charged and that you need to have the electrical
system begins applying and releasing the brakes
and system checked.55

This light comes on every time you turn the
ignition to the ON or START position (engine
offl. The light should go off when the engine
starts and the alternator begins to charge.
If the light stays on or comes on when the
engine is running, have the electrical system
checked as soon as possible.
Turn Signal Indicator Lights
When you push the turn signal lever up before
making a right turn, the right side arrow on the
instrument panel flashes.
When you push the turn signal lever down
before making a left turn, the left side arrow on
the instrument panel flashes.
Usually, the turn signals turn off automatically
after you turn your car. If the turn signal
continues to flash after you have made the turn,
push the lever back to the OFF position.
56If one or both of your turn indicators do not flash
or stay on continuously, have them serviced as
soon as possible. In the meantime, be sure to use
the accepted hand signals.
Service Engine Soon Warning Light
The Powertrain On-Board Diagnostic 11
(OBD 11) system consists of the hardware
and software necessary to monitor the
operation of the powertrain. The OBD 11
system is designed to check the function
of the vehicle's powertrain control system
during normal operation. If an emission
problem is detected, the Service Engine
Soon light (in the cluster) is turned on.

Modification or additions to the vehicle may
cause incorrect operation of the OBD 11
system. Additions such as burglar alarms,
cellular phones, and CB radios must be
carefully installed. Do not install these
devices by tapping into or running wires close
to powertrain control system wires or
components.SERVICEENGINESOONThe light comes on briefly when you turn the ignition
to the ON position, but should turn off when the
engine starts. If the light does not come on when you
turn the ignition to the ON position or if it comes on
and stays on when you are driving, have your vehicle
serviced as soon as conveniently possible.This indicates a possible problem with one of the
vehicle's emission control systems. You do not
need to have your vehicle towed in.
If the light turns on and off at one second intervals
while you are driving the vehicle, it means that the
engine is misfiring. If this condition persists,
damage could occur to the engine or catalytic
convertor. Have your vehicle serviced at the first
opportunity.
If the light turns on and off on rare occasions
while you are driving, it means that a malfunction
occurred and the condition corrected itself.
An example of a condition which corrects itself
occurs when an engine running out of fuel begins
to misfire. In this case, the Service Engine Soon
Light may turn on and will then set a diagnostic
trouble code indicating that the engine was
misfiring while the last of the fuel was being
consumed. After refueling, the Service Engine
Soon Light wfll turn off after the vehicle has
completed three consecutive warm up cycles
without a misfire
57

condition occurring. A warm up cycle consists
of engine start from a cold condition (engine at
ambient temperature) and running until the
engine reaches normal operating temperature.
On the fourth engine start up, the Service
Engine Soon light will turn off as soon as the
engine begins to crank. It is not necessary to
have the engine serviced.
Under certain conditions, the Service Engine
Soon Light may come on if the fuel cap is not
properly installed. If the Service Engine Soon
Light comes on and you suspect that the fuel
cap is not properly installed, pull off the road as
soon as it is safely possible and turn off the
engine. Remove and replace the cap, making
sure it is properly seated.
After completing the three consecutive warm
up cycles and on the fourth engine start up, the
Service Engine Soon Warning Light should
turn off. If the light does not go off after the
fourth engine re-start, have your vehicle
serviced by your dealer or a qualified
technician.
58High Beam LightThis light comes on when the headlamps are turned
to high beam or when you flash the lights.
Chime for Headlamps On
This chime sounds if the driver or any passenger
door is open when the parking lamps or headlamps
are on. The chime sounds until you close the door,
turn off the lamps or turn the ignition to the ON
position.

Air Bag Readiness Light
The air bag system uses a readiness light and
a tone to indicate the condition of the system.
The readiness light is in the instrument
cluster. When you turn the ignition key to the
ON position, this light will light up for six (6)
seconds and then turn off. This indicates that
the system is operating normally. NOTE:
Regularly scheduled maintenance of the air
bag system is not required.AIRBAGIf the light fails to Ruminate, continues to
flash, remains on, or you hear a beeping
sound, have the system serviced at your Ford
or Lincoln-Mercury dealer immediately.Anti-Theft Alarm Light
(If equipped)
This light flashes on and off when the ignition is
turned to the OFF position and any door is
opened. As soon as you lock the doors, the light
glows steadily. Within 30 seconds of closing all
the doors, the light goes out. This indicates that
the alarm system is armed.ANTI-THEFTSee Anti-Theft System in the Features chapter for
more information.
59

The Instrument Cluster
In addition to warning lights, the instrument
cluster has a message center/odometer, a
speedometer, tachometer, fuel and coolant
temperature gauges.
The Electronic Message Center (M/C)
The Electronic Message Center only works
when the ignition is in the ON position.
Each time the WC is powered the display goes
through a self test by displaying the PLEASE
FASTEN SEATBELT message. This self test
is used to stabilize the systems before reporting
the status to you.
60The message center tells you about the
condition of your vehicle by two methods: operator selectable features continuous warning reporting of
monitored systems
You can select different features for the M/C to
display by using the message center control
buttons located to the right of the instrument
cluster. You will hear a tone when you press one
of these buttons. However, if the M/C detects a
warning from any of the monitored systems, then
the M/C will display the appropriate warning
message.

Operator Selectable FeaturesCluster Control Buttons and Message Center
Control ButtonsThese features are controlled by the message
center control buttons located to the right of the
instrument cluster.
System Check
Pressing the SYSTEM CHECK button causes
the M/C to cycle through a status of each of the
systems being monitored. For each of the
monitored systems, the M/C will indicate either
an OK message or a warning message for three
seconds. The sequence of the system check
report is as follows: Washer Fluid Level Ride Control Oil Level Engine Coolant Level Voltage Level Engine Temperature
61
