1996 LINCOLN CONTINENTAL turn signal bulb

If the turn signal stays on after you turn, move
the lever back to the center (off) position. A
warning chime will sound after approximately
one-half mile (one kilometer) of driving if you do
not return the lever to off.
For lane changes, move the lever far enough to
signal but not to latch. The lever will return to
the off position when you release it.
NOTE: The flash rate of the turn signal will
speed up considerably if the Lighting Control
Module detects a left or right turn lamp bulb
(front or rear) is burned out.
High Beams
To turn on the high beams, turn the headlamp
control switch to the headlamp ON position (or
activate the autolamp feature) and push the turn
signal lever away from you until it latches. When
the high beams are ON, the high beam indicator
light on the instrument cluster comes on.
90To turn off the high beams, pull the lever toward
you until it latches. The high beam indicator
light turns off.
Flashing the Lights
To flash the headlamps, pull the lever toward
you for a moment and then release it. The
headlamps will flash whether the headlamp knob
is in the on or off position.
Windshield Wipers and Washer
To turn on the windshield wipers, the ignition
key must be turned to the ON or ACC position.
Rotate the knob towards "S" to activate the
wipers. The first seven detents are interval wipe
positions, the eighth detent is the LO position
and the ninth detent is the HI position.
To turn the wipers off, turn the knob to the OFF
position.

/! WARNINGAlways replace a fuse with one that has thespecified amperage rating. Using a fuse witha higher amperage rating can cause severewire damage and could start a fire.5.Align the edge of the cover with the edge of
the fuse panel and push the cover up until it
latches.
Even after you replace a fuse, it will continue to
blow if you do not find what caused the overload.
If the fuse continues to blow, have your electrical
system checked.
Lights and Bulb Replacement
It is a good idea to check the operation of the
following lights ftequently: headlamps high-mount brakelamp tail lamps brakelamps hazard flasher turn signals side markers license plate lamp
The alignment of your headlamps should be
checked if: oncoming motorists frequently signal you to
turn off your vehicle's high beams when you do
not have the high beams on the headlamps do not seem to give you enough
light to see clearly at night
277

Bulb specifications
FunctionTrade numberExterior illuminationBackup lamp3156Cornering lamp3156Headlamp9007High-mount brakelamp912License plate lamp168Luggage compartment lamp912Side marker - front lamp916NA*Side marker - rear lamp194Turn signal and park lamp - front3457NA*Turn signal, stoplamp and tail lamp
- rear3157Redundant turn - rear3157Decklid reflector168Instrument panel lightsElectronic automatic temperature
control***Air bag readiness light37Anti-lock warning lamp37And-theft warning lamp37Ash receptacle1445Ash ttay - rear doors37Clock***FunctionTradenumberInstrument panel lights (continued)Cluster illumination***Cluster control button37Compact disc player**Glove compartment194Headlamp switch nomenclature37Message center control buttons***“PRN@D I" bulb (floor console)194Rear window defrost switchnomenclature37Radio**Warning lights (cluster)37Interior courtesy lampsCigar lighter (door mounted)1893Door mounted lamp (front and rear)214-2Illuminated visor mirror (passenger)74Overhead console-reading lamps (without
moon roof)211-2Passenger assist handle (rear seat)211-2Under instrument panel906*NA means Natural Amber.
**Refer bulb replacement to a Ford -authorized radio service
center.
***Refer bulb replacement to a Ford or Lincoln-Mercury
dealer.
283

Engine compartment/ Servicing Windshield wipers Headlamp bulbs and Daytime Running Lights Hood latch Turn signal bulbs Parking lamp bulbs
Cornering lamp bulbs Moon roof Keyless entry Side view mirrors Tires299

Trunk Taillamp bulbs Backup lamp bulbs Brakelamp bulbs Turn signal bulbs High-mount brakelamp bulbs Fuel door
Doors300

Keys.............................................................charging system...............................55
key in ignition chime............................42engine oil pressure...........................54
positions of the ignition........................41high beam........................................58
removing from the ignition...................42oil pressure......................................54
stuck in lock position...........................42safety belt........................................52
L.................................service engine soon..........................56
Lamps..........................................................turn signal indicator.........................56
autolamp delay system.........................83Load limits
checking............................................277GAWR............................................192
................................................................GVVVR..........................................192
daytime running light system................81trailer towing...................................194
flashing the lamps................................90Lubricant specifications........................289
hazard flashers.....................................92Luggage compartment..........................135
headlamps............................................82Lug nuts, anti-theft...............................209
high beams...........................................90
replacing bulbs...................................277..........................M
trailer.................................................197Maintenance (see Servicing).................231
Lane change indicator (see Turn signal)....89Map pockets.........................................134
Lights, warning and indicator.......................Methanol in fuel...................................241
air bag.................................................59Mileage, calculating fuel economy........243
anti-theft..............................................59Mirrors
brake...................................................52automatic dimming rearview mirror..125
315
