1996 HONDA ODYSSEY Owners Manual

Audio System

CD Error Indications

If you see an error indication in the display while in CD mode, find the
cause in the chart to the right. If you cannot clear the error indication,
take the car to your Honda dealer.
Comfort and Convenience FeaturesProCarManuals.comMain Menu s t Table of Contents

Audio System

Theft Protection
On U.S. EX model

Your car's audio system will disable itself if it is disconnected fromelectrical power for any reason. To
make it work again, the user must enter a specific five-digit code in the
Preset buttons. Because there are
hundreds of number combinations possible from five digits, making the system work without knowing the
exact code is nearly impossible.
You should have received a card that lists your audio system's code number and serial number. It is best
to store this card in a safe place at
home, or to keep it in your wallet or
purse. In addition, you should write the audio system's serial number in
this Owner's Manual. If you should
happen to lose the card, you must
obtain the code number from yourHonda dealer. To do this, you will
need the system's serial number. If your car's battery is disconnected
or goes dead, the audio system will
disable itself. If this happens, you
will see "Code" in the frequency display the next time you turn on the
system. Use the Preset buttons toenter the five-digit code. If it is
entered correctly, the radio will start

playing.

If you make a mistake entering thecode, do not start over or try to
correct your mistake. Complete the
five-digit sequence, then enter the correct code. You have three tries toenter the correct code. If you are
unsuccessful in three attempts, you
must then leave the system on for one hour before trying again. You will have to store your favorite
stations in the Preset buttons after
the system begins working. Your original settings were lost when
power was disconnected.
Comfort and Convenience FeaturesProCarManuals.comMain Menu s t Table of Contents

Before Driving

Before you begin driving your Honda,
you should know what gasoline to use, and how to check the levels ofimportant fluids. You also need to
know how to properly stow luggage
or packages. This section will help
you. If you plan to add any accesso- ries to your car, please read theinformation in this section first. Break-in Period.............................. 108
Gasoline.......................................... 108
Oxygenated Fuels...................... 108
Driving in Foreign Countries... 109
Service Station Procedures .......... 110 Filling the Fuel Tank................. 110Opening the Hood..................... 111
Fuel Economy................................ 114
Vehicle Condition...................... 114Driving Habits............................ 114
Accessories..................................... 115
Loading Cargo................................ 116

Before DrivingProCarManuals.comMain Menu s t

Break-in Period, Gasoline

Break-in Period
Help assure your car's future
reliability and performance by payingextra attention to how you drive
during the first 1,000 km (600 miles).
During this period:
Avoid full-throttle starts and rapid
acceleration.

If you need to add oil, use the
engine oil recommended in this
owner's manual.
Avoid hard braking. New brakes need to be broken-in by moderate
use for the first 300 km (200

miles).

You should follow these same re- commendations with an overhauled
or exchanged engine, or when the
brakes are relined.
Gasoline

Your Honda operates most effec- tively on unleaded gasoline with a
pump octane number of 86 or higher.
Use of a lower octane gasoline can
cause a persistent, heavy metallicrapping noise in the engine that can
lead to mechanical damage.
We recommend gasolines containing detergent additives that help prevent
fuel system and engine deposits.
Using gasoline containing lead will
damage your car's emission controls.
This contributes to air pollution and can void certain parts of your
warranty. Oxygenated Fuels

Some conventional gasolines are

being blended with alcohol or an
ether compound. These gasolines

are collectively referred to as
oxygenated fuels. To meet clean air standards, some areas of the United

States and Canada use oxygenated

fuels to help reduce emissions.
If you use an oxygenated fuel, besure it is unleaded and meets the

minimum octane rating requiremen

Before using an oxygenated fuel,

to confirm the fuel's contents. Some states/provinces require this
information to be posted on the

pump.

Before DrivingProCarManuals.comMain Menu s t Table of Contents

Gasoline

The following are the EPA-approved percentages of oxygenates:
ETHANOL (ethyl or grain alcohol)
You may use gasoline containing up to 10% ethanol by volume. Gasoline containing ethanol may be marketed
under the name "Gasohol."
MTBE (Methyl Tertiary Butyl

Ether)

You may use gasoline containing up to 15% MTBE by volume. METHANOL (methyl or wood

alcohol)

You may use gasoline containing up to 5% methanol by volume as long asit also contains cosolvents andcorrosion inhibitors to protect the
fuel system. Gasoline containing more than 5% methanol by volume
may cause starting and/or perform-ance problems. It may also damage
metal, rubber and plastic parts of
your fuel system.
If you notice any undesirableoperating symptoms, try another
service station or switch to another
brand of gasoline.
Fuel system damage or performance
problems resulting from the use of an oxygenated fuel containing morethan the percentages of oxygenates
given above are not covered under
warranty.
Driving in Foreign Countries

If you are planning to take your
Honda outside the U.S. or Canada,
contact the tourist bureaus in the areas you will be traveling in to find
out about the availability of unleaded
gasoline with the proper octane
rating.

If unleaded gasoline is not available,
be aware that using leaded gasoline in your Honda will affect perfor-
mance and fuel mileage, and damage its emissions controls. It will nolonger comply with U.S. andCanadian emissions regulations, and
will be illegal to operate in North
America. To bring your car back into compliance will require the replace-
ment of several components, such as
the oxygen sensor and the three way catalytic converter. These replace-
ments are not covered under
warranty.
Before DrivingProCarManuals.comMain Menu s t Table of Contents

Service Station Procedures

Filling the Fuel Tank
1. The fuel fill is on the driver's side of the car. Park with that side
closest to the service station

pumps.

2. Open the fuel fill door by pulling on the handle to the left of the

driver's seat.
3. Remove the fuel fill cap slowly.
You may hear a hissing sound as
pressure inside the tank escapes.

Place the fuel fill cap on the inside

of the door as shown.
4. Stop filling the tank after the fuel pump automatically clicks off. Do
not try to "top off the tank, leave
some room for the fuel to expand
with temperature changes.
5. Screw the fuel till cap back on, tighten it until it clicks more than

twice.

6. Push the fuel fill door until it
latches.
Befor
e
Drivin
g
Gasoline i
s highly flammable

and explosive. You can be
burned or seriously injured

when handling fuel.

Stop the engine and keep

heat, sparks, and flame away.
Handle fuel only outdoors.

Wipe up spills immediately.

Pull

FUEL FILL CAPProCarManuals.comMain Menu s t Table of Contents

Service Station Procedures

Opening the Hood
1. Shift to Park or Neutral and set the parking brake. Pull the hood
release handle, located under the
left lower corner of the dashboard.
The hood will pop up slightly. 2. Standing in front of the car, put
your fingers under the front edge
of the hood to the right of center.
Slide your hand to the left until
you feel the hood latch handle.
Push this handle up until it
releases the hood. Lift the hood. 3. Pull the support rod out of its clip
and insert the end into the hole on
the left side of the hood.
To close the hood, lift it up slightly to remove the support rod from the
hole. Put the support rod back into
its holding clip. Lower the hood toabout a foot above the fender, then
let it drop.
Before Driving
CONTINUED

HOOD RELEASE HANDLE

LATCH

SUPPORT RODProCarManuals.comMain Menu s t Table of Contents

Service Station Procedures

Oil Check

Check the engine oil level every time
you fill the car with fuel. Wait at least two minutes after turning the engineoff before you check the oil.
1. Remove the dipstick (orange handle). 2. Wipe the dipstick with a clean
cloth or paper towel. 3. Insert it all the way back in its tube.

Before Driving
DIPSTICKProCarManuals.comMain Menu s t Table of Contents
