1996 HONDA ODYSSEY Owners Manual

Child Safety

If you are using a toddler seat in the

front passenger's seat, move the
passenger's seat as far back as
possible before installing the child
seat. If the passenger's bag inflates,

it could seriously hurt a toddler who
is not in the proper position or

properly restrained.
Restraining a Child Who Weighs
Over 18 kg (40 Ibs)

We recommend that, whenever
possible, a child who has outgrown a

toddler seat ride in the second or
third seat and use a lap/shoulder

belt. Put the seat belt on your child and
check its fit. The shoulder belt
should fit over the collarbone and
across the chest. The lap belt should sit low on your child's hips, not
across the stomach.
If the shoulder belt crosses the neck,
while sitting in the second or third
bench seat, have your child move
toward the center of the seat until the belt fits properly. If the belt still
crosses the child's neck, you should
use a booster seat.
Several styles of booster seats areavailable. We recommend a design
that allows the child to use the car's
lap/shoulder belt.
Whichever style you select, follow the booster seat manufacturer's
instructions.

Driver and Passenger SafetyProCarManuals.comMain Menu s t Table of Contents

Child Safety

Securing a Child Seat with a Lap/
Shoulder Belt
The lap/shoulder belt retractors in the passenger seating positions havea built-in locking mechanism
intended to secure a child seat. If
you are placing a child seat in one of the outside seating positions, do the

following:
1. Place the child restraint in the
desired seating position. Route the
lap/shoulder belt through the seat
according to the seat manufac-
turer's instructions.
2. Insert the latch plate into the buckle. Make sure it is fully

latched.

3. Slowly pull the shoulder portion of the belt out of the retractor until it

stops.

4. Allow the belt to slowly feed back into the retractor. You should hear
a clicking noise that indicates the
locking mechanism has engaged.
5. After the belt has retracted fully, pull up on the shoulder portion to
remove any slack. 6. Push and pull on the child seat to
verify that it is held firmly in place.
If not, unlatch the seat belt, allow
it to retract fully, and repeat these

steps.

To unlatch the seat belt, push the red PRESS button on the buckle.Guide the belt across to the door
pillar. If the belt doesn't retract easily, pull it out and check for twists

or kinks.

Driver and Passenger SafetyProCarManuals.comMain Menu s t Table of Contents

Child Safety

Using Child Restraints with
Tethers

U.S. Models

35 mm (1.4 in)

Your Honda has two attachment points on the tailgate sill that allow
for a tether-style child seat to beinstalled in the third row seat. Use
the dimensions in the above illustra-
tion to locate the attachment point
you want to use. Cut a 22 mm (7/8 inch) diameter hole. Install the tether hardware that came
with the child seat.
Tighten to:
22 N.m (2.2 kgf.m , 16 lbf.ft)

If you are not sure how to install the
bracket, have it installed by your Honda dealer.
If you need an anchor plate and mounting hardware, you can obtain
them by writing to:
American Honda Motor Co., Inc. Consumer Affairs1919 Torrance Blvd.
Torrance, CA 90501-2746
Canadian Models

Your Honda has attachment points for a tether-style child seat to beinstalled on the second or third seat
as shown.

Driver and Passenger Safety
265 mm

(10.5
in)ProCarManuals.comMain Menu s t Table of Contents

Child Safety

Second Seat Installation:

There are three attachment points available for the seven-passenger
model, and two attachment points
available for the six-passenger model.
To install a child seat in the second seat, fold the third seat into the floor
recess (see page 60 ). You will find a U-shaped slit in the carpeting at each
attachment point. Select the attach-
ment point you want to use, and pull
up the carpeting at the slit.
Third Seat Installation:

There are two attachment points on the tailgate sill. Select the attach-
ment point you want use, and
remove the plug with a small flat-
tipped screwdriver or a fingernail file.
Install the tether hardware that came
with the child seat.
Tighten to:
22 N.m (2.2 kgf.m , 16 lbf.ft)

If you are not sure how to install the
bracket, have it installed by your Honda dealer.

Canadian Cars

The anchor plate and mounting hardware for a top tether aresupplied with the car. When install-
ing, make sure the toothed washer is
on the bottom of the bolt.
TOOTHED WASHER

The supplied anchor plate is designed only for mounting a child
restraint. Do not use it for any other
purpose.
Storing a Child Seat
When you are not using an infant seat or other child restraint, either
remove it or make sure it is properly secured so it cannot be thrown
around the car during a crash.
Driver and Passenger SafetyProCarManuals.comMain Menu s t Table of Contents

Alcohol and Drugs

Driving a car requires your full at-
tention and alertness. Traffic condi-
tions change rapidly. You must beable to react just as rapidly. Alcoholor drugs directly affect your alert-
ness and ability to react. Even pre-scription and non-prescription medi-
cines can have this effect.
There are laws that deal with drunken driving. These laws define
how much alcohol it takes in your system to be legally "drunk." How-ever, your judgment and reaction
time get worse with every drink— even the first one. The safest thing you can do is never
drink and drive. This can be done if
you plan ahead. If you know you are going to be drinking, make plans toride with a friend who will not be drinking.
What if you find that you've been drinking and cannot get a ride from a
friend? Find alternative transpor- tation. Call a taxi. Take a bus. Many communities have transportation
services devoted to shuttling people
who have been drinking. If you have no choice but to drive,
stop drinking and give yourself lots
of time to sober up. Time is the only
thing that can make you sober.
Things like coffee or a cold shower don't speed up the process.
If you see friends trying to get
behind the wheel after drinking, stop
them. Drive them yourself or arrange other transportation. If you
think you are interfering, remember
that your interference will keep them
from sharing the road with you.

Driver and Passenger SafetyProCarManuals.comMain Menu s t Table of Contents

Carbon Monoxide Hazard

Your car's exhaust contains carbon monoxide gas. You should have no
problem with carbon monoxide
entering the car in normal driving ifyou maintain your car properly.Have the exhaust system inspected
for leaks whenever:
The car is raised for an oil change.
You notice a change in the soundof the exhaust. The car was in an accident that
may have damaged the underside. High levels of carbon monoxide can
collect rapidly in enclosed areas, such as a garage. Do not run the
engine with the garage door closed.Even with the door open, run the
engine only long enough to move the
car out of the garage.
With the tailgate open, air flow can pull exhaust gas into your car'sinterior and create a hazardous
condition. If you must drive with the
tailgate open, open all the windows and set the heating and cooling
system as follows. If you must sit in your parked car,
even in an unconfined area, with the engine running, adjust the heating
and cooling system as follows:

1. Push the
button. 2. Select the mode.
3. Turn the fan on high speed.
4. Set the temperature control to a
comfortable setting.

Driver and Passenger Safety

Carbon monoxide gas is toxic.
Breathing it can cause
unconsciousness and can even

kill you.

Avoid any enclosed areas or activities that expose you tocarbon monoxide.ProCarManuals.comMain Menu s t Table of Contents

Safety Labels

These labels are in the locations shown. They warn you of potential
hazards that could cause serious injury. Read these labels carefully
and don't remove them.
If a label comes off or becomes hard
to read, contact your Honda dealer
for a replacement.
Driver and Passenger Safety
BATTERY RADIATOR CAPProCarManuals.comMain Menu s t Table of Contents

Instruments and Controls

This section gives information about the controls and displays thatcontribute to the daily operation of
your Honda. All the essential controls are within easy reach.
Control Locations............................ 32
Indicator Lights................................ 33
Gauges.............................................. 37
Speedometer................................ 37

Trip Meter.................................... 37
Odometer......................................
37

Temperature Gauge................... .
38

Fuel Gauge.................................. 38

Maintenanc
e Required

Indicator...................................

38

Controls Nea r
the Steering

Wheel........................................ 39

Headlights.................................... 40
Daytime Running Lights............. 40
Instrument Panel Brightness..... 41
Turn Signals................................. 41
Windshield Wipers...................... 42
Windshield Washers................... 42 Rear Window Wiper and Washer...................................... 43

Hazard Warning........................... 43

Rear Window Defogger.............. 43
Steering Wheel Adjustment....... 44
Steering Wheel Controls................ 46 Cruise Control.............................. 46
Keys and Locks................................ 49
Keys............................................... 49
Ignition Switch............................. 49
Power Door Locks....................... 50
Remote Transmitter.................... 51Childproof Door Locks............... 52
Tailgate......................................... 52
Glove Box..................................... 53

Seats.................................................. 54
Passenger Seating....................... 54

Seat Adjustments......................... 54
Driver's Seat Power Height Adjustment............................... 55
Head Restraints........................... 56 Third Seat Access........................ 56
Removing the Second Seats in the Six-Passenger Model.... 57
Folding the Second Seats in the Seven-Passenger
Model....................................

58

Reclining th e
Second Seat.......... 59

Folding the Third Seat
in All Models............................ 60

Power Windows............................... 62

Sunroof.............................................. 63

Mirrors.............................................. 64
Adjusting the Power Mirrors..... 64

Parking Brake..................................

65

Digital Clock.................................... .
66
Beverage Holder.............................. 66
Dashboard Compartment............... 68 Center Pocket.................................. 68
Vanity Mirror................................... 68 Cigarette Lighter............................. 69
Ashtrays............................................ 69 Interior Lights.................................. 70

Ceiling Lights............................... 70

Spotlights...................................... 70
Tailgate Light............................... 71 Courtesy Lights........................... 71

Instruments and ControlsProCarManuals.comMain Menu s t
