1996 HONDA ODYSSEY Owners Manual

Sunroof, Mirrors

If you try to open the sunroof in below-
freezing temperatures, or when it is covered with snow or ice, you can
damage the sunroof panel or motor. Mirrors
Keep the inside and outside mirrors
clean and adjusted for best visibility.
Be sure to adjust the mirrors before
you start driving.
The inside mirror has day and nightpositions. The night position reduces
glare from headlights behind you.Flip the tab on the bottom edge of
the mirror to select the day or night
position.
Adjusting the Power Mirrors
Adjust the outside mirrors with theadjustment switch on the driver's
door armrest:
1. Turn the ignition switch ON (II).
2. Move the selector switch to L (driver's side) or R (passenger's

side).

Instruments and Controls

Closing the sunroof on
someone's hands or fingers can

cause serious injury.

Make sure passengers are
clear of the sunroof before

closing it.

TAB
NOTICE
SELECTOR SWITCHProCarManuals.coms t Main Menu Table of Contents

Mirrors, Parking Brake
ADJUSTMENT SWITCH

3. Push the appropriate edge of the adjustment switch to move the
mirror right, left, up or down.
4. When you finish, move the selector switch to the center (off)
position. This turns off the
adjustment switch so you can't
move a mirror out of position by
accidentally bumping the switch. Parking Brake
To apply the parking brake, pull the lever up fully. To release it, pull upslightly, push the button, and lower
the lever. The parking brake light on
the instrument panel should go out
when the parking brake is fully released (see page 36 ). If you try todrive the car without releasing the
parking brake, the ABS cannot work properly.
Driving the car with the parking brake
applied can damage the rear brakes
and axles.

Instruments and Controls
NOTICE
PARKING BRAKE LEVERProCarManuals.coms t Main Menu Table of Contents

Digital Clock, Beverage Holder

Digital Clock

The digital clock displays the time with the ignition switch ON (II).
To set the clock:
1. Turn the ignition switch ON (II) to display the time. 2. Press and hold the HOUR button
until the hour advances to the
desired time.
3. Press and hold the MIN. button until the numbers advance to the
desired time.
You can use the RESET button to quickly set the time to the nearest
hour. If the displayed time is before
the half hour, pressing the RESET
button sets the clock back to the previous hour. If the displayed time
is after the half hour, pressing the
RESET button sets the clock for-
ward to the beginning of the next
hour. For example: 1:06 would RESET to 1:00.
1:52 would RESET to 2:00.
Beverage Holder

To use the front beverage holder,
pull on the front. Push the holder all
the way in to close it.
Instruments and Controls

HOUR

MIN
RESETProCarManuals.coms t Main Menu Table of Contents

Beverage Holder

The beverage holder for the second seat passengers is located in the
armrest on each rear door.
The third seat also has a beverage holder in each side panel. Use the beverage holder only when
the car is parked. If you place cups in
the holder while driving, the liquid may spill when you go over bumps oraround corners.
Liquid can also spill from the holders
by the second seat when you close
the rear doors. A spilled liquid that is
very hot can scald you or your
passengers.
Spilled liquids can also damage the
upholstery, carpeting, and electrical
components in the interior.

Instruments and ControlsProCarManuals.coms t Main Menu Table of Contents

Dashboard Compartment, Center Pocket, Vanity Mirror

Dashboard Compartment

Open the dashboard compartment
by squeezing the handle. Close it
with a firm push. Center Pocket
Open the center pocket by pulling
the handle. Close it with a firm push.
The light in the pocket comes on when the instrument panel lights are
on.
Vanity Mirror

To use the vanity mirror, pull downeither sun visor and swing down the

cover.

The passenger's vanity mirror is lighted. The light beside the mirrorcomes on only when the light switch
is turned on.

Instruments and ControlsProCarManuals.coms t Main Menu Table of Contents

Cigarette Lighter, Ashtrays
Cigarette Lighter
The ignition switch must be in ACCESSORY (I) or ON (II) for the cigarette lighter to work. To heat up
the lighter, push it in. It will pop out
when it is ready for use. Do not hold
the lighter in while it is heating up,
you could cause it to overheat. Ashtrays

ASHTRAY

Open the front ashtray by pulling on
the bottom edge. Push it in to close it.
To remove the ashtray for emptying, push down on the metal plate inside,
then pull the ashtray out completely. ASHTRAY
The rear ashtray is in the armrest on the left rear door. To use the rearashtray, swing the lid open.
To remove the rear ashtray, open the lid and pull it straight up.

CONTINUED

Instruments and Controls

CIGARETTE LIGHTERProCarManuals.coms t Main Menu Table of Contents

Ashtrays, Interior Lights

Use the ashtray only for cigarettes,
cigars and other smoking materials. To
prevent a possible fire and damage to your car, don't put paper or other things that can burn in the ashtray.
Ceiling Lights
Your Honda has two ceiling lights. Each ceiling light has a three-
position switch. In the OFF position,
the lights do not come on. In the center position they come on when
you open any door. In the ON
position, they stay on continuously. Spotlights
On some models
Turn on the spotlight by pushing the button next to each light. Push the
button again to turn it off.

Instruments and Controls

NOTICE

DOOR ACTIVATEDProCarManuals.comMain Menu s t Table of Contents

Interior Lights

Tailgate Light
The tailgate light has a two positionswitch. In the OFF (down) position,
the light does not come on. In the ON (up) position, the light comes on
when you open the tailgate. Courtesy Lights
Each door has a courtesy light. This
light comes on when you open the door.
Your car also has a courtesy light in the ignition switch. This light comeson when you open the driver's door.
It remains on for several seconds
after the door is closed.

Instruments and ControlsProCarManuals.comMain Menu s t Table of Contents
