1996 HONDA ODYSSEY Owners Manual

Cooling System, Windshield Washers

10.Turn off the engine. Check the
level in the radiator, add coolant if

needed. Install the radiator cap,

tighten it fully.

11.Fill the reserve tank to the MAX
mark. Install the reserve tank cap.
Windshield Washers

Check the level in the windshield
washer reservoir at least monthly during normal usage. In bad weather,
when you use the washers often, check the level every time you stop

for fuel.

The windshield washer reservoir is located behind the left headlight.Check the reservoir's fluid level by
removing the cap and looking at the
level gauge attached to the cap.
Fill the reservoir with a good-quality
windshield washer fluid. This increases the cleaning capability andprevents freezing in cold weather.
Do not use engine antifreeze or a vinegar/water solution in the wind-
shield washer reservoir.
LEVEL GAUGE

Antifreeze can damage your car's pain while a vinegar/water solution can
damage the windshield washer pump.
Use only commercially-available

windshield washer fluid.

Maintenance
RESERVE TANK

NOTICEProCarManuals.comMain Menu s t Table of Contents

Automatic Transmission Fluid
Check the fluid level with the engine
at normal operating temperature.
1. Park the car on level ground. Shut off the engine.
2. Remove the dipstick (yellow loop) from the transmission and wipe it
with a clean cloth. UPPER MARK

3. Insert the dipstick all the way into
the transmission.

4. Remove the dipstick and check
the fluid level. It should be

between the upper and lower
marks. 5. If the level is below the lower
mark, add fluid into the tube to
bring it to the upper mark. Use
Honda Premium Formula Auto-
matic Transmission Fluid or an equivalent DEXRON ®
II Auto-
matic Transmission Fluid (ATF)
only.
6. Insert the dipstick all the way back in the transmission.
The transmission should be drained and refilled with new fluid according
to the time and distance recommen- dations in the maintenance schedule.

Maintenance

DIPSTICK

LOWER MARKProCarManuals.comMain Menu s t Table of Contents

Brake Fluid

Check the fluid level in the reser-
voirs monthly. There are one or two reservoirs, depending on model.
They are: Brake fluid reservoir (all models)
ABS reservoir (cars with ABS)
The brake fluid in the brake system should be replaced every 36 months
or 72,000 km (45,000 miles), which-
ever comes first. Brake System
MIN
The fluid should be between the MIN and MAX marks on the side of
the reservoir. If the level is at or below the MIN mark, it is an
indication that your brake system needs attention. Have the brakesystem inspected for leaks or worn
brake pads. If you add brake fluid to bring it up
to the MAX mark, use Genuine Honda Brake Fluid or an equivalent
from a sealed container that is marked DOT3 or DOT4 only. Brake
fluid marked DOT5 is not compatible
with your car's braking system.

Maintenance
MAXProCarManuals.comMain Menu s t Table of Contents

Brake Fluid, Power Steering
Anti-lock Brake System
The fluid should be between the MIN and MAX marks on the side of
the reservoir. If it is at or below the
MIN mark, it indicates a possible
problem in the ABS. Have the dealer inspect the system as soon as

possible.
Power Steering
LOWER LEVEL
You should check the fluid level in the power steering reservoirmonthly. Check the level when the
engine is cold. Look at the side of
the reservoir. The fluid should be
between the UPPER LEVEL and LOWER LEVEL. If it is below the
LOWER LEVEL, add power steering
fluid to the UPPER LEVEL.
Using automatic transmission fluid or
another brand of power steering fluid
will damage the system. Use only GENUINE HONDA Power Steering

Fluid-V.

A low power steering fluid level can indicate a leak in the system. Check
the fluid level frequently and have
the system inspected as soon aspossible.

Turning the steering wheel to full left
or right lock and holding it there can damage the power steering pump.

Maintenance

MAX

MIN
UPPER LEVEL

NOTICE
NOTICEProCarManuals.comMain Menu s t Table of Contents

Air Cleaner
The air cleaner element should becleaned or replaced according to the
time and distance recommendationsin the maintenance schedule. Cleaning (Severe Conditions)
Clean the air cleaner element by
blowing compressed air through it in the opposite direction to normal air
flow. If you do not have access to compressed air (such as a servicestation), ask your Honda dealer to do
this service.
Follow the replacement procedure
for removal and reinstallation.
The air cleaner element is inside thebox on the passenger's side of theengine compartment.
To replace it:
1. Remove the two pins holding the air intake cover by pulling the
head on each pin. Remove the air
intake cover.
2. Remove the air duct from the air cleaner housing cover.

MaintenanceProCarManuals.comMain Menu s t Table of Contents

Air Cleaner

MAINTENANCE

HOLE CAP
BOLTS

3. Loosen the four bolts and remove the air cleaner housing cover.Remove the maintenance hole cap so you can reach the right front
bolt through the hole.
4. Remove the old air cleaner element.
Clean the inside of the air cleaner
housing with a damp rag.
AIR CLEANER ELEMENT

5. Place the new air cleaner element in the air cleaner housing.
6. Reinstall the air cleaner housing cover, tighten the four bolts.
7. Reinstall the air intake cover. Reinstall the two pins and securethem by pushing on the headsuntil they lock. 8. Reinstall the air duct on the air
cleaner housing cover.Reinstall the maintenance hole cap.

MaintenanceProCarManuals.comMain Menu s t Table of Contents

Spark Plugs

The spark plugs in your car need to be replaced every 2 years or 48,000

km (30,000 miles), whichever comes

first.
Replacement

SPARK PLUG CAP

1. Clean up any dirt and oil around the spark plug caps.
2. Remove the spark plug cap by pulling it straight out.
3. Remove the spark plug with a 16 mm (5/8 inch) spark plug socket. 4. Put the new spark plug into the
socket, then thread it into the hole
Screw it in by hand so you do not
crossthread it

MaintenanceProCarManuals.comMain Menu s t Table of Contents

Spark Plugs

5. Torque the spark plug. (If you do not have a torque wrench, tighten
the spark plug 2/3 turn after itcontacts the cylinder head.)
Tightening torque:
18 N.m (1.8 kgf.m , 13 Ibf.ft)

Tighten the spark plugs carefully. A
spark plug that is too loose can overheat and damage the engine. Overtightening can cause damage to
the threads in the cylinder head.

6. Install the spark plug cap.
7. Repeat this procedure for the other three spark plugs.
Specifications:

NGK:

Nippondenso:

Spark Plug Gap:
ZFR5F-11

KJ16CR-L11

1.1 mm (0.04 in)

Maintenance

NOTICE
