2023 TOYOTA BZ4X shift

3515-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
NOTICE
●Check the battery charge level
of the smartphon e before using
Remote control function. If the
battery of the smartphone dies
while operating Remote control
function, assist will be sus-
pended. Also, if the battery
charge level of the smartphone
is 20% or less when attempting
to start Remote control function,
Remote control function will not
be started.
●Turn on the Bluetooth communi-
cation function of the smart-
phone before using Remote
control function. Remote con-
trol function cannot be used if
the Bluetooth function is off.
●Do not turn off the Bluetooth
function of the smartphone or
disconnect from the multimedia
system while using Remote
control function. If the vehicle
cannot be connected to via
Bluetooth, Remote control func-
tion cannot be used.
●While using Remote control
function, if a call is received,
etc., and another app is
opened, Remote control func-
tion will be suspended. Assist
can be resumed if the Remote
Park app is reopened within 3
minutes. If 3 minutes or more
elapse, assist will be canceled.
●While using Remote control
function, if the home button or
power button of the smartphone
is pressed and the screen is
locked, Remote control function
will be suspended. Assist can
be resumed if the Remote Park
app is reopened within 3 min-
utes. If 3 minutes or more
elapse, assist will be canceled.
●Do not use the Remote Park
app with devices other than
those which operation has been
confirmed by the maker. Other-
wise the system may not oper-
ate correctly.
●When the ambient temperature
is low, it may take time for the
system to start, due to 12-volt
battery charging.
●If the 12-volt battery voltage
drops, assistance will be can-
celed.
●When using Remote control
function on a slope, the vehicle
speed will be slower and the
distance that th e vehicle will
approach objects will become
longer than when on a level
road surface.
●If a system temporary failure
occurs, after th e vehicle is
stopped by the electronic park-
ing brake or the shift position
being changed to P, the power
switch may turn off and the sys-
tem may be canceled. In this
case, have the vehicle
inspected by your Toyota
dealer.
●If a system malfunction occurs,
assistance may be temporarily
suspended. If the system
returns to normal, operation can
be resumed. Follow the content
on the smartphone screen to
resume operation.
●Remote control function cannot
be started if the EV system has
been started using an aftermar-
ket remote starter.

3565-4. Using the driving support systems
Owners Manual_USA_M42C01_enbe displayed over the guidance dis-
play.
■Brake control operation when
Advanced Park is operating
While the Advanced Park is operat-
ing, if the system determines that
the possibility of collision with
detected moving or stationary object
is high, the EV system output
restriction control and brake control
will operate.
If brake control operates, Advanced
Park operation will be suspended
and a message will be displayed on
the multi-information display.
■Buzzer
Depending on surrounding sounds
or sounds from other systems, it
may be difficult to hear the buzzer of
this system.
■If a black screen is displayed on
the multimedia display when
the Advanced Park is operating
The system is being affected by
radio waves or may be malfunction-
ing. If a radio antenna is installed
near a camera, move it to a location
as far from the cameras as possible.
If a radio antenna is not installed
near a camera, and the screen does
not return to normal after turning the
power switch off and then starting
the EV system agai n, have the vehi-
cle inspected by your Toyota dealer.
■Function description
The perpendicular parking (for-
ward/reverse) function can be
used if the target parking space
can be detected when the vehi-
cle is stopped close and perpen-
dicular to the center of the parking space. Also, depending
on the condition of the parking
space, etc., if it is necessary to
change the direction of travel of
the vehicle, the shift position can
be changed by assistance con-
trol.
■Parking using the perpen-
dicular parking (for-
ward/reverse) function
1 Stop the vehicle at a position
close and perpendicular to
the center of the target park-
ing space.
If there are parking space
lines
Approximately 3.3 ft. (1 m)
*
Approximately 8.2 ft. (2.5 m)*
Approximately 19.7 ft. (6 m)
or more
*
Approximately 18.0 ft. (5.5 m)
or more
*
The system can o perate even if
there is a parking space line on only
one side of the target parking
space.
*: This is a reference measurement for detection of a parking space.
Advanced Park Perpen-
dicular parking (for-
ward/reverse) function

3585-4. Using the driving support systems
Owners Manual_USA_M42C01_en
3Select “Start” button.
A buzzer will sound, an operation
message will be dis played on the
multi-information display, and assis-
tance will begin operating.
 When the brake pedal is
released, “Moving Forward...”,
“Backing Up...” will be dis-
played and the vehicle will
begin moving for-
ward/reverse.
 To cancel assistance, press
the Advanced Park main
switch.
If assistance is canceled,
“Advanced Park Cancelled” will be
displayed.
If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter:  P. 3 5 8
4Perform operations as indi-
cated by the advice displays
until the vehicle stops in the
target parking space.
When the vehicle stops, “Advanced
Park Finished” will be displayed
and parking assistance will end.
If you select on the multimedia
display, the vehicle displayed on
the parking assist completion screen will rotate.
■If you feel that
the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter
Depress the brake pedal to stop the
vehicle and then change the shift
position to change the direction of
travel of the vehicle. At this time,
assist will be sus pended. However,
if the “Start” button is selected,
assist will resume and the vehicle
will move in the di rection corre-
sponding to the selected shift posi-
tion.
NOTICE
■When using the perpendicu-
lar parking (forward/reverse)
function
●Make sure that there are no
obstructions within the yellow
guide lines and between the
vehicle and target parking spot.
If there are any obstructions
between the vehicle and the tar-
get parking space, or between
the yellow guide lines, cancel
the function.
●As the tar get parking space will
not be able to be set correctly if
the surface of the parking space
is on a slope or has differences
in height, the veh icle may stray
from the target parking space or
be slanted. Therefore, do not
use the function f or this kind of
parking spot.

3595-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
■Function description
When exiting from a perpendic-
ular parking space, if the system
determines that exit is possible
the perpendicular exiting (for-
ward/reverse) function can be
used. Also, depending on the
surrounding environment, if it is
necessary to change the direc-
tion of travel of the vehicle, the
shift position can be changed by
assistance control.
■Perpendicular exiting (for-
ward/reverse) function
1 With the brake pedal
depressed and P shift posi-
tion selected, press the
Advanced Park main switch and check that the exit direc-
tion selection screen is dis-
played on the multimedia
display.
2 Select an arrow on the multi-
media display to select the
direction you wish to exit.
If the turn signal lever is operated,
only exit to the left or right can be
selected.
3Depress the brake pedal and
select “Start” button.
If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter: P.360
A buzzer will sound, an operation
message will be displayed on the
multi information display, and assis-
tance will begin operating. To can-
NOTICE
●When parking in a narrow park-
ing space, the vehicle may
closely approach an adjacent
parked vehicle. If a collision
seems likely, depress the brake
pedal to stop the vehicle.
●If a detected parked vehicle is
narrow or parked extremely
close to the curb, the position at
which assistance will park the
vehicle will also be close to the
curb. If it seems likely the vehi-
cle will collide with something or
drive off of the road, depress
the brake pedal to stop the vehi-
cle, and then press the Advance
Park main switch to disable the
system.
Advanced Park perpen-
dicular exiting (for-
ward/reverse) function

3605-4. Using the driving support systems
Owners Manual_USA_M42C01_encel assistance, press the Advanced
Park main switch. If assistance is
canceled, “Advanced Park Can-
celled” will be displayed.
4
Perform operations as indi-
cated by the advice displays
until the vehicle is in a posi-
tion where exit is possible.
If the steering w heel is not oper-
ated, the vehicle will stop at the exit
position. Assistance can be ended
by depressing the accelerator pedal
or brake pedal. When the vehicle
reaches a position where exit is
possible, “You can exit by moving
the steering wheel” will be dis-
played. If the steering wheel is
operated, “Advanced Park Fin-
ished” will be displayed and assis-
tance will end. Gri p the steering
wheel and drive forward.
■If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter
Depress the brake pedal to stop the
vehicle and then ch ange the shift
position to change the direction of
travel of the vehicle.
At this time, assist will be sus-
pended. However, if the “Start” but-
ton is selected, assist will resume
and the vehicle will move in the
direction corresponding to the
selected shift position.
■Perpendicular exiting (for-
ward/reverse) function
Do not use exiting (for- ward/reverse) function in any situa-
tion other than when exciting a
parallel parking spot. If assistance is
started unintentionally, depress the
brake pedal and stop the vehicle,
then press the Advanced Park main
switch to cancel assistance.
■Situations in which the perpen-
dicular exiting (forward /
reverse) function will not oper-
ate
Situations in which the perpendicu-
lar exiting (forward/reverse) function
will not operate.
●When a vehicle which is waiting to
park is in the exit direction
●When a wall, column, or person is
detected as near a front or rear
center or corner sensor
■Function description
The parallel parking function can
be used if the target parking
space can be detected when the
vehicle is stopped close and
aligned with the center of the
parking space. Also, depending
Advanced Park Parallel
parking function

3615-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
on the condition of the parking
space, etc., if it is necessary to
change the direction of travel of
the vehicle, the shift position can
be changed by assistance con-
trol.
■Parking using the parallel
parking function
1 Stop the vehicle with it
aligned near the center of the
target parking space.
If there are parking space
lines
Approximately 3.3 ft. (1 m)
*
Approximately 16.4 to 19.7 ft.
(5 to 6 m)
*
Approximately 14.8 ft. (4.5 m)
or more
*
Approximately 26.2 ft. (8 m)
or more
*
*: This is a reference measurement for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.
If there is an adjacent parked
vehicle
Approximately 3.3 ft. (1 m)
*
Approximately 23.0 ft. (7 m)
or more
*
Approximately 14.8 ft. (4.5 m)
or more
*
Approximately 26.2 ft. (8 m)
or more
*
*: This is a reference measurement for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.
2 Press the Advanced Park
main switch and check that a

3635-4. Using the driving support systems
Owners Manual_USA_M42C01_en
5
Driving
screen will rotate.
■If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter
Depress the brake pedal to stop the
vehicle and then ch ange the shift
position to change the direction of
travel of the vehicle.
At this time, assist will be sus-
pended. However, if the “Start” but-
ton is selected, assist will resume
and the vehicle will move in the
direction corresponding to the
selected shift position.
■If “No available parking space”
is displayed
Even if the vehicle is stopped paral-
lel to a parking space, an adjacent
parked vehicle may not be detected.
In this case, if the vehicle is moved
to a position that a parked vehicle
can be detected, assistance can be
started.
NOTICE
■When using the parallel park-
ing function
●Make sure that there are no
obstructions within the yellow
guide lines and between the
vehicle and target parking spot.
If any obstructions are detected
within the yellow guide lines or
between the vehicle and the tar-
get parking space, the parallel
parking function will be can-
celled.
●As the tar get parking space will
not be able to be set correctly if
the surface of the parking space
is on a slope or has differences
in height, the veh icle may stray
from the target parking space or
be slanted. Therefore, do not
use the parallel parking func-
tion for this kind of parking spot.
●When parking in a narrow park-
ing space, the vehicle may
closely approach an adjacent
parked vehicle. if a collision
seems likely, depress the brake
pedal to stop the vehicle.

3645-4. Using the driving support systems
Owners Manual_USA_M42C01_en
■Function description
When exiting from a parallel
parking space, if the system
determines that exit is possible
the parallel exiting function can
be used. Also, depending on the
surrounding environment, if it is
necessary to change the direc- tion of travel of the vehicle, the
shift position can be changed by
assistance control.
■Leaving a parking space
using the parallel exiting
function
1 With the brake pedal
depressed and P shift posi-
tion selected, press the
Advanced Park main switch
and check that the exit direc-
tion selection screen is dis-
played on the multimedia
display.
2 Select an arrow on the multi-
media display to select the
direction you wish to exit.
If the turn signal lever is operated,
only exit to the left or right can be
selected.
3Depress the brake pedal and
select “Start” button.
A buzzer will sound, an operation
message will be displayed on the
multi-information display, and assis-
tance will begin operating.
To cancel assistance, press the
Advanced Park main switch.
NOTICE
●If an adjacent parked vehicle is
narrow or parked extremely
close to the curb, the position at
which assistance will park the
vehicle will also be close to the
curb. If it seems likely the vehi-
cle will collide with the curb or
drive off of the road, depress
the brake pedal to stop the vehi-
cle, and then press the
Advanced Park main switch to
disable the system.
●If there is a wall or other barrier
on the inner side of the parking
space, the vehicle may stop at a
position slightly outside of the
set target parking space.
Advanced Park Parallel
exiting function
