2023 CADILLAC XT4 Owners Manual

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
272 Driving and Operating
2. Get up to the desiredspeed.
3. Move the thumbwheel down to SET−. The desired
set speed briefly appears
in the instrument cluster.
4. Remove your foot from the accelerator.
When the cruise control has
been set to the desired speed,
a green cruise control
indicator appears on the
instrument cluster and a
cruise set speed message
appears on the Head-Up
Display (HUD), if equipped.
Resuming a Set Speed
If the cruise control is set at a
desired speed and then the
brakes are applied or
*is
pressed, the cruise control is
disengaged without erasing
the set speed from memory.
Once the vehicle speed
reaches about 40 km/h
(25 mph) or more, move the thumbwheel up toward RES+
briefly. The vehicle returns to
the previous set speed.
Increasing Speed While Using
Cruise Control
If the cruise control system is
already activated:
.Move the thumbwheel up
toward RES+ until the
desired speed is reached,
then release it.
.To increase vehicle speed in
small increments, move the
thumbwheel up toward
RES+ briefly. For each press,
the vehicle goes about
1 km/h (1 mph) faster.
.To increase vehicle speed in
larger increments, move the
thumbwheel up toward
RES+ to the second detent.
For each press, the vehicle
speed increases to the next
5 km/h (5 mph) mark on the
speedometer.
The speedometer reading can
be displayed in either English
or metric units. See
Instrument Cluster
0119. The
increment value used depends
on the units displayed.
Reducing Speed While Using
Cruise Control
If the cruise control system is
already activated:
.Move the thumbwheel down
toward SET− until the
desired lower speed is
reached, then release it.
.To decrease the vehicle
speed in small increments,
move the thumbwheel down
toward SET− briefly. For
each press, the vehicle goes
about 1 km/h (1 mph) slower.
.To decrease the vehicle
speed in larger increments,
move the thumbwheel down
toward SET− to the second
detent. For each press, the
vehicle speed decreases to
the next 5 km/h (5 mph) mark
on the speedometer.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 273
The cruise control system may
automatically brake to slow
the vehicle down.
The speedometer reading can
be displayed in either English
or metric units. See
Instrument Cluster0119. The
increment value used depends
on the units displayed.
Passing Another Vehicle
While Using Cruise Control
Use the accelerator pedal to
increase the vehicle speed.
When you take your foot off
the pedal, the vehicle will slow
down to the previous set
cruise speed.
While pressing the accelerator
pedal or shortly following the
release to override cruise,
briefly moving the thumbwheel
down toward SET− will result
in cruise set to the current
vehicle speed.
Using Cruise Control on Hills
How well the cruise control will
work on hills depends upon
the vehicle speed, load, and the steepness of the hills.
When going up steep hills, you
might have to step on the
accelerator pedal to maintain
your speed. When going
downhill, the cruise control
system may automatically
brake to slow the vehicle
down. Also, you may have to
brake or shift to a lower gear
to keep your speed down.
If the brake pedal is applied,
cruise control disengages.
Ending Cruise Control
There are four ways to end
cruise control:
.Step lightly on the brake
pedal.
.Press*.
.Shift the transmission to
N (Neutral).
.PressJ.
Erasing Speed Memory
The cruise control set speed is
erased from memory if
Jis
pressed or if the ignition is
turned off.
Adaptive Cruise
Control (Advanced)
If equipped with Adaptive
Cruise Control (ACC), it allows
the driver to select the cruise
control set speed and
following gap. Read this entire
section before using this
system. The following gap is
the following time between
your vehicle and a vehicle
detected directly ahead in
your path, moving in the same
direction. If no vehicle is
detected in your path, ACC
works like regular cruise
control. ACC uses camera and
radar sensors. See Radio
Frequency Statement 0446.
If a vehicle is detected in your
path, ACC can apply
acceleration or limited,
moderate braking to maintain
the selected following gap. To
disengage ACC, apply the
brake. If ACC is controlling
your vehicle speed when the
Traction Control System (TCS)
or StabiliTrak/Electronic

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
274 Driving and Operating
Stability Control (ESC) system
activates, the ACC may
automatically disengage. See
Traction Control/Electronic
Stability Control0267. When
road conditions allow ACC to
be safely used, the ACC can
be turned back on.
Disabling the TCS or
StabiliTrak/ESC system will
disengage and prevent
engagement of ACC.
ACC can reduce the need for
you to frequently brake and
accelerate, especially when
used on expressways,
freeways, and interstate
highways. When used on other
roads, you may need to take
over the control of braking or
acceleration more often.
ACC automatically slows the
vehicle down while navigating
the curve and may increase
speed out of the curve, but will
not exceed the set speed.{Warning
ACC has limited braking
ability and may not have
time to slow the vehicle
down enough to avoid a
collision with another vehicle
you are following. This can
occur when vehicles
suddenly slow or stop
ahead, or enter your lane.
Also see “Alerting the
Driver” in this section.
Complete attention is
always required while driving
and you should be ready to
take action and apply the
brakes. See Defensive
Driving 0230.
{Warning
ACC will not detect or brake
for children, pedestrians,
animals, or other objects.
Do not use ACC when:
.On winding and hilly roads
or when the sensors are
blocked by snow, ice,
or dirt. The system may
not detect a vehicle
ahead. Keep the entire
front of the vehicle clean.
.Visibility is low, such as in
fog, rain, or snow
conditions. ACC
performance is limited
under these conditions.
.On slippery roads where
fast changes in tire
traction can cause
excessive wheel slip.
.When towing a trailer.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 275
J:Press to turn the system
on or off. The indicator turns
white on the instrument
cluster when ACC is
turned on.
RES+ : Press briefly to resume
the previous set speed or to
increase vehicle speed if ACC
is already activated. To
increase speed by 1 km/h
(1 mph), press RES+ to the first
detent. To increase speed to
the next 5 km/h (5 mph) mark
on the speedometer, press
RES+ to the second detent. SET–
:Press briefly to set the
speed and activate ACC or to
decrease vehicle speed if ACC
is already activated. To
decrease speed by 1 km/h
(1 mph), press SET− to the first
detent. To decrease speed to
the next 5 km/h (5 mph) mark
on the speedometer, press
SET− to the second detent.
*:Press to disengage ACC
without erasing the selected
set speed.
[: Press to select a
following gap time (or
distance) setting for ACC of
Far, Medium, or Near.
Switching Between ACC and
Regular Cruise Control
To switch between ACC and
regular cruise control, press
and hold
*. A Driver
Information Display (DIC)
message displays. See Vehicle
Messages 0143.
ACC IndicatorRegular Cruise
Control
Indicator
When ACC is engaged, a
green
oindicator will be lit on
the instrument cluster and the
following gap will be displayed.
When the regular cruise
control is engaged, a green
J
indicator will be lit on the
instrument cluster; the
following gap will not display.
It is recommended to switch
from ACC to regular Cruise
Control when there are no
vehicles ahead of your vehicle.
When the vehicle is turned on,
the cruise control mode will be
set to the last mode used
before the vehicle was
turned off.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
276 Driving and Operating
{Warning
Always check the cruise
control indicator on the
instrument cluster to
determine which mode
cruise control is in before
using the feature. If ACC is
not active, the vehicle will
not automatically brake for
other vehicles, which could
cause a crash if the brakes
are not applied manually.
You and others could be
seriously injured or killed.
Setting Adaptive Cruise
Control
If
Jis on when not in use, it
could get pressed and go into
cruise when not desired. Keep
Joff when cruise is not
being used.
Select the set speed desired
for cruise. This is the vehicle
speed when no vehicle is
detected in its path. ACC will not set at a speed
less than 25 km/h (15 mph),
although it can be resumed
when driving at lower speeds.
The minimum allowable set
speed is 25 km/h (15 mph).
To set ACC while moving:
1. Press
J.
2. Get up to the desired speed.
3. Press and release SET–.
4. Remove your foot from the accelerator.
After ACC is set, it may
immediately apply the brakes if
a vehicle ahead is detected
closer than the selected
following gap.
ACC can also be set while the
vehicle is stopped if ACC is on
and the brake pedal is applied. The ACC indicator displays on
the instrument cluster and
Head-Up Display (HUD),
if equipped. When ACC is
turned on, the indicator will be
lit white. When ACC is
engaged, the indicator will turn
green.
Be mindful of speed limits,
surrounding traffic speeds,
and weather conditions when
selecting the set speed.
Resuming a Set Speed
If the ACC is set at a desired
speed and then the brakes are
applied, ACC is disengaged
without erasing the set speed
from memory.
To begin using ACC again,
press RES+ up briefly.
.If the vehicle is moving more
than 5 km/h (3 mph), it
returns to the previous set
speed.
.If the vehicle is stopped with
the brake pedal applied,
press RES+ and release the

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 277
brake pedal. ACC will hold
the vehicle until RES+ or the
accelerator pedal is pressed.
A green ACC indicator and the
set speed display on the
instrument cluster. The vehicle
ahead indicator may be
flashing if a vehicle ahead was
present and moved. See
“Approaching and Following a
Vehicle” later in this section.
Once ACC has resumed,
if there is no vehicle ahead,
if the vehicle ahead is beyond
the selected following gap,
or if the vehicle has exited a
sharp curve, then the vehicle
speed will increase to the set
speed.
Increasing Speed While ACC
is at a Set Speed
If ACC is already activated, do
one of the following:
.Use the accelerator to get
to the higher speed. Briefly
press and release SET– and
release the accelerator
pedal. The vehicle will now cruise at the higher speed.
When the accelerator pedal
is pressed, ACC will not
brake because it is
overridden. While
overridden, the ACC
indicator will turn blue on the
instrument cluster and
heads up display,
if equipped.
.Press and hold RES+ until
the desired set speed is
displayed, then release it.
.To increase speed in small
increments, press RES+ to
the first detent. For each
press, the vehicle goes
1 km/h (1 mph) faster.
.To increase speed in larger
increments, press RES+ to
the second detent. For each
press, the vehicle speed
increases to the next 5 km/h
(5 mph) mark on the
speedometer.
The set speed can also be
increased while the vehicle is
stopped.
.If stopped with the brake
applied, press RES+ until the
desired set speed is
displayed.
.If ACC is holding the vehicle
at a stop and there is
another vehicle directly
ahead, pressing RES+ will
increase the set speed.
.Pressing RES+ when there is
no longer a vehicle ahead or
the vehicle ahead is pulling
away and the brake is not
applied will cause the ACC to
resume.
When it is determined that
there is no vehicle ahead or
the vehicle ahead is beyond
the selected following gap,
then the vehicle speed will
increase to the set speed.
The speedometer reading can
be displayed in either English
or metric units. See
Instrument Cluster 0119. The
increment value used depends
on the units displayed.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
278 Driving and Operating
Reducing Speed While ACC is
at a Set Speed
If ACC is already activated, do
one of the following:
.Use the brake to get to the
desired lower speed.
Release the brake and press
SET–. The vehicle will now
cruise at the lower speed.
.Press and hold SET– until
the desired lower speed is
reached, then release it.
.To decrease speed in
smaller increments, press
SET− to the first detent. For
each press, the vehicle goes
about 1 km/h (1 mph) slower.
.To decrease speed in larger
increments, press SET− to
the second detent. For each
press, the vehicle speed
decreases to the next
5 km/h (5 mph) mark on the
speedometer.
The set speed can also be
decreased while the vehicle is
stopped.
.If stopped with the brake
applied, press or hold SET−
until the desired set speed is
displayed.
Selecting the Follow
Distance Gap
When a slower moving vehicle
is detected ahead within the
selected following gap, ACC
will adjust the vehicle's speed
and attempt to maintain the
follow distance gap selected.
Press
[on the steering
wheel to adjust the following
gap. Each press cycles the gap
button through three settings:
Far, Medium, or Near.
When pressed, the current
gap setting displays briefly on
the instrument cluster and
HUD, if equipped. The gap
setting will be maintained until
it is changed.
Since each gap setting
corresponds to a following
time (Far, Medium, or Near),
the following distance will vary
based on vehicle speed. The faster the vehicle speed, the
further back your vehicle will
follow a vehicle detected
ahead. Consider traffic and
weather conditions when
selecting the following gap.
The range of selectable gaps
may not be appropriate for all
drivers and driving conditions.
Changing the gap setting
automatically changes the
alert timing sensitivity (Far,
Medium, or Near) for the
Forward Collision Alert (FCA)
feature. See Forward Collision
Alert (FCA) System
0297.
Alerting the Driver
With Head-Up Display

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 279
Without Head-Up Display
If ACC is engaged, driver
action may be required when
ACC cannot apply sufficient
braking because of
approaching a vehicle too
rapidly.
When this condition occurs,
the collision alert symbol will
flash on the windshield. Either
eight beeps will sound from
the front, or both sides of the
Safety Alert Seat will pulse
five times. Touch the Settings
icon on the infotainment home
page. Select “Vehicle”to
display the list of available
options and select “Collision/
Detection Systems”.
See Defensive Driving 0230. Approaching and Following a
Vehicle
The vehicle ahead indicator is
in the instrument cluster and
HUD display, if equipped.
The vehicle ahead indicator
only displays when a vehicle is
detected in your vehicle’s path
moving in the same direction.
If this symbol is not displaying,
ACC will not respond to or
brake for vehicles ahead.
ACC automatically slows the
vehicle down and adjusts
vehicle speed to follow the
vehicle in front at the selected
follow gap. The vehicle speed
increases or decreases to
follow the vehicle in front of
you, but will not exceed the
set speed. It may apply limited
braking, if necessary. When braking is active, the brake
lamps will come on. The
automatic braking may feel or
sound different than if the
brakes were applied manually.
This is normal.
Passing a Vehicle While
Using ACC
If the set speed is high
enough, and the left turn
signal is used to pass a vehicle
ahead in the selected
following gap, ACC may assist
by gradually accelerating the
vehicle prior to the lane
change.
{Warning
When using ACC to pass a
vehicle or perform a lane
change, the following
distance to the vehicle being
passed may be reduced.
ACC may not apply
sufficient acceleration or
braking when passing a
vehicle or performing a lane
(Continued)
