2023 CADILLAC XT4 Owners Manual

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
320 Driving and Operating
VehicleMaximum Trailer
Weight GCWR* Maximum
Tongue Weight
2.0L L4 Gas Engine (LSY) 1 134 kg (2,500 lb) 3 150 kg (6,945 lb) 113 kg (250 lb)
2.0L L4 Gas Engine (LSY) with
Heavy Duty Cooling System (V08) 1 588 kg (3,500 lb) 3 600 kg
(7,936 lb)159 kg (350 lb)
*The Gross Combination Weight Rating (GCWR) is the total allowable weight of the completely
loaded vehicle and trailer including any passengers, cargo, equipment, and conversions. The
GCWR for the vehicle should not be exceeded.
Maximum Trailer Tongue
Weight Rating
The Maximum Trailer Tongue
Weight Rating is the allowable
trailer tongue weight that the
vehicle can support using a
conventional trailer hitch.
It may be necessary to reduce
the overall trailer weight to
stay within the maximum
trailer tongue weight rating
while still maintaining the
correct trailer load balance.
The trailer tongue weight
contributes to the Gross
Vehicle Weight (GVW). GVW
includes the curb weight of
your vehicle, any passengers, cargo, equipment and the
trailer tongue weight. Vehicle
options, passengers, cargo,
and equipment reduce the
maximum allowable tongue
weight the vehicle can carry,
which also reduces the
maximum allowable trailer
weight.
Trailer Load Balance
The correct trailer load
balance must be maintained to
ensure trailer stability.
Incorrect load balance is a
leading cause of trailer sway.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 321
The trailer tongue weight (1)
should be 10% of the total
loaded trailer weight (2). Some
specific trailer types, such as
boat trailers, fall outside of
this range. Always refer to the
trailer owner’s manual for the
recommended trailer tongue
weight for each trailer. Never
exceed the maximum loads for
your vehicle, hitch and trailer.
The trailer load
balance percentage is
calculated as: weight (1)
divided by weight (2)
times 100.After loading the trailer,
separately weigh the trailer
and then the trailer tongue to
see if the weights are
appropriate for your vehicle.
If the trailer weight is too high,
it may be possible to transfer
some of the cargo into your
vehicle. If the trailer tongue
weight is too high or too low, it
may be possible to rearrange
some of the cargo inside of
the trailer.
Do not exceed the maximum
allowable tongue weight for
your vehicle. Use the shortest
hitch extension available to
position the hitch ball closer to
your vehicle. This will help
reduce the effect of the trailer
tongue weight on the trailer
hitch and the rear axle.
If a cargo carrier is used in the
trailer hitch receiver, choose a
carrier that positions the load
as close to the vehicle as
possible. Make sure the total
weight, including the carrier, is
no more than half of themaximum allowable tongue
weight for the vehicle or
227 kg (500 lb), whichever
is less.
Ask your dealer for trailering
information or assistance.
Rear Gross Axle Weight
Rating (GAWR-RR)
The GAWR-RR is the total
weight that can be supported
by the rear axle of the vehicle.
Do not exceed the GAWR-RR
for the vehicle, with the tow
vehicle and trailer fully loaded
for the trip including the
weight of the trailer tongue.
If using a weight-distributing
hitch, do not exceed the
GAWR-RR before applying the
weight distribution
spring bars.
For additional assistance with
trailering or additional
information, see your dealer.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
322 Driving and Operating
Towing Equipment
Hitches
Always use the correct hitch
equipment for your vehicle.
Crosswinds, large trucks going
by, and rough roads can affect
the trailer and the hitch.
Proper hitch equipment for
your vehicle helps maintain
control of the vehicle-trailer
combination. Many trailers can
be towed using a
weight-carrying hitch which
has a coupler latched to the
hitch ball, or a tow eye latched
to a pintle hook. Other trailers
may require a
weight-distributing hitch that
uses spring bars to distribute
the trailer tongue weight
between your vehicle and
trailer axles. See“Maximum
Trailer Tongue Weight” under
Trailer Towing 0318 for
weight limits with various hitch
types. Never attach rental hitches or
other bumper-type hitches.
Only use frame-mounted
hitches that do not attach to
the bumper.
Hitch Cover
To remove hitch cover,
if equipped:
1. Remove the two fasteners on the lower tabs.
2. Pull the lower edge of the cover to about a 45 degree
angle.
3. Pull the cover downward to disengage the upper
attachments. To reinstall the hitch cover:
1. Hold cover at a 45 degree angle to the vehicle and
push the upper tabs into
the slots in the bumper.
2. Push the bottom of the cover forward until the
lower tabs line up with the
lower slots.
3. Snap the hitch cover into place by pushing the upper
corners forward.
4. Reinstall the two fasteners on the lower tabs.
Consider using mechanical
sway controls with any trailer.
Ask a trailering professional
about sway controls or refer
to the trailer manufacturer's
recommendations and
instructions.
Tires
.Do not tow a trailer while
using a compact spare tire
on the vehicle.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 323
.Tires must be properly
inflated to support loads
while towing a trailer. See
Tires0364 for instructions
on proper tire inflation.
Safety Chains
Always attach chains between
the vehicle and the trailer, and
attach the chains to the holes
on the trailer hitch platform.
Instructions about safety
chains may be provided by the
hitch manufacturer or by the
trailer manufacturer.
Cross the safety chains under
the tongue of the trailer to
help prevent the tongue from
contacting the road if it
becomes separated from the
hitch. Always leave just
enough slack so the
combination can turn. Never
allow safety chains to drag on
the ground.
Trailer Brakes
Loaded trailers over 450 kg
(1,000 lb) must be equipped
with brake systems and with brakes for each axle. Trailer
braking equipment conforming
to Canadian Standards
Association (CSA) requirement
CAN3-D313, or its equivalent,
is recommended.
State or local regulations may
require trailers to have their
own braking system if the
loaded weight of the trailer
exceeds certain minimums
that can vary from state to
state. Read and follow the
instructions for the trailer
brakes so they are installed,
adjusted, and maintained
properly. Never attempt to tap
into your vehicle's hydraulic
brake system. If you do, both
the vehicle anti-lock brakes
and the trailer brakes may not
function, which could result in
a crash.
Trailer Wiring Harness
Basic Trailer Wiring
The trailer wiring harness is
located at the rear of the
vehicle and is tied to the
vehicle's frame. The harness
connector can be plugged into
a trailer connector available
through your dealer.
Trailer Lamps
Always check all trailer lamps
are working at the beginning
of each trip, and periodically
on longer trips.
Turn Signals When
Towing a Trailer
When properly connected, the
trailer turn signals will
illuminate to indicate the
vehicle is turning, changing
lanes, or stopping. When
towing a trailer, the arrows on
the instrument cluster will
illuminate even if the trailer is
not properly connected or the
bulbs are burned out.
Trailer Sway
Control (TSC)
Vehicles with StabiliTrak/
Electronic Stability Control
(ESC) have a Trailer Sway

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
324 Driving and Operating
Control (TSC) feature. Trailer
sway is unintended
side-to-side motion of a trailer
while towing. If the vehicle is
towing a trailer and the TSC
detects that sway is
increasing, the vehicle brakes
are selectively applied at each
wheel, to help reduce
excessive trailer sway.
If equipped with the
Integrated Trailer Brake
Control (ITBC) system, and the
trailer has an electric brake
system, StabiliTrak/ESC may
also apply the trailer brakes.
If TSC is enabled, the Traction
Control System (TCS)/
StabiliTrak/ESC warning light
will flash on the instrument
cluster. Reduce vehicle speed
by gradually removing your
foot from the accelerator.If trailer sway continues,
StabiliTrak/ESC can reduce
engine torque to help slow the
vehicle. TSC will not function if
StabiliTrak/ESC is turned off.
See Traction Control/
Electronic Stability Control
0
267.
{Warning
Trailer sway can result in a
crash and in serious injury or
death, even if the vehicle is
equipped with TSC.
If the trailer begins to sway,
reduce vehicle speed by
gradually removing your foot
from the accelerator. Then
pull over to check the trailer
and vehicle to help correct
possible causes, including an
improperly or overloaded
trailer, unrestrained cargo,
improper trailer hitch
configuration, or improperly
inflated or incorrect vehicle
(Continued)
Warning (Continued)
or trailer tires. See Towing
Equipment0322 for trailer
ratings and hitch setup
recommendations.
Trailer Tires
Special Trailer (ST) tires differ
from vehicle tires. Trailer tires
are designed with stiff
sidewalls to help prevent sway
and to support heavy loads.
These features can make it
difficult to determine if the
trailer tire pressures are low
only based on a visual
inspection.
Always check all trailer tire
pressures before each trip
when the tires are cool. Low
trailer tire pressure is a
leading cause of trailer tire
blow-outs.
Trailer tires deteriorate over
time. The trailer tire sidewall
will show the week and year
the tire was manufactured.
Many trailer tire

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Driving and Operating 325
manufacturers recommend
replacing tires more than six
years old.
Overloading is another leading
cause of trailer tire blow-outs.
Never load your trailer with
more weight than the tires are
designed to support. The load
rating is located on the trailer
tire sidewall.
Always know the maximum
speed rating for the trailer
tires before driving. This may
be significantly lower than the
vehicle tire speed rating. The
speed rating may be on the
trailer tire sidewall. If the
speed rating is not shown, the
default trailer tire speed rating
is 105 km/h (65 mph).Conversions and
Add-Ons
Add-On Electrical
Equipment
{Warning
The Data Link Connector
(DLC) is used for vehicle
service and Emission
Inspection/Maintenance
testing. See Malfunction
Indicator Lamp (Check
Engine Light)0126. A device
connected to the DLC —
such as an aftermarket fleet
or driver-behavior tracking
device —may interfere with
vehicle systems. This could
affect vehicle operation and
cause a crash. Such devices
may also access information
stored in the vehicle’s
systems.
Caution
Some electrical equipment
can damage the vehicle or
cause components to not
work and would not be
covered by the vehicle
warranty. Always check with
your dealer before adding
electrical equipment.
Add-on equipment can drain
the vehicle's 12-volt battery,
even if the vehicle is not
operating.
The vehicle has an airbag
system. Before attempting to
add anything electrical to the
vehicle, see Servicing the
Airbag-Equipped Vehicle 076
and Adding Equipment to the
Airbag-Equipped Vehicle 077.

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
326 Vehicle Care
Vehicle Care
General Information
General Information . . . . . . 327
California PerchlorateMaterials
Requirements . . . . . . . . . . . . . 327
Accessories and Modifications . . . . . . . . . . . . . . 327
Vehicle Checks
Doing Your OwnService Work . . . . . . . . . . . . . . 328
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . 329
Engine Compartment Overview . . . . . . . . . . . . . . . . . . . . 331
Engine Oil . . . . . . . . . . . . . . . . . . . . 332
Engine Oil Life System . . . 335
Automatic Transmission Fluid . . . . . . . . . . . . . . . . . . . . . . . . . 336
Engine Air Filter Life System . . . . . . . . . . . . . . . . . . . . . . 336
Engine Air Cleaner/ Filter . . . . . . . . . . . . . . . . . . . . . . . . . 337
Cooling System . . . . . . . . . . . . 338
Engine Overheating . . . . . . 342
Washer Fluid . . . . . . . . . . . . . . . . 343
Brakes . . . . . . . . . . . . . . . . . . . . . . . . 344
Brake Fluid . . . . . . . . . . . . . . . . . . 345 Battery - North
America . . . . . . . . . . . . . . . . . . . . . 346
All-Wheel Drive . . . . . . . . . . . . . 347
Park Brake and P (Park) Mechanism Check . . . . . . . 347
Wiper Blade Replacement . . . . . . . . . . . . . . 347
Windshield Replacement . . . . . . . . . . . . . . 349
Gas Strut(s) . . . . . . . . . . . . . . . . . 349Headlamp Aiming
Front Headlamp Aiming . . . . . . . . . . . . . . . . . . . . . . . 350
Bulb Replacement
Bulb Replacement . . . . . . . . 350
LED Lighting . . . . . . . . . . . . . . . . 350
Front Turn SignalLamps . . . . . . . . . . . . . . . . . . . . . . . 350
Back-Up Lamps . . . . . . . . . . . . . 351
Electrical System
Electrical System Overload . . . . . . . . . . . . . . . . . . . . 352
Fuses and Circuit Breakers . . . . . . . . . . . . . . . . . . . . 353
Engine Compartment Fuse Block . . . . . . . . . . . . . . . . . 354
Instrument Panel Fuse Block . . . . . . . . . . . . . . . . . . . . . . . . 360
Wheels and Tires
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . 364
All-Season Tires . . . . . . . . . . . 365
Winter Tires . . . . . . . . . . . . . . . . 366
Summer Tires . . . . . . . . . . . . . . 366
Tire Sidewall Labeling . . . . 367
Tire Designations . . . . . . . . . . 369
Tire Terminology andDefinitions . . . . . . . . . . . . . . . . . 370
Tire Pressure . . . . . . . . . . . . . . . 372
Tire Pressure for High-Speed
Operation . . . . . . . . . . . . . . . . . . 374
Tire Pressure Monitor System . . . . . . . . . . . . . . . . . . . . . . 375
Tire Pressure Monitor Operation . . . . . . . . . . . . . . . . . . 376
Tire Inspection . . . . . . . . . . . . . 380
Tire Rotation . . . . . . . . . . . . . . . . 381
When It Is Time for New Tires . . . . . . . . . . . . . . . . . . . . . . . . . 382
Buying New Tires . . . . . . . . . 383
Different Size Tires and Wheels . . . . . . . . . . . . . . . . . . . . . . 385
Uniform Tire Quality Grading . . . . . . . . . . . . . . . . . . . . . 385
Wheel Alignment and Tire Balance . . . . . . . . . . . . . . . . . . . . . 387
Wheel Replacement . . . . . . 387
Tire Chains . . . . . . . . . . . . . . . . . . 388

Cadillac XT4 Owner Manual (GMNA-Localizing-U.S./Canada/Mexico-
16412876) - 2023 - CRC - 3/25/22
Vehicle Care 327
If a Tire Goes Flat . . . . . . . . . 389
Tire Sealant andCompressor Kit . . . . . . . . . . 390
Storing the Tire Sealant and Compressor Kit . . . . . 398
Tire Changing . . . . . . . . . . . . . . 398
Compact Spare Tire . . . . . . 404
Jump Starting
Jump Starting - North America . . . . . . . . . . . . . . . . . . . . . 404
Towing the Vehicle
Transporting a DisabledVehicle . . . . . . . . . . . . . . . . . . . . . . 407
Recreational Vehicle Towing . . . . . . . . . . . . . . . . . . . . . . 409
Appearance Care
Exterior Care . . . . . . . . . . . . . . . . 412
Interior Care . . . . . . . . . . . . . . . . . 417
Floor Mats . . . . . . . . . . . . . . . . . . . 421
General
Information
For service and parts needs,
visit your dealer. You will
receive genuine GM parts and
GM-trained and supported
service people.
Genuine GM parts have one of
these marks:
California Perchlorate
Materials
Requirements
Certain types of automotive
applications, such as airbag
initiators, seat belt
pretensioners, and lithium
batteries contained in
electronic keys, may contain
perchlorate materials.
Perchlorate Material –special
handling may apply. See
www.dtsc.ca.gov/
hazardouswaste/perchlorate.
Accessories and
Modifications
Adding non-dealer accessories
or making modifications to the
vehicle can affect vehicle
performance and safety,
including such things as
airbags, braking, stability, ride
and handling, emissions
systems, aerodynamics,
durability, Driver Assistance
Systems, and electronic
systems like antilock brakes,
